Summary of Contents for Boss Audio Systems 609UAB
-
Page 2: Table Of Contents
CONTENTS Precautions..............................1 ..........................1 Lithium Battery Cell Warnings Use Caution s ............................1 Installation ..............................2 Installation Procedures .......................... 2 Installation Opening..........................2 Wiring Connections ..........................3 Uninstall the Main Unit ........................... 3 Overview of the Components ........................4 General Operation ............................4 Turn Unit on/off ............................ -
Page 3: Precautions
PRECAUTIONS Lithium Battery Cell Warnings • Cell leakage may cause damage to the remote control. • Do not throw cells into as this may cause an explosion. • Keep battery cells out of reach of children. Use cautions • • Some MP3/WMA files may not be playable. -
Page 4: Installation
INSTALLATION Installation Procedures First complete the electrical connections and then check for correctness. Installation Opening This unit can be installed in any dashboard Having an opening as shown below. 2.05 inches 7.20 inches Insert mounting collar into the dashboard and bend the mounting tabs out with a screwdriver. -
Page 5: Wiring Connections
INSTALLATION(CONT.) Connect all wiring harness and slide the head unit into the mounting collar until it clicks into place. Wiring Connections Radio Antenna White: Front Left PRE-AMP Output Red: Front Right PRE-AMP Output Red: Rear Right PRE-AMP Output ACC + (Red) GND - (Black) White: Rear Left PRE-AMP Output ANT + (Blue) -
Page 6: Overview Of The Components
Overview of the Components MUTE - OFF(power On/Off) / SRC (source) button 2. VOL (volume) knob and SEL (select/menu) button 3. Hands-free Microphone 4. LCD Display 5. Reset button 6. USB Port 7. BAND button (tune/ seek up, next track, fast forward) button (automatic store / preset station scan, automatic music search) button 10. -
Page 7: Adjust Menu Options (Sel)
General Operation Adjust Menu Options (SEL) • Press SEL button repeatedly to cycle through the following adjustable audio functions: - ILL MID/HI/LOW: This receiver is equipped with 3 brightness settings. - BASS/TREBLE:-7, -6, ~, 1, 0, +1,~, +6, +7 Note: BASS and TREBLE settings are only enabled when EQ setting is turned OFF. - BALANCE:L7, L6,~, L1, L=R, R1,~,R6, R7 - FADER:R7, R6, ~, R1, 0, F1, ~ ,F6, F7 - EQ(Equalizer) Setting: OFF, CLASS, ROCK, POP, FLAT... -
Page 8: Radio Operation
Radio Operation Switch Between USA area and Europe area Frequency In radio mode, press the SEL button to enter the switch state of the US (USA) and EU(europe)frequency, then rotate it to switch between US(USA) and EU(europe) frequency. The system will change the frequency setting in about 3 seconds. -
Page 9: Usb Operation
USB Operation Play MP3/WMA music inside a USB stick. Insert the USB stick with MP3/WMA musics into the USB port, it will play automatically.Note: the USB port also supports charging mobile phone, the maximumcharging ability is 5V / 1A. Select Next Track or Previous Track In the USB mode, briefly press the button to play the the next or previou track. -
Page 10: Auxiliarly Operation
To begin pairing, enable BT mode on your mobile phone. 2. When the phone finds the car audio system, the “BOSS AUDIO 609UAB” name will be displayed. 3. Choose the “BOSS AUDIO 609UAB” from the device list to pair and connect with the car audio system. -
Page 11: Switch Audio Between Car Audio And Mobile Phone
Bluetooth Operation Switch Audio Between Car Audio and mobile Phone During a call, press the VOL knob/button to switch the audio source from the car audio system back to your mobile phone. Adjust Call Volume During a call, use VOL knob to adjust the call volume level. Audio Streaming (A2DP) The unit supports A2DP (advanced audio distribution profile) wireless streaming audio from your Bluetooth mobile device directly to your head unit. -
Page 12: Remote Control
Remote Control (Power on/off) button 2. VOL+/VOL-(volume increase/decrease) button 3. Band button, (answer call) button 4. PREV: tune down, seek down; Track down, fast reverse 5. SEL(selection) button 6. NEXT: tune up, seek up; Track up, fast forward 7. Mute button, DEL(Delete) button 8. -
Page 13: Specifications
Specifications General Power supply Requirement : DC 12V Maximum power output : 50W X 4CH Speaker impedance : 4 - 8 Ohm Unit Dimensions(WxHxD) : 7.0 X 2.0 X 2.76 inches Weight : 1.04 lbs Fuse : 10 A RADIO Frequency Range: 87.5 MHz - 107.9 MHz (USA) 87.5 MHz - 108.0MHz (EUROPE)
