Wall Mounting

Some CRAFTSMAN chargers are designed to be wall
mountable or to sit upright on a table or work surface. If wall
mounting, locate the charger within reach of an electrical
outlet, and away from a corner or other obstructions which
may impede air flow. Use the back of the charger as a
template for the location of the mounting screws on the wall.
Mount the charger securely using drywall screws (purchased
separately) at least 1" (25.4 mm) long, with a screw head
diameter of 0.28–0.35" (7–9 mm), screwed into wood to an
optimal depth leaving approximately 7/32" (5.5 mm) of the
screw exposed. Align the slots on the back of the charger
with the exposed screws and fully engage them in the slots.
nOTE: Do not attempt to mount CMCB101 charger under a
bench or table.
nOTE: Only mount CMCB101 charger with the charging
lights pointed upward toward the ceiling.
VersaTrack™

WARNING: Do not charge batteries while charger is
hung on Trackwall.
CRAFTSMAN chargers, except the CMCB101, can
be stored on CRAFTSMAN VersaTrack™ Trackwall.
Hooks and accessories are sold separately. Please
refer to the VersaTrack™ Trackwall accessory sheet for
further information.
nOTE: The CMCB101 charger is not CRAFTSMAN
VersaTrack™ Trackwall compatible.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can cause injury.
Installing a Bit or Accessory into a Keyless
Chuck (Fig. E)

WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changing acces sories.

WARNING: Always ensure the bit is secure before
starting the tool. A loose bit may eject from tool
causing possible personal injury.
To insert a drill bit or other accessory, follow these steps.
1. Turn tool off and remove battery pack.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desired accessory.
3. Insert the accessory about 3/4" (19 mm) into the
6
chuck and tighten securely by grasping and rotating
8
11
the chuck sleeve
holding the tool with the other. When the chuck is nearly
tightened you will hear a clicking sound. After 5-7 clicks
the chuck is securely tightened around the accessory.
Your tool is equipped with an automatic spindle lock
mechanism. This allows you to open and close the chuck
with one hand.
Be sure to tighten chuck with one hand on the chuck sleeve
and one hand holding the tool for maximum tightness.
To release the accessory, repeat steps 1 and 2 above.
Speed Selection (Fig. A)
The tool features two speed settings for greater versatility.
nOTE: Do not change speeds when the tool is running.
Always allow the tool to come to a complete stop before
changing speed.
1. To select speed 1 (higher torque setting), slide the speed
4
selector forward (towards from the chuck).
2. To select speed 2 (lower torque setting), slide the speed
selector back (away the chuck).
If the tool does not change speeds, confirm that the speed
selection switch is completely engaged in the forward or
back position.
Mode Selection (Fig. A)
The mode selection collar
the correct operating mode depending upon the
planned application.
To select, rotate the collar until the desired symbol aligns
with the arrow.

WARNING: When the mode selection collar is in
the drill or hammerdrill positions, the drill will not
clutch. The drill may stall if overloaded, causing a
sudden twist.
symbol
1-15
Screwdriving (higher number = greater torque)

OPERATION


WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can cause injury.

Installing and Removing the Battery Pack

(Fig. F)

WARNING: Ensure the tool/appliance is in the off
position before inserting the battery pack.
nOTE: For best results, make sure your battery pack is
fully charged.
To install the battery pack
battery pack with the rails inside the tool's handle and slide
it into the handle until the battery pack is firmly seated in the
tool and ensure that it does not disengage.
clockwise with one hand while
3
can be used to select
Mode
Drilling
Hammerdrilling
8
into the tool handle, align the
