AutoMoto
Motorised Roman Blind Cassette System
Setup & Operating Instructions
Setting up power: Battery Operation
1.1 Unscrew the end cap on the battery wand
at the end without the cable protuding.
1.2 Insert 8 x AA Lithium-ion batteries
in to the battery wand – check
that they are pointing in the
correct direction as shown
on the side of the wand.
IMPORTANT:
Do not mix type/brand or old
batteries with new for replacement batteries.
1.3 Screw back end cap back on and connect the
2-pin cable plug at the other end of the wand into
the plug from the wire protruding out of the blind
headrail (Fig 1). The power is now connected.
™
x 8
AA
TIP: Mount the battery
wand to the wall using
the brackets provided.
Place the rubber band
beside the bracket
to stop it moving.
Fig 1
rca-uk.com
Advertisement
Related Manuals for Renaissance AutoMoto
Summary of Contents for Renaissance AutoMoto
- Page 1 AutoMoto ™ Motorised Roman Blind Cassette System Setup & Operating Instructions Setting up power: Battery Operation 1.1 Unscrew the end cap on the battery wand at the end without the cable protuding. 1.2 Insert 8 x AA Lithium-ion batteries in to the battery wand – check...
- Page 2 Setting up power: Mains Operation 1.4 Connect the relevant mains adaptor plug front to the transformer by twisting into position (as shown below) 1.5 Connect the 2-pin cable plug into the wire protruding out of the blind headrail (Fig 1). The power is now connected. ‘CLICK’...
- Page 3 Programming your remote continued Reverse the direction 3.2 Press and hold the DOWN button to test that 3.1 To reverse the direction of the motor, press the motor direction is correct. and hold the button until the blind shunts. Press & hold TIP: The motor is quick –...
- Page 4 Programming your remote continued Set your lower limit position 5.1 Press and hold the and Up button until the blind starts to move up. Press & hold for 1 sec 5.2 The blind will now automatically stop at 5.3 Press and hold the button until the blind your previously chosen Upper limit position.
- Page 5 Changing your saved settings Adjusting the lower limit position 7.1 Press the Down button and send the blind 7.2 Press and hold the Up and Down buttons to the current-set lower limit position until the blind shunts. Press & hold for 5 secs AUTO STOP...
- Page 6 Using your remote control and my settings Once programmed, your remote will automatically stop at the set upper and lower limits when you press either the up or down buttons respectively, unless you press the button, which will stop the blind. How to programme a Multi-Channel remote Multi-Channel Remote (MCR) Single Channel Remotes (SCR)
- Page 7 How to programme a Multi-Channel remote continued To program a Multi-Channel Remote (MCR) NOTE: Only one blind can be copied at a time you are going to copy the programming from so all other blinds should remain disconnected each Single Channel Remote (SCR) onto the from their power supply during the copying relevant channel of your choice on the MCR.
- Page 8 Resetting your blind/Restoring to factory default IMPORTANT: This step can erase all memory or any previously recorded settings! Ensure you follow this procedure carefully Locate the motor reset button which is in a small hole within the headrail channel on the silver coloured motor close to the wiring end.
