VI-2300 FireWire 800 DV PCI Kit
Product information
B
C
D
A: Optional power connection (FDD power connector of power supply)
B: 6 pin 1394a Firewire connection
C: 9-pin 1394b Firewire connection
D: PCI-32 connection
E: PCI-64 connection
Installation
1
2
A
E
Computer off
Open case
1
UK
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trust FIREWIRE 800 DV PCI KIT VI-2300
Summary of Contents for Trust FIREWIRE 800 DV PCI KIT VI-2300
- Page 1 VI-2300 FireWire 800 DV PCI Kit Product information A: Optional power connection (FDD power connector of power supply) B: 6 pin 1394a Firewire connection C: 9-pin 1394b Firewire connection D: PCI-32 connection E: PCI-64 connection Installation Computer off Open case...
- Page 2 VI-2300 FireWire 800 DV PCI Kit Install PCI card in PC firmly Close case Computer on Windows 2000/XP: go to 7 Windows 98SE, assure the latest patch is installed: http://www.microsoft.com/windows98/downloads/contents /WURecommended/S_WUFeatured/1394/Default.asp Windows 98SE/ME: Follow Windows Hardware Wizard to finish (click Next…) Restart system when Windows prompts …...
- Page 3 VI-2300 FireWire 800 DV PCI Kit Windows 2000, assure SP4 is installed Place CD in CD-ROM Install driver because the default Windows driver does not support 1394b Install driver Driver installation may be finished without further prompt When prompt the driver is not digitally signed, please …...
- Page 4 Warranty & copyright • This product has a two-year manufacturer's warranty which is effective from the date of purchase. For more information see www.trust.com/warranty • Reproduction of this manual or any part of it is prohibited without permission from Trust International B.V.
