- Page 1 Hand Control Programming-TDH27P 20210727 User Manual Hand Control Programming- TDH27P Version 1 July 2021 1 of 12...
-
Page 2: Table Of Contents
Hand Control Programming-TDH27P Contents Contents ..................................2 Disclaimer .................................. 3 1. User Interface Guide ............................. 4 2. Reset ..................................5 3. Adjusting the Height ............................. 6 4. Setting the Memorized Position ........................... 6 5. Setting the Upper and Lower Height Limit ......................7 6. -
Page 3: Disclaimer
Hand Control Programming-TDH27P Disclaimer This user manual is ONLY for generic TiMOTION products. Manufacturers may have altered product settings causing them to differ from this user manual. Please contact the manufacturer for a revised manual if the product settings are different than this manual. -
Page 4: User Interface Guide
Hand Control Programming-TDH27P 1. User Interface Guide Up and down buttons Safety lock button 3-digit height display Memory setting buttons Version 1 July 2021 4 of 12... -
Page 5: Reset
Hand Control Programming-TDH27P 2. Reset Simultaneously press for 3 seconds. Continue pressing the buttons until both columns are in the lowest position. When finished with the reset, the control box will make a “beep” sound, and the buttons can be released. -
Page 6: Adjusting The Height
Press button until the desk reaches the preferred height. 4. Setting the Memorized Position TDH27P supports a maximum of 2 memory positions. How to memorize a position: Adjust the desk to the desired height. Press the preferred memory button (1 or 2), with either for 2 seconds. -
Page 7: Setting The Upper And Lower Height Limit
Hand Control Programming-TDH27P 5. Setting the Upper and Lower Height Limit Setting the upper height limit: (1) Adjust the desk to the preferred upper height limit. (2) Press buttons together for less than 3 seconds, holding and release button. (Note 2) (3) Re-press for more than 3 times at a slow pace. -
Page 8: Presetting The Desk Starting Height
Hand Control Programming-TDH27P 6. Presetting the Desk Starting Height (1) Press button until the desk reaches its lowest position and then release button. Re-press button again for 5 seconds, and the digital display will flash for 10 seconds. (2) Adjust the starting height number with the button. -
Page 9: Switching Metric And Imperial Unit
Hand Control Programming-TDH27P 8. Switching Metric and Imperial Unit (1) Press memory buttons 1, 2 and, Lock for 5 seconds. (2) The digital display will show “C-I.” If no further instruction is input within 5 seconds, the system reverts to normal operation mode. -
Page 10: Adjusting Built-In T-Touch Or Tcs1 Sensitivity
Hand Control Programming-TDH27P 9. Adjusting built-in T-touch or TCS1 sensitivity Press memory buttons 1 & 2 for 5 seconds; the display will show the current sensitivity level (0~9) by flashing. (Note 4) Press the button to adjust the sensitivity level. If no button is pressed within 5 seconds, the system will resume normal operation mode. -
Page 11: Error Codes
Hand Control Programming-TDH27P 11. Error Codes The digital display shows the error codes below to suggest the issues that users may encounter during the operation. (Note 5) Error code Descriptions Resetting Not reset completely Overuse protection Unbalance protection Anti-collision T-touch Protection... -
Page 12: Power Saving Function - Waking Up The Control
Hand Control Programming-TDH27P 12. Power Saving Function - Waking Up the Control The digital display automatically turns off if no buttons are pressed within 25 seconds. Press any button to light up the display again. The system goes into <0.1W standby mode if no buttons are pressed within 30 seconds.
