MX10C, MX40C Series of Optical Transmitters

4.6 Menu Page

To get to this page tap the blue Menu button on the Home page. The Menu page has links to several pages that allow the user
to control the display, sounds, lights, and get help information. The following sections describe these functions in more detail.

4.6.1 Display and Sound Settings Page

To open the screen shown below, tap the DISPLAY AND SOUNDS button on the Menu pane.
DISPLAY BRIGHTNESS controls the overall brightness of the touch-screen display
DISPLAY SLEEP TIME controls how long the touch-screen display is visible before it sleeps
BUTTON CLICK toggles the sound produced when tapping buttons (On/Off)
NOTIFICATION BEEP toggles the sound associated with certain on screen notifications (On/Off)
Rev. F, February 21, 2020
Figure 30 Controls on the Menu Page
Figure 31 Display and Sound Settings Page
Chapter 4: Operating Instructions
Tap here to control the
touch-screen and the
sounds it makes.
Tap here to find system info.
Tap here to control the accent
LEDs producing the light
emanating from the bottom of the
instrument.
Tap here to find help from
Thorlabs Technical Support.
Tap any of the fields to access
the respective controls.
