IF PIER WALL HAS BEEN
PURCHASED, ASSEMBLE
THE PIER WALL FIRST.
Position headboard in front
of bridge.
SI VOUS AVEZ
ACHETÉ LES TOURS,
ASSEMBLEZ CECI EN
PREMIER.
Placez la tête de lit
devant le pont.
L'ASSEMBLAGE DU LIT PLATE-FORME
!
Page 1 of 10 • Comp #P2019 • Revision #2 • 02/2013
PLATFORM BED ASSEMBLY
Platform Bed with Pier Wall
Lit Plate-Forme avec Tours
Platform Bed only
Lit Plate-Forme seulement
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DeFehr PLATFORM BED
Summary of Contents for DeFehr PLATFORM BED
- Page 1 ACHETÉ LES TOURS, ASSEMBLEZ CECI EN PREMIER. Placez la tête de lit devant le pont. Platform Bed with Pier Wall Lit Plate-Forme avec Tours Platform Bed only Lit Plate-Forme seulement Page 1 of 10 • Comp #P2019 • Revision #2 • 02/2013...
- Page 2 1. Read all instructions before proceeding. Not following instructions may result in personal harm or damage to your furniture. 2. Depending on model purchased, the unit may not look exactly as shown. 3. Two people are required for safe assembly of the unit. 4.
-
Page 3: Tools Required
Tools required: Outils requis: Hardware: Quincaillerie: X24 - QN X28 - KG 5/8” 1-1/4” 1” #10057 #15825 #15824 #12217 #10056 Bolt/Boulon Screw/Vis #8 1-1/4” Cam/Came Screw/Vis #8 5/8” Screw/Vis #8 1” STEP 1 Place Headboard (AA) in desired location near a wall leaving adequate room between the headboard and wall. - Page 4 STEP 2 1. Position Base-Left (BB) and Base-Right (CC) against Headboard approximately 9.5cm (3-3/4”) in from either side of the headboard. 2. Place Large and Small Supports (DD) between Base units. Adjust positioning as needed so supports fit snugly between bases and the entire assembly is centred on the headboard. 1.
- Page 5 STEP 3 Attach Footboard Panel (EE) to base with Screws (A). Open the drawer to access the screw holes. Fixez le pied de lit (EE) à la base avec les vis 1-1/4” (A). Ouvrez le tiroir pour avoir accés aux trous de vis.
- Page 6 STEP 4 Set the Platform Decks onto the base assembly. Use Platform Deck (FF) for a Queen Bed or Platform Deck (GG) for a King Bed. Leave approximately 1.8cm (3/4”) of space between the headboard and the platform deck. Mettez les plate-formes sur la base. Utilisez la plate-form (FF) pour un lit Queen ou la plate-forme (GG) pour un lit King.
- Page 7 STEP 5 1. Screw Bolt (B) into the holes located in the End Rails (JJ) as shown. 2. Insert Cams (C) into the holes located in the Side Rails (HH) as shown. Ensure that the arrow on the Cam points to the hole for the bolt (see Diagram 1).
- Page 8 STEP 6 X24 - QN TO BE COMPLETED SAFELY, THIS STEP REQUIRES TWO PEOPLE. X28 - KG Lift the rail assembly onto the bed. It will fit over the edges of the platform deck (see Diagram 3). Secure the rail assembly to the deck with two Screws (D) per bracket as shown.
- Page 9 STEP 7 Gently push the Platform/Rail assembly towards the headboard so that it is snug. Using four Screws (A), secure the rail assembly to the headboard as shown. Poussez gentiment l’assemblage vers la tête de lit. Assurez-vous que les 2 pièces soient serrées l’une contre l’autre.
- Page 10 Pour sécuriser la plate-forme à la base, utilisez une Vis (E) dans chaque coin, tel qu’illustré. 1” Suggested Platform Bed set-up. SET-UP BED IN FRONT OF PIER WALL. Assemblage suggéré pour le lit plate-forme. ASSEMBLEZ LE LIT DEVANT LES TOURS.
