Instruction Manual
Venetian Blinds
Assembly Accessories:
2x
End Brackets
Tools required for installation:
NB: Blind headrails shall not be installed less than 1.5m from the floor.
Fix brackets
1
Measure and mark bracket
position. Dill holes in the wall
substrate and plug if required,
then fix the 2 x brackets into
place with the screws provided.
Fix intermediary support brackets
2
For blind width sizes over 75cm you then need
to fix support brackets. Ensure these brackets are
positioned to line-up exactly with the slots on the
underside of the head rail.
NOTE: The support bracket closest to the pull
cord end must be installed. This is essential.
0–3x
2x
Support Brackets
Face Plates
In a recess
1x
1x
2x
Wand
Cleat
Retention Plate
Wall mounted
Centre Support
Head Rail
6–14x
Screws
To the ceiling
Side view
Slot on underside
of the Head Rail
