- Page 1 User manual Bongartz GmbH - purway Crystal Group® | Damaschkestr. 10 | 28307 Bremen | Telephone: +49 (0)4721 - 66 30 50 | E-Mail: info@purway.de...
-
Page 2: Table Of Contents
Dear Customer, Thank you for purchasing the PUR Booster 5 stages direct flow reserve osmosis water purifier produced by purway Crystal Group©. The reverse osmosis system in your possession is one of the most efficient and practical water treatment systems currently available on the market. -
Page 3: Safety Instruction
Safety instruction Do not make any changes to Do not cover the device! the device! Do not exceed the maximum Do not load the system with water inlet pressure of 4 bar! heavy objects! Do not contaminate the Do not use the device near system with caustic or sources of fire! corrosive materials! -
Page 4: Introduction To The Main Functions Of The Reverse Osmosis System
Introduction to the main functions of the reverse osmosis system MPa 0…1,6 Inlet solenoid valves psi 0…220 Wastewater solenoid valves Stage 1: PP10 „Melt blown“ filter: 10 µm filtering sediments as rust, sand, dust etc. Stage 2: GC10 Granular activated carbon filter: Filtration of chlorine, org. -
Page 5: Technical Specifications
Technical specifications Voltage U 230V AC 50 Hz/60 Hz - 24V DC Rated power P 240 W Rated power standby P < 1W Recommended water supply pressure p 1 – 4 bar Eintr Operating pressure p 8 bar ± 0,5 bar Betr Water temperature ϑ... -
Page 6: Scope Of Delivery
Scope of delivery • 1x Reverse osmosis system PUR SMART 800 Pro including pre-installed filter levels. • 1x Operation manual PUR SMART 800 Pro • 1x RO-membrane model 3013-800 • 1x Wastewater clamp for 1/4“tube • 1x 3-way inlet valve with washer 1/2"... - Page 7 2. Use of quick-change adapters Assembly Release Remove the blue safety Remove the blue safety clip. clip. Push the front ring Push the t over a towards the connector constriction (seal) into the with your thumb and index connector (approx. 8mm). finger.
- Page 8 4. Installation of the water supply Ball valve Connection faucet Screw nut Washer 3-way inlet valve Ball valve Washer Inlet water valve 4.1 Shut off the water supply. 4.2 Release the flex tube of your faucet in the cold water and screw the 3-way inlet valve to the water pipe. 4.3 Ensure a correct fit of the washers.
- Page 9 6. Installation of the faucet 6.1 Mark the place where you want to mount your osmosis faucet. 6.2 Use a drilling machine to drill a 12 mm diameter hole through the sink or worktop. 6.3 Guide the base and the white rubber seal over the threaded rod and place the fitting in the hole in the worktop or sink.
- Page 10 8. Installation aquastop leak sensor An aquastop leak sensor with two separate tablets is included in the scope of delivery for further protection against leaks. A tablet is placed in the holder and floats up as soon as it meets water. This opens the flap and immediately cuts off the water supply to the system.
-
Page 11: Initial Start-Up
Initial start-up Please make sure that the faucet of the reverse osmosis system is closed when the system is started up for the first time, so that the system can perform an automatic flush after plugging in the power switch. This ensures that any possible coal dust from the prefilters will be flushed out and does not reach the membrane! Usage hint... -
Page 12: Filter Change
Filter change 1. Installation SMART change prefilters: Before you start changing the filter, disconnect the water supply to your RO unit and pull the 230 V power plug out of the socket! When the system is empty and depressurized, the filter bowls can be opened more easily. -
Page 13: Troubleshooting
Troubleshooting Error Reason Solution The device cannot be Device is not connected to the power. Check the power supply. switched on. power supply defective. Contact customer service. Blown fuse in the computer control. Replace the computer controller. The pump works Inlet water solenoid valve is defective, Replace the solenoid valve. - Page 14 Directive 2016/35 / EC. Only for use in closed rooms Bongartz GmbH - purway Crystal Group® | Damaschkestr. 10 | 28307 Bremen | Telephone: +49 (0)4721 - 66 30 50 | E-Mail: info@purway.de...
