MX10C, MX40C Series of Optical Transmitters

1.4 Front and Back Panel Overview

A
E
Callout
A
B
C
D
E
F
G
H
J
K
L
Rev. F, February 21, 2020
B
F G
Figure 2
Description
Touchscreen Display
Adjustment Knob
Key Switch and Indicator
Lasing Disabled; Lasing
Enabled
Grounding Jack (Banana
Connector)
Earth Ground
Laser Output
Laser Input
Optical Output
Amplifier RF Output
Modulator RF Input
Amplifier RF Input
Standby Button
H
Front Panel
MX10C Series MX40C Series
-
-
-
Banana
PM FC/PC
PM FC/PC
FC/PC
SMA
SMA
SMA
-
Chapter 1: Introduction
C
D
L
K
J
-
-
-
Banana
PM FC/PC
PM FC/PC
FC/PC
Not Available
Not Available
2.92 mm
-
