- Page 1 Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Three-Phase Perfection Premium Series Voltage Regulator User´s Manual 1 - Rev – 1 Version 10.0 to 100.0 kVA CM COMANDOS LINEARES - 1/38 -...
-
Page 2: Table Of Contents
Positioning ________________________________________________________________ 9 Composition ______________________________________________________________ 10 Electrical Connections – typical installation sketches ______________________________ 10 * For other voltages, please, consult CM Comandos Lineares´ Applications Engineering Department. Placement of Internal Components __________________________________ 11 Cable Terminal Block _______________________________________________________ 13 IT Model Connection Label __________________________________________________ 14... -
Page 3: Security Regulations
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Terms of Warranty _________________________________________________________ 35 Warning! This manual contains instructions on Receipt, Handling, Storage, Installation, Placement, Initial Activation and Operation of the Perfection Premium Series Voltage Regulator. Read this manual carefully before performing the installation procedures, which should be carried out by trained personnel. -
Page 4: Receipt
3. Check for evidences of humidity in the package due to rain or contact with other liquids. In case of any problem, get in contact with CM together with the carrier. Determine, upon receipt, the Refusal of Acceptance or Receipt With Reservations. -
Page 5: Refusal Of The Material
User´s Manual The caveat characterizes the partial receipt for the cases of small proportion damage. CM will send a technician to perform the repair in loco on the carrier´s cost. Important: the refusal or caveat is the only way to lay responsibility on the carrier for the quality of transportation services. -
Page 6: Handling
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Handling We recommend the correct handling through compatible equipment with its dimension and weight. The package is fit for use with trans-pallet carts, or hoisted through a Munk type truck with the aid of suitable belts, or with the use of trucks fitted with a lifting platform. -
Page 7: Storage
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Detail of pallet removal with Munk type truck hydraulic gear. Storage By proceeding correctly with the Receipt step, make sure the equipment is stored in a safe place, sheltered, and away from humidity. -
Page 8: Installation
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Installation Preparation – Choice of local and environment setting The Premium Perfection Series Voltage Regulator is strongly built and may function under diverse conditions, however, the choice of the installation place will influence very much on the life of the components and frequency of maintenance. -
Page 9: Positioning
The connecting terminals from the voltage regulator input and outlet cables are located in the frontal lower part. Consider a height of 30 cm between the floor and the connecting terminals, besides the needed gap of 2.0 to 4.0 meters for the whip as from the recommended above. -
Page 10: Composition
Other items for the installation of the system are up to the client, since they depend on variable factors according to the demands of the project. All information contained in this manual are enough for most installation cases. CM Command Lineares´ Applications Engineering Department is available to the users for any clarification and suggestions. -
Page 11: For Other Voltages, Please, Consult Cm Comandos Lineares´ Applications Engineering
Consider the input neutral conductor in the versions: Perfection Premium Series - TA Perfection Premium Series - T Perfection Premium Series - IT(with 380V input voltage)* * For other voltages, please, consult CM Comandos Lineares´ Applications Engineering Department. CM COMANDOS LINEARES - 11/38 -... - Page 12 Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Placement of Internal Components Front Panel The images are merely illustrative. The place of some components may vary without previous notice, depending on the model and configuration of the voltage regulator.
-
Page 13: Cable Terminal Block
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Cable Terminal Block The input and output cable connection terminals are placed in the frontal part of the voltage regulator. The terminal block has numbered identification with respective input and output connection inscription. -
Page 14: It Model Connection Label
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual IT Model Connection Label 220V input Ground 380V input Neutral MAINS Ground Mod: 001A Terminal Label IT TERMINAL LABEL R1 - INPUT PHASE R Warning ! S1 - INPUT PHASE S... -
Page 15: Cable Connections
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Cable Connections Prior to connecting the cables, it is always important to verify the input voltage available and the desired output voltage, matching the specific values on the voltage regulator identification label. -
Page 16: Initial Activation
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Initial activation Connect the input circuit breaker on the Power Board, energizing the voltage regulator input. With a multimeter, measure the voltage on the voltage regulator input terminals, checking for the presence of voltage of the three phases in relation to the Neutral and Ground, as well as between the phases. - Page 17 Switch the manual bypass key to the Off position. The panel will display the message Press Enter to Start. Press the Enter button. The screen will display the initialization messages according to the above mentioned. Wait for the message Normal Operation – CM Comandos Lineares. CM COMANDOS LINEARES...
-
Page 18: Functional Check
These values are indicated on the panel by the power indications in Watts and VA. In case of doubt about the total consumption of the critical load, consult CM Comandos Lineares´ Applications Engineering Department. Failure Reset or Alarm, with Connected Load. -
Page 19: Functioning Theory
Mains through an innovative IGTS converter technology, controlled by DSP chip, a unique system in the world market developed by CM Comandos Lineares, which also includes the registration of a Log of Events that keeps 25,500 records, allowing for Operation History Traceability. -
Page 20: Stabilization Principle
Three-Phase Perfection Premium Series User´s Manual The electronic voltage regulators were developed by CM to meet the most sophisticated and demanding consumers. The main characteristic is to withstand great load variations – 0 to 100% - in extremely short periods of time – in the millisecond order, keeping the output absolutely stable, within 1%. -
Page 21: Panel Messages And Measurements
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Panel Messages and Measurements The Perfection Premium Series Voltage regulator has a liquid crystal display which, through messages and measurements, informs the voltage regulator´s operational condition, enabling commands which the operator may need to run by simply pressing the button on the panel according to the needs, or simply by verifying the measurements and status, such as voltage, frequency, consumed power, etc. -
Page 22: Serial Number
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Firmware Version STCC 1000 UPGS 3100 Indication of the firmware version of the control boards and panel. Serial Number 70000 Serial Number Indication. Sound Alarm Beep ON Sound alarm indication - ON/OFF, to alter, press the Enter button. -
Page 23: Alarm Description
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Alarm Description Gate Driver Error Triggered Bypass Error in the inverter module or rectifier (continuous sound alarm). Transfers to bypass – does not shutoff the output. Internal Alarm Under Network Voltage High voltage in the network, however, within the 25% nominal voltage range (beeps 2 times per second), maintains the output on. - Page 24 Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Triggered Bypass KVA Surge Output surge in KVA (beeps 2 times per second). Transfers to bypass – does not shut down the output. Triggered Bypass KW Surge Output surge in KW (beeps 2 times per second). Transfers to bypass – does not shut down the output.
-
Page 25: Under And Over Voltage Protection
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Output OFF Network Sinking Micro cut in the input voltage (3 beeps per second). Shuts down the output. Output OFF Output Sinking Micro cut in the output voltage (3 beeps per second). Shuts down the output. -
Page 26: System With Automatic Reset
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual System with Automatic Reset The system with automatic reset allows the reestablishment of the load under normal operation in the cases of shutting down due to failure from the concessionaire, causing the voltage regulator to automatically turn itself on after the retake of the electric power, not being necessary any intervention from the operator. -
Page 27: Technical Specifications
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Technical Specifications Model Perfection Premium Series 10,000 to 100,000 Power 10 kVA to 100 kVA (other powers by consultation) Voltage 380/220VITStandard Models (other voltages by consultation) Configuration Three-phase (3 phases + ground) or (3 phases + neutral + ground) N. - Page 28 Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Model Perfection Premium Series 10,000 to 100,000 Output Overload Electric sensors Input Overload Magnetothermal circuit breaker Under voltage Electronic sensors Protection Over voltage Electronic sensors Repositioning Operation Automatic reset system Manual: bypass – voltage regulator Bypass key C –...
-
Page 29: Physical Dimension Table
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Physical Dimension Table IT Models – Isolated Three-Phase Weight Module Equipment Height mm Width mm Depth mm Amount TI 10000 TI 15000 TI 20000 TI 30000 1,100 TI 40000 1,300 TI 50000... -
Page 30: T Models - Three-Phase Without Input Transformer
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual T Models – Three-phase without input transformer Weight Module Equipment Height mm Width mm Depth mm Amount T 10000 T 15000 T 20000 T 30000 T 40000 T 50000 T 75000... -
Page 31: Preventive Maintenance
Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Preventive Maintenance The voltage regulator must be kept within temperature and relative humidity operational limits in order to reach maximum life of internal components (see Technical Specifications in this Manual). Cleaning around the voltage regulator and checking the operation of the internal fans is recommended every 3 months of continuous operation of 24/7 type. -
Page 32: First Aid
Check if the circuit breaker that feeds the voltage triggered regulator is of the same type as the one described in the Circuit Breaker Table, specified by the CM Linear Command Engineering Department. Check the circuit breaker from the Distribution –... - Page 33 Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Previous Presented Procedures to verify Situation Anomaly 1. Check if the input voltage is not outside the specified values (nominal +/ – 16%). 2. Check in the panel(s) that feed the voltage...
-
Page 34: Corrective Maintenance
Accredited Network CM Comandos Lineares has a team of qualified technicians in the Greater São Paulo area, and accredited technical representatives throughout the country, apt to readily give technical support to CM Comandos Lineares´ Equipment, covered or not by warranty. - Page 35 Three-Phase Perfection Premium Series User´s Manual Terms of Warranty CM Comandos Lineares ensures the functioning of the equipment for a period of 12 months, starting on the issuing of the Purchase DANFE (Electronic Invoice Auxiliary Document) by the first owner.
- Page 36 This commitment is limited solely to repairs and replacement of faulty components. The bad functioning or stoppage of the equipment or system, under no circumstances, shall burden CM Comandos Lineares with occasional loss or damage to the proprietor or users, limiting the responsibility to the manufacturer to the terms exposed herein.
- Page 37 Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Identification Label MANUFACTURE DATE: CM COMANDOS LINEARES - 37/38 -...
- Page 38 Microprocessed Voltage Regulator Three-Phase Perfection Premium Series User´s Manual Av. Eng. Alberto de Zagottis, 760 04675-085 - São Paulo – SP, BRAZIL www.cmcomandos.com.br General PABX +55 (11) 5696-5000 +55 (11) 5696-5055 cm@cmcomandos.com.br Applications Engineering Phone: +55 (11) 5696-5012 +55 (11) 5696-5022 aplicacoes@cmcomandos.com.br...
