- Do not send DALI data in idle mode
Address: 893
- DMX HOLD
Address: 894
- GOTO ON
Address: 895
- GOTO OFF
Address: 896
- ARC LEVEL*
Address: 897
- OFF COMMAND*
Address: 898
- Set maximum DALI adress or group number
Address: 804-864 Tens and Ones represent the number of DALI addresses supported
Dimensions:
Power supply:
DALI OUT:
DALI Devices:
DMX IN:
DMX channels:
Mounting:
IP rating:
Temperature range: 0...50C
Humidity:
Order code:
If a trouble-free operation cannot be guaranteed, disconnect the interface and secure it against un-
wanted operation. This is especially necessary, when
- the unit has visible damages;
- the unit does not operate;
- internal parts are loose;
- connection cables show visible damages.
DALI Data are output only when DMX data contents change.
The last setting is retained at loss of DMX signal.
At data loss, all outputs go to 100% intensity
At data loss, all outputs to to the „off" state
„off" (0% intensity) will be sent as ARC LEVEL command
„off" (0% intensity) will be sent as „OFF" command
(min. value 4, max. value 16, default value: 4)
804: set to enable 4 address mode
805: set to enable 5 address mode
etc
864: set to enable 64 address mode
NOTE: Pls note that converting more than 4 adresses simultaneously
may cause significant delays due to the limited DALI bus speed.
65 mm x 105 mm x 65 mm
230V AC
optically isolated, potential.free, polarity independent
4-16 Addresses, single adressing or group addressing
according to USITT DMX512 / DIN56930-2 / ANSI E1-11 compatible
4...64 (8...128)
DIN rail 35mm
IP 20
non-condensing
7044B-H

TECHNICAL DATA

DISTURBANCES
