Trust 13351 Instruction Manual

Method when using for the first time
1.

Connections

2. Uninstalling Old Drivers And Devices
3. Installing the driver in Windows 98 /98SE /ME /2000 /XP (3.3)
4. Installing The Usb Card
5. Checking After The Installation
1

Introduction

This instruction manual is for users of the TRUST 2 PORT USB 2.0 PCI CARD. The
TRUST 2 PORT USB 2.0 PCI CARD supports a higher bandwidth (up to 480 Mbps
data transfer) for USB 2.0 devices. This makes the card up to 20 times faster than
the USB 1.1 standard. The TRUST 2 PORT USB 2.0 PCI CARD also supports the
current USB 1.1 devices for a PC.
Note: The TRUST 2 PORT USB 2.0 PCI CARD does not work on a MAC
system.
2

Safety

Carefully read the following instructions before use:
1. Computer components may contain static electricity. You may receive an
electric shock if you touch the computer casing.
2. Turn the computer off and remove the plug from the plug socket before
opening the computer.
3. Make sure the components you wish to add are compatible with your
computer system.
4. Always hold the USB 2.0 card on the edges to prevent damage caused by
static electricity.
3

Installation

3.1 Connections
Follow the instructions below and refer to table 1 and figure 1.
Connection Function
A Connection for external USB devices, such as scanners,
modems, cameras, etc.
Table 1: Connections on the TRUST 2 PORT USB 2.0 PCI CARD
TRUST 2 PORT USB 2.0 PCI CARD
Chapter
(3.1)
!
U K
(3.2)
(3.4)
(4)
1
