evertz 7708SFP Series User Manual

Fiber optic sfp card module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
© Copyright 2015
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone:
+1 905-335-3700
Sales:
sales@evertz.com
Tech Support: service@evertz.com
Web Page:
http://www.evertz.com
Version 1.0, February 2015
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for
the use of purchasers of the 7708SFP Series. Evertz Microsystems expressly prohibits the use of this manual for any purpose
other than the operation of the device.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems
Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz Microsystems.
7708SFP Series
Fiber Optic SFP Card Module
User Manual
Fax: +1 905-335-3573
Fax: +1 905-335-7571

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7708SFP Series and is the answer not in the manual?

Questions and answers

Related Manuals for evertz 7708SFP Series

Summary of Contents for evertz 7708SFP Series

  • Page 1 Version 1.0, February 2015 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 7708SFP Series. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the device.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface...

  • Page 5: Table Of Contents

    4.5. 7708SFP-4-DIN-A ....................... 24 4.5.1. Control ........................24 4.5.2. Monitor ........................26 4.5.3. Notify ........................28 UPGRADING THE FIRMWARE ....................31 5.1. CHECKING FIRMWARE VERSION ON THE 7708SFP SERIES ........31 5.1.1. Downloading the 7708SFP Image................31 Page - iii Revision 1.0...
  • Page 6 7708SFP Fiber Optic SFP Card Module 5.2. REMOTE UPGRADE PROCEDURE USING VISTALINK ..........32 ® 5.2.1. Upgrading the 7708SFP Image using VistaLINK ........... 32 ® 5.3. UPGRADING SERIALLY THROUGH THE SERIAL PORT ..........33 5.3.1. Setting the 7708SFP to Upgrade Mode ..............33 5.3.2.
  • Page 7 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 8 7708SFP Fiber Optic SFP Card Module This page left intentionally blank Page - vi Revision 1.0...

  • Page 9: Overview

    Fiber Optic SFP Card Module OVERVIEW The Evertz 7708SFP series is a card-based equivalient to the 3405FR series fiber optic SFP frames. The 7708SFP series can accommodate any 3405 series SFP, allowing the SFP cages to be populated as needed with optical transmit, receive, regenerator or electrical distribution amplifier SFP’s. The 7708SFP series offers a very high-density and cost-effective solution for constructing modern fiber optic infrastructures.

  • Page 10: 7708Sfp Versions

    7708SFP Fiber Optic SFP Card Module 1.1. 7708SFP VERSIONS The 7708SFP series is available in four different versions: Number Model Description Connector Density of Slot Single SFP BNC Up to 2 EO or OE conversions in 1 7708SFP card module...

  • Page 11: Figure 1-3: 7708Sfp-4-Din-A

    7708SFP Fiber Optic SFP Card Module Figure 1-3: 7708SFP-4-DIN-A Figure 1-4: Complete Block Diagram Overview Page - 3 Revision 1.0...

  • Page 12: Sfp Options

    7708SFP Fiber Optic SFP Card Module 1.2. SFP OPTIONS SFP Type Optical and Electrical Layout 3405T13-2/ Electrical Input A maps to Optical Out A 3405Txx/yy-2 Electrical Input B maps to Optical Out B Electrical input C and D not used 3405T13-R/ Electrical Input A maps to Optical Output A 3405Txx-R...
  • Page 13 7708SFP Fiber Optic SFP Card Module Page - 5 Revision 1.0...

  • Page 14: Figure 1-5: Sfp Options

    7708SFP Fiber Optic SFP Card Module Figure 1-5: SFP Options Page - 6 Revision 1.0...

  • Page 15: Getting Started

    7708SFP Fiber Optic SFP Card Module GETTING STARTED Each 7708SFP module comes with a companion rear plate that has at least one SFP connector (depending on the options ordered). In addition, there can be an array of BNC or DIN connectors used to to suit different density or connector preferences.
  • Page 16 When installing the Evertz SFP module into the rear plate SFP housing, align the transmit and receive arrow indicators to the LEFT with the rear plate upright. Gently slide the SFP module into the rear plate SFP housing until it clicks into place.

  • Page 17: Technical Specifications

    7708SFP Fiber Optic SFP Card Module TECHNICAL SPECIFICATIONS 3.1. SYSTEM Density: 7708SFP: 1 SFP module 7708SFP-2: Up to 2 SFP modules 7708SFP-2-DIN: Up to 2 SFP modules 7708SFP-4-DIN-A: Up to 4 SFP modules Impedance: 75Ω Connector: 7708SFP: BNC per IEC 61169-8 Annex A 7708SFP-2: BNC per IEC 61169-8 Annex A 7708SFP-2-DIN:...

  • Page 18: Reclocked Electrical Outputs

    7708SFP Fiber Optic SFP Card Module Equalization: Automatic to 80m @ 3Gb/s 100m @ 1.5Gb/s 250m @ 270Mb/s (wih Belden 1694A or equivalent) Return Loss: >15dB up to 1.5GHz >10dB to 3GHz 3.5. RECLOCKED ELECTRICAL OUTPUTS Signal Level: 800mV (nominal) DC Offset: 0V +/0.5V Rise and Fall Time:...

  • Page 19: Vistalink Pro Interface

    “+” button. Your card should appear as a newly listed device under the IP address used for the frame controller.  Please consult your network administrator if you continue to have problems connecting card with VistaLINK PRO, alternatively contact Evertz ® Microsystems Ltd. or your authorized reseller for technical support. Page - 11 Revision 1.0...

  • Page 20: 7708Sfp On Vistalink Pro

    7708SFP Fiber Optic SFP Card Module 4.2. 7708SFP ON VISTALINK PRO 4.2.1. Control Figure 4-1: Control Conguration Screen Transmitter Squelch: This control allows the user to either enable or disable the ability to Squelch transmitted signals. Receiver Squelch: This control allows the user to either enable or disable the ability to Squelch received signals.

  • Page 21: Monitor

    7708SFP Fiber Optic SFP Card Module Receiver Swap Channels: This control allows channel swapping for input streams. Receiver Invert Output: This control allows the user to invert the output being received on Output A or Output Mute: This control allows the user to mute the output. Reclocker Mode: This control allows the user to set the reclocking method to either Auto Bypass or Forced Bypass.

  • Page 22: Notify

    Fiber Optic SFP Card Module Module Type: Displays the 7708SFP series module type Module Serial Number: Displays the part serial number, this is required to access the card via Evertz Product Support Services Web page. Module Version: Displays the current firmware version being used on the card.

  • Page 23: 7708Sfp-2 On Vistalink Pro

    7708SFP Fiber Optic SFP Card Module No Input Detected: Video not present. Reclocker loss: Video not detected by reclocker. Transmitter Laser Status: Laser health. SFP Communication Loss: SFP communication with FC not present. 4.3. 7708SFP-2 ON VISTALINK PRO 4.3.1. Control Figure 4-4: Control Configuration Screen Transmitter Squelch: This control allows the user to either enable or disable the ability to Squelch transmitted signals.

  • Page 24: Figure 4-5: Monitor Screen

    Switch Type: This control allows the user to define the method switch type to detect based on Signal Presence Loss, or Reclock Loss. Figure 4-5: Monitor Screen Module Type: Displays the 7708SFP series module type Page - 16 Revision 1.0...
  • Page 25 7708SFP Fiber Optic SFP Card Module Module Serial Number: Displays the part serial number, this is required to access the card via Evertz Product Support Services Web page. Module Version: Displays the current firmware version being used on the card.

  • Page 26: Figure 4-6: Trap Enable & Fault Status

    7708SFP Fiber Optic SFP Card Module Figure 4-6: Trap Enable & Fault Status Receiver Optical Power High: Optical input power exceeds max input power specification. Receiver Optical Power Low: Optical input power below threshold. No Input Detected: Video not present. Reclocker loss: Video not detected by reclocker.

  • Page 27: 7708Sfp-2-Din On Vistalink Pro

    7708SFP Fiber Optic SFP Card Module 4.4. 7708SFP-2-DIN ON VISTALINK PRO 4.4.1. Control Figure 4-7: Control Configuration Screen Transmitter Squelch: This control allows the user to either enable or disable the ability to Squelch transmitted signals. Receiver Squelch: This control allows the user to either enable or disable the ability to Squelch received signals.

  • Page 28: Monitor

    4.4.2. Monitor Figure 4-8: Monitor Screen Module Type: Displays the 7708SFP series module type Module Serial Number: Displays the part serial number, this is required to access the card via Evertz Product Support Services Web page. Page - 20 Revision 1.0...
  • Page 29 7708SFP Fiber Optic SFP Card Module Module Version: Displays the current firmware version being used on the card. Upgrade Support: Displays whether or not there is Upgrade Support that is provided for the current firmware version. Receiver Optical Power: This control displays the currently measured optical power on the receiver input in dB.

  • Page 30: Notify

    7708SFP Fiber Optic SFP Card Module 4.4.3. Notify Figure 4-9: Trap Enable & Fault Status Page - 22 Revision 1.0...
  • Page 31 7708SFP Fiber Optic SFP Card Module Receiver Optical Power High: Optical input power exceeds max input power specification. Receiver Optical Power Low: Optical input power below threshold. No Input Detected: Video not present. Reclocker loss: Video not detected by reclocker. Transmitter Laser Status: Laser health.

  • Page 32: 7708Sfp-4-Din-A

    7708SFP Fiber Optic SFP Card Module 4.5. 7708SFP-4-DIN-A 4.5.1. Control Figure 4-10: Control Configuration Screen Transmitter Squelch: This control allows the user to either enable or disable the ability to Squelch transmitted signals. Receiver Squelch: This control allows the user to either enable or disable the ability to Squelch received signals.
  • Page 33 7708SFP Fiber Optic SFP Card Module Receiver Low Optical Threshold: This control allows the user to set the minimum optical level drop being received in in dB. Range for this value can be from -2dB to -40dB. Receiver Output Slew Rate: This control allows the user to set the slew rate to either SD, HD, or 3G on the receiver output.

  • Page 34: Monitor

    7708SFP Fiber Optic SFP Card Module 4.5.2. Monitor Figure 4-11: Monitor Screen Page - 26 Revision 1.0...
  • Page 35 Fiber Optic SFP Card Module Module Type: Displays the 7708SFP series module type Module Serial Number: Displays the part serial number, this is required to access the card via Evertz Product Support Services Web page. Module Version: Displays the current firmware version being used on the card.

  • Page 36: Notify

    7708SFP Fiber Optic SFP Card Module 4.5.3. Notify Figure 4-12: Trap Enable & Fault Status Page - 28 Revision 1.0...
  • Page 37 7708SFP Fiber Optic SFP Card Module Receiver Optical Power High: Optical input power exceeds max input power specification. Receiver Optical Power Low: Optical input power below threshold. No Input Detected: Video not present. Reclocker loss: Video not detected by reclocker. Transmitter Laser Status: Laser health.
  • Page 38 7708SFP Fiber Optic SFP Card Module This page left intentionally blank Page - 30 Revision 1.0...

  • Page 39: Upgrading The Firmware

    5.1. CHECKING FIRMWARE VERSION ON THE 7708SFP SERIES From time to time, the 7708SFP series modules will need to be upgraded with the latest information (“image”) to maintain the most up-to-date monitoring and control capabilities. There are two methods for checking the firmware version.

  • Page 40: Remote Upgrade Procedure Using Vistalink

    6) Click the ‘Upgrade’ button and wait for the upload to complete. This will take approximately 5 to 10 minutes depending on network traffic. Upon completion, the 7708SFP series modules will reboot automatically and return online in normal “run” mode.

  • Page 41: Upgrading Serially Through The Serial Port

    For normal operation the jumper is set in the RUN position. To upgrade the firmware in the module unit pull it out of the frame. Move Jumper J5 into the UPGRADE position. Connect Once Tera Term is connected, insert the 7708SFP series module into its slot. ...

  • Page 42: Upgrading In Run Mode

    7708SFP Fiber Optic SFP Card Module 5.5. UPGRADING IN RUN MODE Boot up card and press ‘enter’. Select ‘1’ for ‘7708-SFP Settings” Select ‘1’ for ‘Firmware Upgrade’. Page - 34 Revision 1.0...

  • Page 43: Viewing Upgrade Information

    7708SFP Fiber Optic SFP Card Module 5.5.1. Viewing Upgrade Information Booting information will then be sent to the Tera Term window. After the card powers up the “upload” message is displayed. Using XMODEM select to ‘Send’. Page - 35 Revision 1.0...
  • Page 44 7708SFP Fiber Optic SFP Card Module Locate the unzipped image file and select ‘Open’. File will now download. This make take several minutes. Select image file downloaded and unzipped in section 5.1.1 and upload file. Module will automatically reboot.  If jumper J5 was used in UPGRADE mode then place jumper J5 back in RUN mode and reboot module.

  • Page 45: Jar Upgrade Procedures

    VISTALINK PRO JAR FILE UPGRADE Evertz products are constantly evolving and new features are often added. It is therefore important to update the JAR files in use to provide access to all the latest features or enhancements. It will also be necessary to add JAR files for new products.

  • Page 46: Figure 6-4: Alarm Server Restart Notification

    7708SFP Fiber Optic SFP Card Module To perform a JAR update, ensure that all VistaLINK PRO clients are closed (those clients which are ® not closed will automatically be disconnected as soon as the VistaLINK PRO Server is restarted). ® Maximize the VistaLINK PRO Server window from the Windows task bar, select Help>...
