- Page 1 Operation Veterinary Systems High Frequency Generators APR-VET Console Technical Publication OM-0118R0...
- Page 3 ¡ IMPORTANTE ! ... Protección ante los rayos-X LOS EQUIPOS DE RAYOS-X SON PELIGROSOS PARA EL PACIENTE Y EL OPERADOR A MENOS QUE LAS MEDIDAS DE PROTECCION SEAN ESTRICTAMENTE OBSERVADAS Si el equipo de rayos-X no se usa adecuadamente, puede causar lesiones. Por este motivo, las instrucciones aquí...
- Page 4 DECLARACION AMBIENTAL SOBRE LA VIDA UTIL DEL EQUIPO O SISTEMA Este equipo o sistema contiene componentes y materiales peligrosos para el medioambiente (tales como tarjetas de circuito impreso, componentes electrónicos, aceite dieléctrico usado, plomo, baterías, etc), los cuales se consideran y son residuos peligrosos al finalizar la vida útil del equipo o sistema, según establecen las normas internacionales, nacionales y locales.
- Page 5 High Frequency Generators - Veterinary Systems APR-VET Operation REVISION HISTORY REVISION DATE REASON FOR CHANGE DEC 1, 2005 First edition This Document is the English original version, edited and supplied by the manufacturer. The Revision state of this Document is indicated in the code number shown at the bottom of this page. ADVISORY SYMBOLS The following advisory symbols will be used throughout this manual.
- Page 6 High Frequency Generators - Veterinary Systems APR-VET Operation SAFETY SYMBOLS The following safety symbols will be used in the equipment. Their meaning are described below. Attention, consult accompanying documents. Ionizing radiation. Type B equipment. Dangerous voltage. Ground. This symbol indicates that the waste of electrical and electronic equipment must not be disposed as unsorted municipal waste and must be collected separately.
-
Page 7: Table Of Contents
High Frequency Generators - Veterinary Systems APR-VET Operation TABLE OF CONTENTS Section Page INTRODUCTION ............General Features . -
Page 8: Section Page
High Frequency Generators - Veterinary Systems APR-VET Operation Section Page Brakes ............3.8.1 Brakes of the Tube-collimator Support for Sliding Column . -
Page 9: Introduction
High Frequency Generators - Veterinary Systems APR-VET Operation SECTION 1 INTRODUCTION This manual contains all the necessary information to understand and operate the Veterinay Systems with High Frecuency Generator and Radiographic Console APR-VET. It provides a general description, safety and regulatory information, operation instructions and specifications concerning the equipment. - Page 10 High Frequency Generators - Veterinary Systems APR-VET Operation These Veterinary Systems consist of: High Frequency X-ray Generator designed for general radiography in • Veterinary applications. It provides all the advantages of high frequency waveform generators including lower patient dose, shorter exposure times and greater accuracy and consistency.
-
Page 11: General Features
High Frequency Generators - Veterinary Systems APR-VET Operation GENERAL FEATURES The main features of this System are: Constant potential at high frequency single phase or three phase. • Three point control by selecting kVp, mA and Exposure Time, or two •... -
Page 12: Product Identification
High Frequency Generators - Veterinary Systems APR-VET Operation PRODUCT IDENTIFICATION The major items in the equipment have some identification labels attached to them which provide the following manufacturer and product information. Product • Model. • Volts (V), Line Phases, Frequency (Hz), and Power (kVA, kW). •... -
Page 13: Certifications
High Frequency Generators - Veterinary Systems APR-VET Operation CERTIFICATIONS The X-ray Unit covered by this Operation Manual is authorized to be marked with CE MARKING in accordance with the provisions of the Council Directive 93 / 42 / EEC. CLASSIFICATION The X-ray Generator covered by this Operation Manual is classified as: Protection against Electric Shock: Class I -- Type B applied parts. - Page 14 High Frequency Generators - Veterinary Systems APR-VET Operation This page intentionally left blank. OM-0118R0...
-
Page 15: Safety
High Frequency Generators - Veterinary Systems APR-VET Operation SECTION 2 SAFETY GENERAL Keep this Operating Manual with the equipment at all times and periodically review the Operating and Safety instructions. For continue safe use of this equipment follow the instructions in this Operation Manual. Study this manual carefully before using the equipment and keep it at hand for quick reference. -
Page 16: Responsibilities
High Frequency Generators - Veterinary Systems APR-VET Operation RESPONSIBILITIES ENSURE THAT ALL PERSONNEL AUTHORIZED TO USE THE EQUIPMENT ARE AWARE OF THE DANGER OF EXCESSIVE EXPOSURE TO X-RAY RADIATION. THE EQUIPMENT HEREIN DESCRIBED IS SOLD WITH THE UNDERSTANDING THE MANUFACTURER, ITS AGENTS, AND REPRESENTATIVES ARE NOT LIABLE FOR INJURY OR DAMAGE WHICH MAY RESULT FROM OVEREXPOSURE OF PATIENTS OR PERSONNEL TO X-RAY RADIATION. -
Page 17: Maximum Permissible Dose (Mpd)
High Frequency Generators - Veterinary Systems APR-VET Operation MAXIMUM PERMISSIBLE DOSE (MPD) Before operation, persons qualified and authorized to operate this equipment should be familiar with the Recommendations of the International Commission on Radiological Protection, contained in Annals Number 60 of the ICRP, with applicable National Standards, and should have been trained in use of the equipment. -
Page 18: Monitoring Of Personnel
High Frequency Generators - Veterinary Systems APR-VET Operation MONITORING OF PERSONNEL Monitoring of personnel to determine the amount of radiation to which they have been exposed provides a valuable cross check to determine whether or not safety measures are adequate. It may reveal inadequate or improper radiation protection practices and potentially serious radiation exposure situations. -
Page 19: Operating Controls
Use the operating controls as described in this manual, any other Note non-indicated combination can cause an incorrect operation of the equipment. Illustration 3-1 APR-VET Console SEDECAL WARNING: THIS X-RAY UNIT MAY BE DANGEROUS TO PATIENT AND OPERATOR UNLESS SAFE EXPOSURE FACTORS AND OPERATING INSTRUCTIONS ARE OBSERVED. TO BE USED BY AUTHORIZED PERSONNEL ONLY. - Page 20 High Frequency Generators - Veterinary Systems APR-VET Operation USE THE EQUIPMENT HAND-GRIPS TO CONTROL AND DRIVE THE UNIT MOVEMENTS, NEVER PUSH DIRECTLY ON THE X-RAY TUBE OR COLLIMATOR. MONITOR THE SYSTEM MOVEMENTS WITH SPECIAL CARE. AVOID ANY IMPACT OF THE SYSTEM ON FLOOR, CEILING OR OTHER ELEMENTS IN THE ROOM.
-
Page 21: Radiography And General Controls
High Frequency Generators - Veterinary Systems APR-VET Operation RADIOGRAPHY AND GENERAL CONTROLS The Radiographic module consists of: Power On / Off, Bucky / No Bucky selection, displays and controls of radiographic parameters, Focal Spot, Status and Error indicators. 3.1.1 POWER ON / OFF ON: The Generator is turned ON by pressing this push-button. -
Page 22: Focal Spot Indicators
High Frequency Generators - Veterinary Systems APR-VET Operation 3.1.3 FOCAL SPOT INDICATORS LARGE FOCAL SPOT: Indicates that the “Large Focal Spot” of the X-ray Tube has been selected. SMALL FOCAL SPOT: Indicates that the “Small Focal Spot” of the X-ray Tube has been selected. -
Page 23: Self Diagnostic Indicators
High Frequency Generators - Veterinary Systems APR-VET Operation 3.1.5 SELF DIAGNOSTIC INDICATORS ERROR INDICATOR: Lights when a malfunction is detected in the system, alerting the operator that one of the following error exists preventing X-ray exposures. This error indicators are shown in the APR Display or as an Error code on the kVp Display. -
Page 24: Radiographic Parameters
High Frequency Generators - Veterinary Systems APR-VET Operation 3.1.6 RADIOGRAPHIC PARAMETERS kV DISPLAY can show: The radiographic kV value selected for the technique. • The actual X-ray Tube heat unit value after pressing the “On” push-button • (Refer to Section 3.5). The error messages during a system fault, preceded by the letter “E”... - Page 25 High Frequency Generators - Veterinary Systems APR-VET Operation INCREASE / DECREASE: Radiographic technique values are increased or decreased by pressing the respective push-buttons. The values increase or decrease step-by-step each time the corresponding push-button is pressed, and changes faster when either of them is pressed continuously. kV: Selects the X-ray Tube voltage.
-
Page 26: Automatic Exposure Control (Aec)
High Frequency Generators - Veterinary Systems APR-VET Operation AUTOMATIC EXPOSURE CONTROL (AEC) Automatic Exposure Control (AEC) produces consistent film density with excellent contrast regardless of the radiographic technique selected. The AEC module comprises the controls for the selection of the Exposure Detector Fields (Ion Chamber), the Film/Screen Combination, Film Density Compensation and AEC Reset. -
Page 27: Anatomical Programmer (Apr)
High Frequency Generators - Veterinary Systems APR-VET Operation AEC RESET: If the exposure is aborted by the AEC back-up timer, the indicator on the “AEC Reset” push-button blinks accompanied of an audible alarm. Next exposure is inhibited until the AEC function is reset by pressing the “AEC Reset” push-button. - Page 28 High Frequency Generators - Veterinary Systems APR-VET Operation THICKNESS INCREASE / DECREASE: These push-buttons are used to decrease (B) or increase (D) the Thickness in centimeters of the area to be exposed, in order to adjust the kVp value of the APR technique according to the patient size.
- Page 29 High Frequency Generators - Veterinary Systems APR-VET Operation APR TECHNIQUE SELECTION (Refer to Illustration 3-2) When the APR mode is activated, the APR Display shows the Body Regions: Skull (1), Abdomen (2), Pelvis (3), Thorax (4), Extremity (5), Spine (6), Exotics (7) or Dental (8). After selecting a Body Region, the APR Display shows the selected Body Region and the four Thickness ranges (push-buttons 2, 3, 6 and 7).
- Page 30 High Frequency Generators - Veterinary Systems APR-VET Operation APR TECHNIQUE CHANGES The APR techniques are factory pre-programmed to standard technique sets. All the parameters and selections of the APR techniques can be modified by the operator and stored in the non-volatile memory for later use. If the operator determines that some factors in an APR technique should be re-programmed, use the following procedure: Select an APR technique (Body Region and Thickness).
- Page 31 High Frequency Generators - Veterinary Systems APR-VET Operation Each Thickness Range of a Body Regions has its own slope of the kVp line. When it is required to move all the line, change and store both APR techniques at maximum and minimum thickness in the selected range.
-
Page 32: Exposure Controls
High Frequency Generators - Veterinary Systems APR-VET Operation EXPOSURE CONTROLS Radiographic exposures are initiated with the Handswitch or with the Footswitch. The status of the exposure is indicated by the “Ready” and “X-ray On” indicators for the duration of the exposure. The X-ray Handswitch as well as the Footswitch have three positions: “OFF”, “Preparation”... -
Page 33: Heat Units
High Frequency Generators - Veterinary Systems APR-VET Operation HEAT UNITS This X-ray Generator is equipped with a Heat Unit Calculator. During exposures, the Heat Units are calculated and totalled. To view the remaining Heat Units, press the “On” push-button. The kVp Display shows the percentage of Heat Units that remain preceded by the letter “H”. - Page 34 High Frequency Generators - Veterinary Systems APR-VET Operation Table 3-1 Error Codes ERROR DESCRIPTION WHAT TO DO System failure. This indication may appear together with an -- -- -- -- -- -- Turn the Generator OFF and ON. error on the Console, and indicates that the error is not on Display If the equipment remains inoperative, turn it OFF and call Field Service.
- Page 35 High Frequency Generators - Veterinary Systems APR-VET Operation Table 3-1 (cont.) Error Codes ERROR DESCRIPTION WHAT TO DO Press the “AEC Reset” push-button. Battery Fault. The batteries charge level is momentarily Wait 5 minutes before making a new exposure. low, or some batteries are discharged or damaged. (Only in If the error code persists, turn the Generator OFF and ON.
-
Page 36: Brakes
High Frequency Generators - Veterinary Systems APR-VET Operation BRAKES 3.8.1 BRAKES OF THE TUBE-COLLIMATOR SUPPORT FOR SLIDING COLUMN Three push-buttons located at the Control Console are used to release the brakes of the Tube-Collimator Support Assembly for Sliding Column. HORIZONTAL: Hold down the Console push-button at the left side below the handle to release the brake of the Column Base and allow horizontal motion of the Tube-Collimator Assembly. -
Page 37: Brakes Of The Fixed Radiographic Table With Floating Table-Top
High Frequency Generators - Veterinary Systems APR-VET Operation 3.8.3 BRAKES OF THE FIXED RADIOGRAPHIC TABLE WITH FLOATING TABLE-TOP Applicable to systems with Fixed Radiographic Table with Floating Table-Top. When the system is working, the Bucky or Cassette Tray and Table-Top are locked at any position by means of the electromagnetic brakes. - Page 38 High Frequency Generators - Veterinary Systems APR-VET Operation This page intentionally left blank. OM-0118R0...
-
Page 39: Operating Sequences
High Frequency Generators - Veterinary Systems APR-VET Operation SECTION 4 OPERATING SEQUENCES START-UP ROUTINE System power is applied by pressing the “Power On” push-button on the Control Console. The Generator will go through a start-up routine conducting an automatic self-test that will show on the RAD kVp Display information usable only by service personnel. -
Page 40: Radiographic Operation
High Frequency Generators - Veterinary Systems APR-VET Operation Perform X-ray Tube warm-up as follows: Close the collimator blades fully. • Select 70 kVp, 100 mAs, 200 mA and 500 ms exposure. • Insure that no one will be exposed. • Make a total of three exposures, 15 seconds apart. -
Page 41: Aec Operation
High Frequency Generators - Veterinary Systems APR-VET Operation AEC OPERATION The proper use of AEC requires accurate patient positioning. For examination using AEC, the operator will need to select the desired AEC parameters as follows: Make sure that the X-ray Tube to be used is properly warmed-up. Position the patient for the examination. -
Page 42: Apr Operation
High Frequency Generators - Veterinary Systems APR-VET Operation APR OPERATION An examination using an APR technique with reference to the Thickness of the Body Region could consist of the following: Make sure that the X-ray Tube to be used is properly warmed-up. Position the patient for the examination. -
Page 43: Periodic Maintenance
High Frequency Generators - Veterinary Systems APR-VET Operation SECTION 5 PERIODIC MAINTENANCE In order to assure continued safe performance of the X-ray Unit, a periodic maintenance program must be established. It is the owner’s responsibility to supply or arrange for this service. There are two levels of maintenance, the first consists of tasks which are performed by the user/operator, and the second are those tasks to be performed by qualified X-ray service personnel. -
Page 44: Service Tasks
High Frequency Generators - Veterinary Systems APR-VET Operation SERVICE TASKS Only service personnel specifically trained on this medical X-ray equipment should work on service tasks or maintenance of the equipment. (Refer to “Maintenance” document.) OM-0118R0... -
Page 45: Technical Specifications
High Frequency Generators - Veterinary Systems APR-VET Operation SECTION 6 TECHNICAL SPECIFICATIONS FACTORS GENERATOR MODEL FACTORS FACTORS 16 kW 20 kW 32 kW Maximum mA 200 mA 320 mA 400 mA Maximum kVp 125 kVp 125 kVp 125 kVp Maximum Power kW 16 kW 20 kW 32 kW... -
Page 46: Physical Characteristics
High Frequency Generators - Veterinary Systems APR-VET Operation PHYSICAL CHARACTERISTICS DIMENSIONS COMPONENT COMPONENT WEIGHT WEIGHT Length Width Height Compact Generator Cabinet 445 mm 360 mm 568 mm 72 kg with Power Module and HV Transformer Compact-ESM Generator Cabinet Power Module, HV Transformer, 813 mm 436 mm 948 mm... - Page 47 Fabricado por: Manufactured by: SEDECAL Sociedad Española de Electromedicina y Calidad S.A. Pelaya, 9. Pol. Ind. Río de Janeiro. Algete - 28110 Madrid - España (Spain) Phone: +34 916 280 544 Fax: +34 902 190 385 www.sedecal.com...
