• Operating Instructions
• Warning Information
• Parts Breakdown
Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities contains chemicals known to
cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how
often you do this type of work. To reduce your exposure to
these chemicals: work in a well ventilated area, and work with
approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
Strokes per Minute . . . . . . . . . . . . . . . . . 9,000
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . 1/4 NPT
Hose Size . . . . . . . . . . . . . . . . . . . . . . . . 3/8 I.D.
Air Pressure . . . . . . . . . . . . . . . . . . . . . . . 90 PSI
Air Consumption . . . . . . . . . . . . . . . . . . 7 CFM
Sound Level . . . . . . . . . . . . . . . . . . . . . .95 dBA
Length . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1/4"
Shipping Weight . . . . . . . . . . . . . . . . 1-1/2 Lbs.
CAT-400AS
SPECIFICATIONS
Copyright © Professional Tool
1
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
WEAR HEARING
PROTECTION
AVOID
PROLONGED
EXPOSURE TO
VIBRATION
CAT-400AS
Air Body Saw
T
Tool
Products, 2005. All rights reserved.
Rev. 12/06/05
Advertisement
Table of Contents
Related Manuals for Cornwell Tools CAT-400AS
Summary of Contents for Cornwell Tools CAT-400AS
- Page 1 Air Consumption ....7 CFM CAT-400AS Sound Level ..... .95 dBA Length .
- Page 2 Always check for damaged, frayed or loose hoses and fittings, and • Use accessories recommended by replace immediately. Do not use Cornwell Tools. quick detach couplings at tool. See instructions for correct set-up. CAT-400AS Rev. 12/06/05...
- Page 3 The foregoing obligation is Cornwell’s sole liability under this or any implied warranty and under no circumstances shall Cornwell be liable for any incidental or consequential damages. Note: Some states do not allow the exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you. CAT-400AS Rev. 12/06/05...
- Page 4 PARTS BREAKDOWN - CAT-400AS Ref.# Item # DESCRIPTION Ref. # Item # DESCRIPTION Qty. RS85831 Air Valve Body RS85801A Piston Assembly RS85832 RS85832 Valve Plug Valve Plug RS85802 Damping Ring RS85803 Gasket Plate RS85833 O-Ring RS85806 Rubber Washer RS85834 RS85834...
