Tersano iClean mini Instructions

PREPARATION
IMPORTANT:
Familiarize yourself with
your new iClean mini.
Your iClean mini
kit includes:
Activation button
• iClean mini device
• USB-C charging
cable (wall charger
not included)
• Instruction sheet
• Gift box
CHARGE
RED
Charging takes up to
USB-C Charging Cable
• The charging port is located on the back of the
iClean mini.
• Connect the USB-C charging cable to the device.
• Plug the other end of the charging cable into a
USB outlet or through a USB power charger (not
included) then into a standard electrical outlet.
• A slowly flashing red light on top indicates
charging is taking place.
• Charging is complete when a blue light
on top flashes.
• Unplug the charging cable from the outlet
and disconnect the charger from the iClean.
Note: If iClean mini does not operate when
activation button is pressed, the iClean mini
needs to be recharged. iClean mini will not
operate during the charging process.
EPA Est. No.: 93508-CHN-1
iClean mini Stabilized Aqueous Ozone (SAO
Model LQFC200
Battery 7.4V Li-ion
USB-C Charging Cable Connect to USB outlet/adapter
5VDC, ≥1A
(1 ft/30.48cm)
Dimension 85 x 63 x 230mm
Charging Time Up to 3 hours
FILL
Indicator light
Spray nozzle
Charging port
–
Waterpipe Turn reservoir on base counter-clockwise and
remove from iClean mini.
Water level
window
–
Fill reservoir with cold tap water ONLY.
Water tank
–
Reattach reservoir to iClean mini and turn
clockwise to fasten tightly.
–
Fill with tap water ONLY.
–
Do NOT add chemicals or soap.
–
Do not submerge under water.
3
hours
USE
PREP
–
3 hours.
To prep the pump, press activation button on
front of iClean mini and spray through 2-3 full
reservoirs until you see a steady stream flow.
INDICATORS
–
When activation button is pressed, a
continuous blue light on top indicates iClean mini
is producing Stabilized Aqueous Ozone (SAO
–
A continuous red light on top indicates
reservoir is empty.
CLEAN
–
Press activation button on front of iClean mini
to wet surface to be cleaned.
–
Wipe surface dry with a cotton, microfiber, or
paper textile.
Note: no need to wipe completely dry – residual
water will evaporate without streaking.
PRODUCT DESCRIPTION
® ) Colour
Water Quality
Water Temperature
Net Weight
Tank Capacity
Water Concentration
O
³
Dark blue
Cold clean tap water
4-40°C
300g
150ml
up to 1.7 ppm
www.tersano.com
IMPORTANT SAFETY INSTRUCTIONS.
READ THESE INSTRUCTIONS COMPLETELY.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
SANITIZE
–
Kill germs on virtually all hard surfaces as well as
carpet, fabric, wood, foods and more.
–
Clean surface with the iClean mini.
–
Press button and continuously spray
surface with Stabilized Aqueous Ozone (SAO
–
Wipe surface dry with any clean cloth.
CARE
RECHARGING
–
It is not necessary to drain battery completely
before recharging.
–
ONLY use charger supplied with iClean mini kit.
MAINTENANCE
To maintain consistent performance, follow these
care instructions.
–
When iClean mini has not been used for more
than 5 days, fill reservoir completely, press
activation button, and spray until reservoir is
empty. Then refill reservoir and iClean mini is
ready for use again.
–
Use only attachments and replacement parts
sold or recommended by manufacturer.
–
iClean mini is NOT dishwasher safe.
–
iClean mini is not a toy. Supervision required
when children present.
STORAGE
–
Empty water from reservoir. Contents of reservoir
are safe for drain disposal.
® ).
–
Store upright at room temperature.
–
Do not dispose of device or battery in household
trash. Dispose of properly.
Contact Tersano with questions.
–
Store upright and indoors above 40°.
TROUBLESHOOTING TIP
Make sure to prep the pump by spraying through
2-3 full reservoirs.
WARRANTY
The Limited Warranty is valid for one year from the
date of your purchase of the Product as shown by
the sales receipt. Details on website: tersano.com
Product may vary slightly from illustrations enclosed in this use and care guide.
CAUTION
–
For first time usage, charge for 4 hours
and then spray at least one tank of water
to activate the unit in order to achieve the
normal concentration value of O
–
Do not spray directly into the eyes.
–
Avoid flushing the unit with water.
US and International Patents and Patent Pending.
SAO®, iClean®, and Tersano® are registered trademarks of Tersano Inc.
QUESTIONS OR CONCERNS QUESTIONS OR CONCERNS
Contact Tersano at 800-727-8835 or +1 519 737 7588
with questions or concerns about your iClean mini.
® ).
water.
³
REV. MAY 2021
