Page 1: Table Of Contents
Manual ENG PUR Smart 600 GPD 5 Stage Direct Flow Reverse Osmosis System NOTE: Please read these Instructions carefully before using the device. In the event of improper treatment, this can lead to serious dysfunction and damage to the device!
Page 2: Safety Precautions Page 1
Do not place heavy objects on Make sure the water pressure is the device, this can damage the not too high, this could damage components inside and lead to the water feeding tube. A dysfunction. recommended input water pressure is between 1 and 4 BAR. Don't leave the device near fire Don't let the device come into sources.
Page 3: Electric Diagram
Connect the device Always pull out the exclusively to a power power plug when supply with max. 220V installing or repairing to avoid overheating the device to avoid an the device. electric shock. Don't damage the plug Do not touch the or power cable to avoid power plug with electric shocks and...
Page 4: Main Functions Of The Reverse Osmosis System
Introduction to the main functions of the reverse osmosis system: 1. Stage 1: PP10 „melt blown“ filter for filtering sediments as rust, sand, dust etc. 2. Stage 2: GC10 activated carbon granules filter for filtration of chlorine, org. substances, taste and odour impairments, oils, flavors, etc.
Page 5 NOTE: To open the tube fast connections, press the small safety ring inside. Hold it down and pull out the tube. To assemble, place the tube into the clutch as deep as possible and secure it by lightly pulling out the tube, thus activating the safety ring.
Page 6 c) Installation of the faucet Drill a 12mm hole through the sink where you want to install the faucet. Take the included faucet, connect the neck to the faucet (picture 7), slide the faucet into the designated borehole, place a base disc on it from below and fasten the faucet with the nut.
Page 7 e) Installation of reverse osmosis membrane Loosen the tube from the inlet water connection of the membrane shell. Use the membrane key to screw open the lid of the membrane shell. Remove the membrane from the packaging and press the end with the O-Ring first into the membrane shell (picture 9).
Page 8: Computer Control
COMPUTER CONTROL After connecting the device to the socket, POWER lights up and an automatic flush is carried out (FLUSH lights up). For a manual flush, please press WASHING. After reaching the required work pressure, FULL lights up and the pump is switched off. If the device is in operation for too long, OVERHAUL lights up and the device switches off.
Page 9: Disclaimer
4. Open the water tap and check if pure water is coming out. If not, check that the water pressure if it is maybe too low. 5. Wait for the device to start working. Close the inlet water ball valve and check to see if the device turns off.
Page 10: Filter Change
Under normal circumstances, you should make a filter change in the following cases: - poor water quality, taste changes, the TDS value of the water increases - the water flow slows noticeingly (check in advance if the filters or membranes are blocked or if there has been a strong drop in temperature.) - when the filters are clogged and no more pure water is produced Filter change:...
Page 11: Error Diagnosis Page 11+12
ATTENTION: If any of the situations occur as listed below, please disconnect the device immediately from the water supply (close the inlet water ball valve) or peel off the power cable and do a repair: - when water leaks from the water pipes or other components - if some of the elements are not working correctly - if some components carry electricity - if you detect other anomalies or errors on the device...
Page 12: Customer Service
Type of disorder Reason for malfunction Troubleshooting High-pressure switch can no longer Replace the high-pressure switch be switched on This device is filled with water (standby mode) and starts again After checking the check valve, and again This device loses water pressure please check the device for possibly leaks Pre-filter is blocked...
Page 13: Notes On The Electrical And Electronic Equipment Act (Elektrog)
Information obligations to private households in accordance with § 18 ElektroG (1) According to § 17 ElektroG, we are obliged under the conditions specified therein to withdraw electrical and electronic waste equipment free of charge. We comply with this legal obligation via the internet portal interseroh.de.
