Summary of Contents for unGer HYDRO POWER RO20S
- Page 1 Operating Instructions READ THE OPERATING INSTRUCTIONS BEFORE TURNING ON THE SYSTEM! KEEP OPERATING INSTRUCTIONS WITH THE MACHINE AT ALL TIMES! (RO20S) OPERATING INSTRUCTIONS www.ungerglobal.com 22842 V1.0 1121...
-
Page 2: Table Of Contents
HydroPower® RO Table of Contents Introduction ........................ 4 General information ..................... 4 Product lifetime guarantee .................. 4 Safety Information ...................... 4 Safety alert symbols and signal words ..............5 Warning signs ...................... 6 Mandatory signs ....................7 General safety information .................. 8 2.4.1 Basic principles ................... - Page 3 HydroPower® RO Table of Contents Preparing for use ....................... 16 Construction of the HydroPower RO ..............16 Interfaces ......................16 Transport and storage ..................17 4.3.1 Transportation .................... 17 4.3.2 Operating the HydroPower RO ..............18 Startup ......................... 19 4.4.1 Starting up a HydroPower RO ..............
-
Page 4: Introduction
Please refer to the Unger website (www.ungerglobal.com) for the Safety Data Sheet (SDS) information. Product Lifetime Guarantee We design and test Unger products to ensure they meet our high quality standards. We support this with the Unger Professional Product Lifetime Guarantee. We will replace your Unger HydroPower RO System if it does not meet our high quality standards for material, construction, or workmanship. -
Page 5: Safety Information
HydroPower® RO Safety Information Safety Information Safety alert symbols and signal words Your safety and the safety of others are very important. We have provided important safety messages in this manual and on the HydroPower RO. Always read and obey all safety messages. These instructions are not meant to cover every possible condition and situation that may occur. -
Page 6: Warning Signs
HydroPower® RO Safety Information Warning signs Warning of a hazard. Warning of electrical voltage. Warning of overpressure in containers. Warning of hot surfaces. Warning of suspended loads. Warning of injury to the limbs. Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ www.ungerglobal.com... -
Page 7: Mandatory Signs
HydroPower® RO Safety Information Mandatory signs Application tips and other useful information. Use protective gloves. Use safety shoes. Use protective goggles. Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ www.ungerglobal.com... -
Page 8: General Safety Information
HydroPower® RO Safety Information General safety information 2.4.1 Basic principles Special safety information may apply to certain activities. Safety instructions and warnings are given in the respective sections of the operating instructions. Operate the HydroPower RO only: • In accordance with the operating instructions •... -
Page 9: Mechanical Hazards
Before each use, perform a visual inspection of the power cable for damage. If you notice any damage, contact your distributor. Maintenance on the electrical components of the system may only be carried out by employees of Unger or its authorized distributors / technicians. 2.7 Thermal hazards Burns due to hot surfaces. -
Page 10: Hazards From Materials And Substances
HydroPower® RO Safety Information 2.9 Hazards from materials and substances The safety data sheets for materials and substances can be found online at www.ungerglobal.com/service/downloads/safety-data-sheet. Irritation to the eyes, skin and respiratory tract. Resin can cause irritation to the eyes, skin and resiratory tract. Avoid any contact with the resin when replacing the DI resin cartridge. -
Page 11: General Hazards
HydroPower® RO Safety Information 2.10 General hazards Read and follow ANSI Standard IWCA 1-14.1 (Window Cleaning Safety). Purified water is delivered to the waterfed pole by hoses from the HydroPower Ultra system. This introduces a risk of tripping to both the operator and the general public. Identify work area with appropriate signage. Any surface that becomes wet must be identified with appropriate signage to direct pedestrians and workers away from work area. -
Page 12: Responsibilities Of The Operator
HydroPower® RO Safety Information 2.11 Responsibilities of the operator The HydroPower RO is for commercial use only. • The operator must be familiar with and observe all applicable workplace rules and regulations, including all accident prevention procedures. • The operator must be familiar with and strictly adhere to all applicable local, state/provincial and federal labor laws, safety codes and standards. -
Page 13: Storing The Operating Instructions
2.13 Contact Address Unger Enterprises LLC 425 Asylum Street Bridgeport, CT 06610 United States Tel.: (1) 800.431.2324 Fax: (1) 800.367.1988 unger@ungerglobal.com... -
Page 14: About Hydropower Ro
HydroPower® RO General safety regulations About the HydroPower RO Using the HydroPower RO 3.1.1 Intended use The HydroPower RO is used for the filtration of municipal water by demineralization for the purpose of glass and surface cleaning. The HydroPower RO is intended for commercial use only. The HydroPower RO may only be connected to municipal water lines. -
Page 15: Pressure Ratings
HydroPower® RO General safety regulations 3.2.4 Pressure ratings Input pressure [PSI] 14-87 PSI Max. operating pressure [bar] 3.2.5 Dimensions quick overview Height [in/mm] 37.8 / 960 Width [in/mm] 20.9 / 530 Depth [in/mm] 26.4 / 670 Empty weight [lb/kg] 99 lb / 45 kg 3.2.6 Media connections Standard feedwater connection thread [”] Standard concentrate connection thread [”]... -
Page 16: Preparing For Use
HydroPower® RO System overview Preparing for use Construction of the HydroPower RO Manometer 2 2 3 3 TDS-Meter Switch WORK/RO FLUSH Switch TAP BOOST / OFF / PURE Water inlet Water outlet Water meter Carbon/sediment combi pre-filter RO Membrane 10 DI resin filter 11 Pump ventilation slots 12 Pump Control 13 Power cord (GFCI) -
Page 17: Transport And Storage
HydroPower® RO Transport and storage 4.3 Transport and storage 4.3.1 Transport The HydroPower RO is delivered on a pallet. Check the completeness of the delivery, see section ”3.4 System products & accessories”. The HydroPower RO is carefully tested and packaged before shipment. However, damage during transport cannot be ruled out. -
Page 18: Operating The Hydropower Ro
HydroPower® RO Operating the HydroPower RO 4.3.2 Operating the HydroPower RO Water inlet Carbon/sediment combi pre-filter RO membrane DI resin filter Water outlet What is Pure Water? Pure Water is water in its purest form, physically processed to remove the minerals that would otherwise lead to limescale spots and streaks. -
Page 19: Startup
HydroPower® RO Startup 4.4 Startup CAUTION Minor or moderate injuries due to pressurized containers possible. The three (3) filter housings are pressurized during operation. Never open a housing or remove a hose during operation. Check if the hoses and tubes are water-tight and fit properly before starting up the system. -
Page 20: Starting Up A Hydropower Ro
HydroPower® RO Startup 4.4.1 Starting up a HydroPower RO: The pre-filter and the resin filter are not inserted in new or used units, as they must not come into contact with the membrane care liquid. Before using the resin filter, the membrane care liquid must be completely rinsed out. 1. -
Page 21: Operation Of The Hydropower Ro
HydroPower® RO Operation Operation of the HydroPower RO General information The operating instructions must be read and understood before operating the HydroPower RO. DANGER Severe injuries or death and property damage due to the HydroPower RO falling are possible. Place the unit on a level surface only. Make sure the unit is standing securely. -
Page 22: Cleaning Surfaces With The Hydropower Ro
HydroPower® RO Operation 5.2 Cleaning surfaces with the HydroPower RO The HydroPower RO has two water out modes: PURE and TAP BOOST. PURE: This mode is used for spotless cleaning of windows and facades and gives out up to 150l/h (39 gal./h) of pure water with 58 PSI (4 bar) (at 18°C [64°F] water temperature with a 12.5mm [1/2”] hose). -
Page 23: Turning Off The Hydropower Ro
HydroPower® RO Operation/Troubleshooting 5.4 Turning off the HydroPower RO To switch off the HydroPower RO after finishing the work, proceed as follows: 1. For a longer service life, the membrane should be flushed for approximately five (5) minutes after work. To do this, set the upper rotary switch to “RO FLUSH”... -
Page 24: Overheating
HydroPower® RO Troubleshooting 6.1.3 Overheating Always ensure that the HydroPower RO is well ventilated and is not too close to objects or walls which could prevent proper air circulation. 1. If the pump motor overheats, the HydroPower RO will automatically stop. 2. -
Page 25: Maintenance And Servicing
General information DANGER Electric shock possible through live parts. Maintenance of the electrical components of the system should only be carried out by employees of Unger or authorized distributors / technicians. CAUTION Burns due to hot surfaces possible. The housing of the pump motor can become hot during operation. -
Page 26: Maintenance And Maintenance Plan
”7.2.3 Membrane protection.” If the membrane is not regularly flushed or protected with the UNGER membrane care liquid, there is a risk of blockage and thus a strong reduction in the unit‘s performance or damage to the unit. -
Page 27: Membrane Protection
If the HydroPower RO is not in use for an extended period of time (longer than 7 days), the membrane must be protected against mineral deposits. For this purpose, there is the UNGER Membrane Care Fluid. You need one bottle (1l) to treat the membrane. This preserves the current state of the membrane and prevents reduced performance and/or damage after non-use. -
Page 28: Repair And Replacement Of Parts
HydroPower® RO Replacing filter cartridges 7.3 Repair and replacement of parts Additional information on replacement parts can be found on the Unger website (www.ungerglobal.com). For all other repairs, please contact your distributor. 7.3.1 Replacing filter cartridges CAUTION Irritation to the eyes, skin and respiratory tract possible. - Page 29 HydroPower® RO Replacing filter cartridges Changing the RO Membrane Place the unit on its back Unscrew the two screws on front and remove the bottom black plastic cover. Remove the remaining two screws on the bottom plate and remove the plate.
-
Page 30: Turning Off The System
Disassembly and storage DANGER Electric shock and burns due to live parts possible. Maintenance the electrical components of the system may only be carried out by employees of Unger or authorized distributors / technicians. CAUTION Burns due to hot surfaces possible. -
Page 31: Recycling
ATTENTION Material damage to the unit due to improper storage. Keep the system clean from dirt buildup. Use only membrane care products from Unger. Never store the HydroPower RO below 5°C (41°F). NOTE When storing the HydroPower RO for an extended period of time (e.g. - Page 32 HydroPower® RO At Unger, we aim to stand apart from the rest thanks to our special “Yes We Can!” service spirit. We love what we do and as proof of that, we promise to deliver a 100% Customer Satisfaction Guarantee on every product and service we offer.
