TERMINAL CONNECTIONS

Connect the unit as in the diagram below or refer to the connection diagram on the top of the unit.
■ EXTERNAL DIMENSIONS unit: mm (inch)
50 (1.97)
■ CONNECTION DIAGRAM
+ 3
INPUT 1
– 4
+ 5
INPUT 2
–
6
MODULAR JACK
PU-2x
Input Connection Examples
■ Open Collector or
Mechanical Contact
+ 3
–
4
–
+ 5
–
6
–
■ Voltage Pulse
+ 3
–
4
–
+ 5
–
6
–
107 (4.21)
127 (5)
1 +
OUTPUT
2 –
7
U(+)
POWER
8
V(–)
■ 2-Wire Current Pulse
• External DC Supply
100Ω
– 3
2-WIRE
+
PICK-UP
4
DC SUPPLY
+
–
100Ω
–
5
2-WIRE
+
PICK-UP
6
DC SUPPLY
+
–
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
CLAMP
(top & bottom)
DIN RAIL
35mm wide
2–4.5 (.18) dia.
MTG HOLE
15 (.59) deep
8–M3.5
SCREW
[3.3 (.13)]
• When mounting, no extra space is needed between units.
Output Connection Examples
■ Open Collector
1 + +
2 – –
■
Noncontact AC/DC Switch
• AC Powered
Relay or
1
Counter Coil
Varistor or Spark
2
LOAD
Quenching Circuit
U
• DC Powered
Relay or
1
Counter Coil
Spark Quenching
2 Diode
LOAD
■ RS-422 Line Driver Pulse
+
1
+ +
2 –
– –
JPS3
7.8 (.31)
6 5 4 3
7 8 1 2
40 (1.57)
50 (1.97)
■ Voltage Pulse
1 + +
2 – –
EM-1575 Rev.4 P. 2 / 5
