INSTRUCTIONS–PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
HVLP Compressor/Carts
240V AC, 50/60 Hz
ProCartt Model 233449, Series A
45 psi (3.1 bar, 310 kPa) Maximum Working Pressure
1
Cart with 2
/
-gallon pressure pot,
2
material hose, and compressor air hose
ProCartt Model 233452, Series A
15 psi (1.0 bar, 104 kPa) Maximum Working Pressure
1
Cart with 2
/
-gallon pressure pot,
2
material hose, compressor air hose
Related Manuals
HVLP Turbine Sprayers
. . . . . . . . . . . . . . . . . . .
HVLP Turbine Gun
. . . . . . . . . . . . . . . . . . . . . . .
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
309243
309205
ECOPYRIGHT 2001, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
309244
First choice when
quality counts.t
Rev. D
TI0822

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProCart 233449 and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco ProCart 233449

  • Page 1 ..... . . 309205 TI0822 GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 ECOPYRIGHT 2001, GRACO INC. Graco Inc. is registered to I.S. EN ISO 9001...
  • Page 2: Table Of Contents

    ..................Graco Phone Number .
  • Page 3 Notes 309244...
  • Page 4: Warnings

    Warnings Know all hazards before operating sprayer! Fire and explosion hazard: Solvent and paint fumes can ignite or explode. D Sprayers generate sparks. Keep sprayer at least 20 feet (6 m) from explosive vapors. DUse in an extremely well ventilated area. DEliminate all ignition sources;...
  • Page 5: Component Identification

    Component Identification Handle/Hose holder Filter Turbine latch Power switch Air Outlet/Check Valve Remote pressure pot Material hose Remote pressure pot holder 309244...
  • Page 6: General Information

    General Information You will need: Cleaning fluids: a compatible solvent; water–based paint also requires soap and water. Suggested proper clothing: • Safety glasses • Sturdy boots or shoes • Respirator • Gloves Power Requirements: • 240V AC 50/60 Hz, 8A circuit with a grounded outlet (models 233430, 233431 and 233433) •...
  • Page 7 General Information PRESSURE RELIEF – Follow this procedure when cleaning, repairing or shuting down sprayer For Cup Guns Turn off turbine. Unlatch cup For Pressure Feed Guns 1. Turn off air supply to the pot. 2. Open pressure relief (A) on 02882A pot until pressure is completely 8069A...
  • Page 8: Setup

    Setup Remote 2 -gallon pressure pot 1. Place remote pressure pot in pressure pot holder on cart. 2. Follow Connect Fluid and Air Supply instructions. Page 10. turbine sprayer (manual 309243) pressure pot 7933A Turbine Sprayer 1. Place turbine sprayer on cart. turbine sprayer 2.
  • Page 9 Setup Storage Position for Cart Handle 1. Turn knob to free handle. 2. Fold handle down to store. knob 7931A 309244...
  • Page 10 Setup Connect Fluid and Air Supply 2. If using spray gun cup (D): Connect cup to gun fluid inlet (E). D The HVLP compressor/cart provides the air supply If using accessory remote pressure pot (F): for remote pressure pots. Connect fluid supply hose (G) between remote D The circled letters (page 11) indicate hose line pressure pot fluid outlet (H) and gun fluid inlet (E).
  • Page 11 Setup cup-over option Manual 309205 spray gun remote pressure pot cup setup for spray gun setup HVLP Compressor/Cart 7934A -gallon remote pressure pot 2-quart remote pressure pot 309244...
  • Page 12 Setup 1. Turn compressor on to warm up a few minutes before you start spraying. power switch Turn compressor off when not used for an extended period of time. The compressor does not shut off auto- matically. 2. Be sure compressor filter (9) is clean before operating. Page 13.
  • Page 13: Maintenance

    Maintenance Daily Check cart daily for cleanliness. WARNING To avoid damage to the compressor and possible Compressor system is lifetime lubricated. The only electric shock, never install a damp filter in the compressor. maintenance required is filter cleaning and replace- ment.
  • Page 14 Maintenance To service the compressor filter 1. Turn turbine and compressor OFF. power switch: compressor turbine 2. Unplug turbine from power source. 309244...
  • Page 15 Maintenance 3. Pinch filter (9) and remove by hand. 4. Clean or replace filter as follows: a. Brush accumulated paint and dirt from surface of foam filter. b. Rinse filter in water with mild detergent. Blow dry. c. Replace filter if paint is caked on. Weekly Check hoses for cracks, leaks, and holes.
  • Page 16: Troubleshooting

    Troubleshooting PROBLEM CAUSE SOLUTION No fluid delivery No material, no remote container Check container for material. pressurization, hose or pickup tube clogged Check for leaks at the container gasket (2-quart pressure pot cover or -gallon pressure pot wing nuts). Tighten wing nuts if loose. Check for air flow from male quick disconnect at compressor outlet (approx.
  • Page 17: Wiring Diagram

    Wiring Diagram CAPACITOR 1 2 3 MOTOR POWER CORD Compressor Wiring Compressor Wiring Model 233452 Model 233449 309244...
  • Page 18: Parts

    Parts Drawing ProCart HVLP Compressor/Carts Model 233449 TI0823a 309244...
  • Page 19 Parts List ProCart HVLP Compressor/Carts Model 233449 Part No. Description Part No. Description 244236 HOUSING ASSY, cart 192802 SPACER, handle 192805 . AXLE, cart 198091 PLATE, cart 191824 . WASHER, space 106084 SCREW, mach, pan hd 113658 . NUT, crest, hat 114421 CONNECTOR, cord strain relief 113647...
  • Page 20 Parts Drawing ProCart HVLP Compressor/Cart Model 233452 Bottom View bottom of cart TI0102A 309244...
  • Page 21 Parts List ProCart HVLP Compressor/Cart Model 233452 Part No. Description Part No. Description 244286 HOUSING ASSY, cart 107262 TERMINAL, insulated, female 276675 . HOUSING, cart 114293 SWITCH, rocker, red 192805 . AXLE, cart 114299 CORD SET, 0.4572 m (18 in.) 191824 .
  • Page 22 Accessories R coated Pot 240045 PTFE -Gallon (9.5 liter) 2-Quart (1.9 liter) Pressure Pot 50 psi (345 kPa, 3.5 bar) Maximum Inlet Air Pressure 50 psi (345 kPa, 3.5 bar) Maximum Inlet Air Pressure 2-quart (1.9 liter) capacity, aluminum cup. -gallon (9.5 liter) capacity, steel tank.
  • Page 23 Accessories Standard Turbine Air Hose Length (ft) Number Fluid Set (FS)/Spray Gun 241413 Number None 244115 244118 Tie Wrap Kit (10 pack) 103473 8483A Material Hose Air & Material Hose Compressor Air Hose Pressure Pot Length (ft) Number Length (ft) Number Length (ft) Number...
  • Page 24: Specifications

    Specifications Power requirement ............240V AC, 50/60 Hz, 1 Amps Power cord (Extension cord must be 3-wire, 12 AWG, 233449 no longer than 100 ft [30 m]...
  • Page 25 Notes 309244...
  • Page 26: Warranty

    Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
