Installation

Installation Procedures
1. First complete the electrical connections and then check for correctness.
2. Disconnect the battery negative terminal of vehicle before beginning
installation.
3. Remove 2 transport CD deck screws before use.
Installation Opening
This unit can be installed in any dashboard Having an opening as shown
below.
Insert mounting collar into the dashboard and bend the mounting
tabs out with a screwdriver.
Make sure that lock lever is flush with the mounting collar( not
projecting outward)
HEX NUT
SPRING WASHER
PLAIN WASHER
TAPPING SCREW
7.20 inch
.
DASH BOARD
METAL MOUNTING STRAP
2.05 inch
CONSOLE
MOUNTING SLEEVE
HEX BOLT
Bracket key
Plastic trim out
Befor using, please
remove 2 transit
screws.
Bracket key
