airbox
sampling products
Specifications:-
Flow Range VARIFLOW: Adjustable 5 -17 l/min (with 0.8 micron cellulose filter)
Flow Range VARIFLOW 8: Adjustable 5 -10 l/min (with 0.8 micron cellulose filter)
Flow Stability: +/- 3%
Battery Pack: (1x) 12 Volt (8.5 amp min) Lead Acid
Charge Time: 6 - 8 Hours Max
Continuous Duration VARIFLOW: 3+ Hours @ 16 l/min, 8+ Hours @ 8 l/min
(with 0.8 micron cellulose filter)
Continuous Duration VARIFLOW 8 : 8+ Hours @ 8 l/min (with 0.8 micron
cellulose filter)
Display: OLED, elapsed run time and battery indicator
Material: HF ABS
Waterproof: To IP65
CE Marked: Yes
Dimensions: H38cm x W24cm x D12cm
Mast extends to: Up to 2.0 metres
Warranty Registration
Don't forget to register your new Airbox product by filling in the
registration form provided and returning it to us at the address below.
Alternatively you can do this online at:
Technical support
For all technical support or customer service enquiries
please contact us:
telephone:
+44(0)1903 524 600
email:
sales@airboxsp.com
web:
www.airboxsp.com
Airbox Sampling Products , Technology Centre,
Easting Close, Worthing, West Sussex BN14 8HQ
www.airboxsp.com
airbox
sampling products
thank you for choosing this Airbox product
Find us online at
www.airboxsp.com
User Manual
VARIFLOW/VARIFLOW 8
V1
t:
+44(0)1903 524 600
e:
sales@airboxsp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VARIFLOW and is the answer not in the manual?

Questions and answers

Related Manuals for airbox VARIFLOW

Summary of Contents for airbox VARIFLOW

  • Page 1 Specifications:- Flow Range VARIFLOW: Adjustable 5 -17 l/min (with 0.8 micron cellulose filter) Flow Range VARIFLOW 8: Adjustable 5 -10 l/min (with 0.8 micron cellulose filter) Flow Stability: +/- 3% Battery Pack: (1x) 12 Volt (8.5 amp min) Lead Acid...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Dear Customer 1. Setting up and using the VARIFLOW/VARIFLOW 8........4 Thank you for purchasing this Airbox product. To ensure that you get the best possible use from it, please read this manual carefully. 1.1 Charging the battery......................4 1.2 Running the VARIFLOW/VARIFLOW 8 from the mains.........

  • Page 3: Setting Up And Using The Variflow/Variflow 8

    The VARIFLOW/VARIFLOW 8 1. Setting up and using the VARIFLOW/VARIFLOW 8 pump Before you use the VARIFLOW/VARIFLOW 8 pump make sure it is fully charged. A battery level indicator shows the available power when the unit is first switched on.

  • Page 4: Setting Test Mode

    VARIFLOW Press start/pause the pump runs and the timer starts counting, (you can pause Before switching on the VARIFLOW connect a flow meter to the air sampling head. during the test by pressing start/pause) start/pause Press to switch on the unit. The display will show, in this order, the serial number, stop when the test is complete and the display shows ‘Test Stop? Are you...

  • Page 5: Maintenance

    2. Maintenance 2.3 Cleaning the unit The casing of the VARIFLOW/VARIFLOW 8 pump is made from a hard wearing ABS 2.1 Replacing the battery structural foam, making it incredibly rugged and also very easy to clean. Tested to The VARIFLOW/VARIFLOW 8 pump has been specifically designed to make IP65 standards (‘Protected against low pressure water jets from any direction.

  • Page 6: Servicing & Warranty

    The defect must not have been caused by improper handling or misuse. EU charger) c) Return the unit to us in the decontamination bag provided by Airbox. We will not VARIFLOW Air Sampling Pump (with UK/ assume responsibility for transport damage under any circumstances.
