TIS -SEC-SM Installation Manual

INSTAllATIoN MANuAl
TIS SecurITy Module
Model: TIS-SEC-SM
Security
TIS Bus
Function
programmable options
Dimensions
Housing
BArcode (uPc-A)
6 58921 79870 6
This Security Module is capable of covering more
than 3000 BUS inputs divided into 8 areas. Arm/
disarm your security system according to different
modes, including vacation, away, day, or night.
It's your call. Equipped with a built-in clock, this
module can also be set to automatically arm/
disarm these modes.
P R O D U C T S P E C I F I C AT I O N S
Levels
Arming commands
Alarm Commands
Extra Alarms
Sirens and buzzer
Number of devices on 1 line
Bus voltage
Current consumption
Protection
Other Functions
Width × length × height
Materials
Casing color
IP rating
Automation Made Easy
ProducT INForMATIoN
Vacation, Away, Night, Day, Disarm
20 for each level
20 for each alarm type
Panic, blackout, freezing temperature,
3 channels addressable. (Burglary, Fire, Buzzer)
Max. 64
12-32 V DC
<30 mA / 24 V DC
Reverse Polarity Protection
Auto Arm/Disarm, Entry/Exit Delay, Dial out Time,
zone auto bypass, Duress Alarm
90mm × 73mm × 76mm
Fire-proof ABS
Black Gray
IP 20
