DMX soundlight 7044B-H Operating Manual page 2

Thank you for choosing a SOUNDLIGHT device.
The SOUNDLIGHT DMX DALI Decoder 7044B-H is a intelligent DMX decoder complying with
DMX data formats conforming to USITT DMX512/1990, DIN 56930-2 and ANSI E1-11 DMX512-A.
The interface converts DMX to DALI control data. The interface can be used with all standard light
control systems. Its special advantages include:
- universal protocol decoding
Recognizes all variants of the protocol as defined by USITT / PLASA / DIN
- future-proof
The unit is software controlled an can easily be adapted to any change in protocol
definition.
- DALI bus compatible
The 7044B-H is compatible to DALI bus systems.
- simple supply
The power supply is from standard mains voltage 230V AC
- signal loss
In the case of a loss of the drive signal a pre-definable action will be taken.
- cost-effective
The SOUNDLIGHT 7044B-H is a cost-effective solution for many purposes.
The decoder 7044B-H is intended for control applications, where DALI units must be controlled
from DMX using a standard DALI bus topology. Please note that we are also offering decoders for
„DirectDALI" control, which allow individual DALI responder control in real-time.
This manual uses symbols to indicate special attention.:
DANGER!
INFO:
INFO:
Non-compliance may cause system or device failure, damage
or personal injuries
How to setup the device
Status Information
PREFACE
APPLICATIONS
Symbols
