  • Page 1 D01127720A US-1800 USB2.0 Audio/MIDI Interface OWNER'S MANUAL...

  • Page 2: Important Safety Instructions

    CAUTION Changes or modifications to this equipment not expressly approved by TEAC CORPORATION for compliance could void the user's authority to operate this equipment. TASCAM US-1800 WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
  • Page 3 19-inch rack, as shown below. Remove the feet of the unit before mounting. NOTE Leave 1U of space above the unit for ventilation. • Allow at least 10 cm (4 in) at the rear of the unit for • ventilation. TASCAM US-1800...

  • Page 4: Table Of Contents

    Uninstalling the driver ...11 Frequently asked installation questions and answers (FAQ) ...11 Settings on your computer ...11 Installing Cubase LE 5 ...11 4 − US-1800 Control panel settings ... 12 Overview ...12 Control panel settings ...12 Audio Performance ...12 Sample Clock Source ...12 Digital Output Format ...12...

  • Page 5: Introduction

    Thank you for your purchase of the TASCAM US-1800 USB2.0 Audio/MIDI Interface. Before connecting and using the unit, please take time to read this manual thoroughly to ensure you understand how to properly set up and connect the unit, as well as the operation of its many useful and convenient functions.

  • Page 6: Trademarks

    1 − Introduction Trademarks TASCAM is a trademark of TEAC Corporation, registered • in the U.S. and other countries. Microsoft, Windows, Windows Vista, Windows 7, and • Windows Media Player are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

  • Page 7: Names And Functions Of Parts

    Failure to do so could cause sudden loud noises and damage hearing, for example. GUITAR ). Use the ) individually. The 1-10 ), from +4 dBu to –42 dBu for Line Inputs knob to adjust the headphones PHONES TASCAM US-1800...

  • Page 8: Rear Panel

    Connect these jacks to monitor speakers, for example. (Tip: HOT, Ring: COLD, Sleeve: GND) Cord holder Loop the cord of the included TASCAM PS-1225L AC adaptor here to prevent the plug from being disconnected accidentally. DC IN 12V jack Connect the included TASCAM PS-1225L AC adaptor to this Jack.

  • Page 9: Installation

    Using a different AC adaptor could cause malfunction, overheating, fire or other problems. Installing the driver In order to use the US-1800, you must install the appropriate driver into your computer. As described below, this is an easy process using the CD-ROM included with the US-1800.

  • Page 10: Installing The Driver For Windows

    This message appears when a driver that has not received Windows Logo testing is installed. This message appears because the drivers for TASCAM products have not received Windows Logo testing. We have, however, confirmed their proper operation. If this message appears, click Continue to proceed with the installation.

  • Page 11: Installing The Driver For Mac Os X

    Version, Device and other data appear correctly, the installation has succeeded. Installing the driver for Mac OS X 1 Confirm that the US-1800 is not connected to the computer. 2 Double-click the TASCAM_US1800_Driver_x.xx.dmg on the included CD-ROM. As the TASCAM_US-1800_x.xx is created on the desktop, open the folder.

  • Page 12: Us-1800 Control Panel Settings

    On Windows OS, the US-1800 Control Panel shortcut can be found in the Windows Start menu > Control Panel or the Start menu > All Programs > TASCAM. On Mac OS X, the US-1800 Control Panel is located in the Applications folder.

  • Page 13: Connections

    Connect all the devices so that they receive power from the same line. When using a power strip, for example, use one • with a thick cable and high electric current capacity to minimize power voltage fluctuation. Vocal microphones Keyboard Computer 5 − Connections Drums Guitar Sound module Drum machine Digital recorder Bass guitar Headphones TASCAM US-1800...

  • Page 14: Usb Connections

    Audio connections Connect the output signal of your mic, guitar, keyboard, or other audio device to the US-1800, where it will be converted into digital audio and sent via USB to your computer. Connect the output of the US-1800 to your...

  • Page 15: Application Guide

    If the above item does not appear, click “Hardware and Sound” and it will appear. 3 Click the Playback tab, click Speakers TASCAM US-1800 and click the Set Default button. This moves the green check mark to Speakers TASCAM US-1800.

  • Page 16: Mac Os X And Itunes

    Click Use this device for sound input and Use this device for sound output. The microphone and speaker icons should move to the US-1800. When using Mac OS 10.5, click the Audio Devices tab and set the Default input, Properties, Default output, and System output to US-1800.

  • Page 17: Midi Implementation Chart

    Mode 2: Omni on, Mono Mode 3: Omni off, Poly Mode 4: Omni off, Mono 7 – MIDI implementation chart Transmitted Received ************* ************* ************* Remarks Through Through Through Through Through Through Through Through Through Through Through Through O: Yes X: No TASCAM US-1800...

  • Page 18: Troubleshooting

    NOTE If the above item does not appear, click “Hardware and Sound” and it will appear. 3 Click the Playback tab, right-click Speakers US-1800 and click the Set Default button. Mac OS X 1 Shut down all applications and open System Preferences from the Apple menu.
  • Page 19 Since Cubase LE 5 is a product provided by Steinberg Media Technologies GmbH, it is not supported by TASCAM. Please use the Cubase LE 5 Help menu (and access the PDF manuals) for information about how to use this software. TASCAM US-1800...

  • Page 20: Specifications

    Headphone output jack (PHONES) Connector: 6.3 mm (1/4”) Standard Stereo phone jack Maximum output: 50 mW + 50 mW (1 kHz, 1%, 32Ω load) TASCAM US-1800 Digital audio input/output Coaxial (DIGITAL IN) terminal Connector: RCA pin jack Compatible signal format: IEC60958-3 (S/PDIF) Input impedance: 75Ω...

  • Page 21: Computer Requirements

    General Sampling frequency 44.1/48/88.2/96 kHz Quantization bit rate 16/24 bit Power Exclusive AC adaptor (TASCAM PS-1225L, included) AC input: 100 - 240 V, 1.0 A DC output: +12 V, 2.0 A Power consumption 7.2 W 9 – Specifications Dimensions (W x H x D) Without projections: 482.6 x 44 x 280 mm/19 x 1.732 x 11.02 in.

  • Page 22: Dimensional Drawings

    Dimensional drawings Illustrations and other depictions may differ in part from the actual product. • Specifications and external appearance may be changed without notification to improve the product. • TASCAM US-1800 432.6 mm 434.2 mm 482.6 mm 465 mm 41.1 mm...

  • Page 23: Block Diagram

    9 – Specifications Block diagram TASCAM US-1800...
  • Page 24 Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacán, CP 04100, México DF, México TEAC UK LIMITED Phone: +44-8451-302511 Suites 19 & 20, Building 6, Croxley Green Business Park, Hatters Lane, Watford, Hertfordshire, WD18 8TE, UK TEAC EUROPE GmbH Phone: +49-611-71580 Bahnstrasse 12, 65205 Wiesbaden-Erbenheim, Germany US-1800 www.tascam.jp www.tascam.com www.tascam.com www.teacmexico.net www.tascam.co.uk www.tascam.de...
