TIS RCU-24R20Z Installation Manual

INSTALLATION MANUAL
ROOM CONTROL UNIT
20 Inputs 24 Outputs
Model: RCU-24R20Z
Output switching voltage
Output switching current
Input
TIS Bus
Operating and display
elements
Functions
Dimensions
Housing
BARCODE (UPC-A)
6 58921 79822 5
This device is used to control ON/OFF for lights
and other devices, electrical locks, 3
motors, shutters, floor heaters, and it includes 20
Digital Inputs (dry inputs).
P R O D U C T S P E C I F I C AT I O N S
Number of channels
Nominal voltage
Max. switching Voltage
Nominal current per channel
Maximum total channels load
Max switching current
Max Continues current
Number of channels
Input Type
Length of connected wire
Number of devices on 1 line
Bus voltage
Current consumption (Normal)
Current consumption (Peak)
Protection
Programming button/LED (PRG)
2 buttons
Lighting control ON/OFF Dimming
Curtain control
Fan speed control
Scenes
24 Digital inputs
Width × Length × Height
Materials
Casing color
Button color
IP rating
Automation Made Easy

PRODUCT INFORMATION

24
0 – 230 V AC 50/60 Hz
440VAC / 125VDC
Ch 1-12: 10A
Ch 13-24: 5A
180 A / 230
CH 1-12: 16A
Ch 13-24: 6A
Ch 1-12: 10A
Ch 13-24: 5A
20
Digital input. Open / Close
< 350 meter
Max. 64
12-32 V DC
<30 mA / 24 V DC
<40 mA / 24 V DC
Reverse Polarity Protection
For assignment of the physical address
Manually ON/OFF and Programming
24 channels controlled separately
Can set 12 group of curtains (open/close) option
Can set 8 group of Fan (low, med, high) option
12 different scenarios
Programmable inputs to connect to normal wall
switches and sensors
215mm × 75mm × 91mm
ABS fire proof
Black Gray
Silver
IP 20
-party curtain
rd
