INSTALLATION, OPERATION AND
MAINTENANCE MANUAL
Electro-Pneumatic Positioner
for Rotary Actuators
GENEBRE Ref: 5951 00 – 5951 04 – 5951 06
GENEBRE S.A.
UPDATE DATE: 27/05/2021
UPDATE NUMBER: 4
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Genebre 5951 00
Summary of Contents for Genebre 5951 00
- Page 1 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es INSTALLATION, OPERATION AND MAINTENANCE MANUAL Electro-Pneumatic Positioner for Rotary Actuators GENEBRE Ref: 5951 00 – 5951 04 – 5951 06 GENEBRE S.A. UPDATE DATE: 27/05/2021 UPDATE NUMBER: 4...
-
Page 2: Table Of Contents
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS 1. Product Description......................3 2. Data and Technical Features ..................3 3. Security Instructions ....................... 4 4. Transport and Storage Conditions ................. 5 5. -
Page 3: Product Description
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 1. Product Description. The electro-pneumatic positioner is used for rotating operation of valves with pneumatic actuators by means of an electric controller or a control system with an analogical output signal of 4 –... -
Page 4: Security Instructions
3. Security Instructions The goal of this manual is to allow users with technical skills to install, turn on, operate and inspect Genebre’s electro-pneumatic positioners. Qualified personnel must be familiar with all notices and warnings described in these instructions. Not complying with these notices and warnings may cause serious personal injury and material damages. -
Page 5: Transport And Storage Conditions
That data can be found in the data plate. • Should there be any deviation or non-conformance, please contact Genebre, S.A. Make sure the supply air to be used is Dry, Clean and Filtered, since bad quality supply air may seriously damage the positioner. -
Page 6: Mounting Of The Cam
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es • The positioner’s support is designed to be mounted on actuators with a shaft height of H=20 or H=30, as well as fixing holes at 80 mm or 130 mm according to Namur regulations. -
Page 7: Air Connection
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es • Fix the cam using the upper nut so that the reference line “0” is tangent to the bearing. • Once the cam is mounted, place and fix the indicator plate to the main shaft using the M3 screw so that the reference lines for the cam and the indicator match up. -
Page 8: Electrical Connection (Transmission Signal)
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 1. Use a regulator with a filter to constantly maintain the supply air pressure (optimum supply pressure of 6 bar to operate the actuator). -
Page 9: Exploded View
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es For the Output wiring instruction art. 5951 06 you should consult the technical data sheet of the limit switch box art. 5987. 7. Breakdown view 8. -
Page 10: Span Setting
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es • In the case of the single effect actuator, check that it is set to zero point at standard pressure. Otherwise, repeat Zero Setting. -
Page 11: Seat Adjustment
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 8.4 Seat Adjustment Attention: This adjustment is done in the factory so it is not necessary to readjust later. ATTENTION! This adjustment must only be performed by qualified technicians. -
Page 12: Transmitter Regulation (Article 5951 04 Only)
• Perform the same operation on both air outputs (OUT 1 and OUT 2). • Replace the pilot valve. If the oscillation persists after performing this operation, please contact Genebre S.A. 8.6 Transmitter regulation (article 5951 04 only) If necessary, the transmission settings should be set so that the output signal settings match the settings of the signal sent (4 / 20 mA). -
Page 13: Maintenance
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 8.6.4 Feedback signal 25% (8 mA) position adjusting The valve locate in feedback 25% (8 mA) position. Press the “+” button or “-“button , adjust the current value, then press the “enter”... -
Page 14: Cleaning The A / M Switch
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 10. Cleaning the A / M Switch Whenever the positioner does not respond correctly to the input signals, proceed as described below: • Turn off any air or power supply.
