Power Brush PB60 06 Assembly/Operators/Parts Manual English Language Version 06 Printed: September 2006 READ & SAVE THIS MANUAL QUADIVATOR INC. 1000 6th Ave. NE Portage La Prairie, MB Canada, R1N 3C5 www.quadivator.com Part #: 89754A...
Page 2
3. Limitations - the warranty applies only to products which have been properly assembled, adjusted and operated in accordance with the instructions contained within this manual. The warranty does not apply to any product of Quadivator Inc. that has been subject to alteration, misuse, abuse, improper assembly or installation, shipping damage or normal wear of the product.
Power Brush. At the time of printing, this may result in some of the minor parts in the manual becoming outdated. Quadivator will have the most up to date parts and service information – call 866 770-2169 for service information and parts orders! Contact Information Quadivator Inc.
Start the Quadivator Power Brush and allow it to run for 5 – 10 minutes, check for excessive operation or unusual noise. The Quadivator Power Brush has been tested and to the best of my knowledge, is ready to be delivered to the customer! Date Pre-delivered –...
Quad Power Brush SAFE OPERATION Failure to observe the following safety instructions DANGER could result in serious injury and or GHDWK 1. GENERAL OPERATION 2. GENERAL DEVICE OPERATION .1 Read the operating and service instruction manual .1 Do not put hands or feet near or under rotating parts. carefully.
Quad Power Brush 3. SET-UP & OPERATION -ii- ANGLE ADJUSTMENT -i- BRUSH MOUNTING *Refer to the Power Unit operator’s manual for Manual instructions on assembly of the Power Unit. Remove Pivot stop pin (shown in Fig 3-2) and manually adjust angle by rotating brush to desired angle and 1.
Quad Power Brush WHEN IN USE: Attach the clip end of the Tether Cord 4. For a longer lasting brush; take note of the to your belt, until you dismount the ATV. The switch the following: cord is attached to: will shut off the engine if pulled deliberately or by inadvertently dismounting from the a) More pressure does not produce a better sweep ATV seat.
Page 10
Quad Power Brush NOTE: Bristles must be replaced all at once or 7. Servicing the roller chain that drives the rotor: uneven sweeping will occur. The longer bristles a. To replace the roller chain, remove the bolts will wear off faster. that hold the springs on the idler.
The following pages contain parts following information on hand: illustrations and replacement part numbers for all components for the Quadivator Power Part Number you are looking for. Brush. At the time of printing, some of the Model Number and Serial Number minor parts in the manual may become of the machine.
Page 12
Quad Power Brush Shields and Sub Assemblies Rotor Sub Assembly - See pages 10, 11 Rear SubAssembly - See Pages 8 & 9 Front Sub Assembly - See pages 12 & 13 Operators Manual - Version 06...
Page 13
Quad Power Brush ITEM PART DESCRIPTION Spacer - Bushing 88540 Idler Pulley - 3" 88574 UNMW - Flange Bearing 88579 Spring, Extension - Tensioner Arm 88651 Weld't -Pulley 4.5" 'B' x 24 Bore 89075B Spacer - Pulley 89529 89550 Gearbox, Worm - 10:1 RatiO W.A.
Page 14
Quad Power Brush Gearbox Assembly * Refer to page 16 for parts breakdown of the gearbox. Operators Manual - Version 06...
Page 15
Quad Power Brush ITEM PART DESCRIPTION 14618 Brg Unit-Prssd Stl Hsng SBPFL205-16 88540 Spacer - Bushing 88574 Idler Pulley - 3" 88579 UNMW - Flange Bearing 88651 Spring, Extension - Tensioner Arm 89702 Shim, Power Brush Arm 70924280 Pop Rivet, Aluminum 1/8 Dia x .390 Long 89075B Weld't -Pulley 4.5"...
Page 16
Quad Power Brush Brush Assembly View from Rear - Some components hidden for clarity. View from Front Some components hidden for clarity. DETAIL A SCALE 2 : 15 Operators Manual - Version 06...
Page 17
Quad Power Brush ITEM PART DESCRIPTION 14618 Brg Unit-Prssd Stl Hsng SBPFL205-16 88540 Spacer - Bushing 88574 Idler Pulley - 3" 88579 UNMW - Flange Bearing 88651 Spring, Extension - Tensioner Arm 89702 Shim, Power Brush Arm 70924280 Pop Rivet, Aluminum 1/8 Dia x .390 Long 89075B Weld't -Pulley 4.5"...
Page 18
Quad Power Brush Brush Rotor Sub Assembly ITEM QTY. PART DESCRIPTION 89710 Wafer, Blue Poly Conv. 88669 Sprocket - 44 Tooth x 50 Pitch 89517 89720 Weld't -Brush Rotor 89771 Chain Guide-Circular 89793 Plate - Retainer, Waffle Shim Spacer -Chain 89833 Weld't -Spacer Ring 89845...
Page 20
Quad Power Brush Long Interframe Assembly 89450-06 To Power Unit Engine Pulley To Power Brush Pulley ITEM 450-06Manual/QTY. PART DESCRIPTION Bushing -Oilite 12.7ID x 16OD x 9.4 Long 19-5-91 Ratchet Strap -05500 1 x 6 86803 88403 Washer - Retainer Spacer - Bushing 88545 88645...
Page 21
PART DESCRIPTION Decal - Warning (Keep Hands and Feet Away 88590 Decal, Warning-Keep Hands Clear 88599 Decal-Quadivator Corp-1.75 x 8.5" 88665 88666 Decal - Serial Plate Foil (1 5/8 x 3.00") Decal - Mylar Overlay, Frosted 88667 Decal, Warning - General...
Page 22
Quad Power Brush Operators Manual - Version 06...
Quad Power Brush WARRANTY REGISTRATION – Quadivator PB60 Power Brush Please fax this sheet to (204) 239-4271 or mail it to: Quadivator Inc. P.O. Box 1127 1000 – 6 Ave NE Portage la Prairie Manitoba, R1N 3C5 CANADA Power Brush Model # -...
Page 24
Quad Power Brush _____________________________________________________________________ Operators Manual – Version 06...
Page 25
Quad Power Brush 86348 Electrical Pivot Option - Installation ITEM QTY. PART DESCRIPTION 86031 Actuator, 4" Stroke, HD, 12VDC 17:1 86348 Instructions, Power Brush Elect Pivot Kit 89906 Bracket - Actuator Base 89915 Weld't -Actuator Rod End 89921 Bracket -Lift Extension 89930 Assy - Brush Pivot Switch CB.25x3/4...
Page 26
Quad Power Brush 86348 Installation - Electrical Pivot 3. Remove the lift pin from existing mount location 1. Loosen clamping bolts on actuator trunnion by removing 1/4 x 1-1/4 bolts and nuts. mount. Make sure both bolts are loose. 4. Remove center carriage bolt from the top of the shroud.
Page 27
Quad Power Brush 86348 Wiring Instructions The following instructions apply to units having a cargo box. Use the guidelines when installing the wiring harness to your unit. 1. Using a tape measure, measure down 2-1/2 inches (63.5mm) from the top left corner inside the front of the cargo box.
Page 28
Quad Power Brush 86348 The following wiring instructions apply to units having no cargo box. Use as a guideline when installing the wiring harness. 1. Remove the battery cover. Disconnect the battery cables making sure to disconnect the negative cable first.
