MX10C, MX40C Series of Optical Transmitters

5.2 Power and Environmental Specifications

Parameter
Main AC Voltage
Power Consumption
Line Frequency
Operating Temperature
Storage Temperature
Humidity

5.3 Internal Control Specifications

Parameter
Power Monitors Accuracy
Power Monitors Resolution
Power Monitor Insertion Loss
VOA Insertion Loss
VOA Response Time

5.4 Internal Amplifier Specifications

Parameter
Rise/Fall Time
RF Amplifier Gain
Small Signal
Bandwidth
RF Amplifier Max Output Swing
Low Frequency Cutoff
Electrical Return Loss

5.5 Internal Modulator Specifications

Parameter
Electro-Optic
Bandwidth
RF Drive Voltage
(V )
pi
Insertion Loss
Rev. F, February 21, 2020
MX10C Series
MX40C Series
MX10C Series
MX40C Series
MX10C Series
MX40C Series
MX10C Series
MX40C Series
MX10C Series
MX40C Series
MX10C Series
MX40C Series
Min
100 VAC
-
50 Hz
10 °C
0 °C
5% RH
Typical
±0.5 dBm
0.01 dBm
0.1 dB Typical
0.4 dB Typical
1 s
Typical Values
35 ps
8 ps
34 dB
30 dB
7 GHz
20 GHz
3 V – 7 V
100 kHz
-10 dB
Typical Values
10 GHz
35 GHz
4.5 V
pp
7 V
pp
3.5 dB (1550 nm)
5.5 dB (1310 nm)
4.0 dB (1550 nm)
6.0 dB (1310 nm)
Chapter 5: Specifications
Max
250 VAC
60 VA
60 Hz
40 °C
50 °C
85% RH
Notes
Each Monitor, At Calibrated
Wavelength
Each Monitors
Per Monitor
-
-
Notes
Large Signal, Digital Response
-
Linear, Analog Response
Adjustable Swing
-
Any RF Port (to -3 dB BW)
Notes
(-3 dB)
At 1 GHz
-
