evertz 7700ACO-HD User Manual

Auto change over
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
7700ACO-HD HD/SD-SDI 8-Channel AES & RS-232/RS-422
© Copyright 2020
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone:
+1 905-335-3700
Sales:
sales@evertz.com
Tech Support: service@evertz.com
Web Page:
http://www.evertz.com
Version 1.3, July 2020
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of
purchasers of the 7700Multiframe. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the
7700AC0-HD.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.
7700 MultiFrame Manual
Auto Changeover User Manual
Fax: +1 905-335-3573
Fax: +1 905-335-7571
Twitter:
@EvertzTV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7700ACO-HD and is the answer not in the manual?

Questions and answers

Related Manuals for evertz 7700ACO-HD

Summary of Contents for evertz 7700ACO-HD

  • Page 1 Version 1.3, July 2020 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 7700Multiframe. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the 7700AC0-HD.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Never look directly into an optical fiber. Non-reversible damage to the eye can occur in a matter of milliseconds. Do not hook up the 7707MB DWDM cards directly with a short fiber optic  cable. The 7707MB DWDM cards produce +7dBm of power which will damage the receiver if connected directly.
  • Page 5 WARNING Changes or modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables...
  • Page 6 This page left intentionally blank...
  • Page 7 July 2020 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
  • Page 8 7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover This page left intentionally blank Page ii Revision 1.3...

  • Page 9: Table Of Contents

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover TABLE OF CONTENTS OVERVIEW ............................1 INSTALLATION ..........................3 2.1. VIDEO CONNECTIONS ......................3 2.2. AES IN AND OUT CONNECTIONS ................... 4 2.3. CONTROL CONNECTIONS ..................... 5 2.4.
  • Page 10 7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover 6.9. SELECTING WHICH INPUT SIGNALS TO SWITCH ON............16 6.9.1. Adding an Input Signal to the Pool ................19 6.10. SETTING THE TYPE OF AUTO CHANGEOVER MODE ............19 JUMPERS ............................
  • Page 11 Table 2-1: AES IN A and AES IN B Audio Connector Pin Out ................4 Table 2-2: AES OUT Audio Connector Pin Out ..................... 4 Table 2-3: AES Audio Breakout Cable (Evertz Part # WPAES8-BNCM-6F) ............5 Table 2-4: GPI Operations ............................. 6 Table 2-5: GPO Status ............................
  • Page 12 7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover This page left intentionally blank Page vi Revision 1.3...

  • Page 13: Overview

    7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover OVERVIEW The 7700ACO-HD HD/SD SDI Auto Changeover is designed to provide a HD/SD SDI video, multi-channel AES audio, and RS422/RS232 changeover in a single device. The module can be controlled via GPI, remotely via VistaLINK PRO, or be set in auto changeover mode.

  • Page 14: Figure 1-1: 7700Aco-Hd Block Diagram

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover HD/SD SDI Latching Relay HD/SD EQ HD/SD SDI Inputs HD/SD EQ Format Validation VistaLINK® Interface GPIO Processor Selector Guide Interface AES Rx AES Inputs Latching AES Rx...

  • Page 15: Installation

    7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover INSTALLATION The 7700ACO-HD comes with a companion rear plate that occupies two slots in the frame. information on mounting the rear plate and inserting the module into the frame see section 3 of the 7700FR chapter.

  • Page 16: Aes In And Out Connections

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover 2.2. AES IN AND OUT CONNECTIONS There are two high-density DB-15 connectors labeled AES IN A and AES IN B. Each connector provides eight unbalanced AES inputs on 8 BNC connectors. There is a third high-density DB-15 connector labeled AES OUT.

  • Page 17: Control Connections

    7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover The 7700ACO-HD is shipped with three breakout cables for the DB-15 connector (Evertz Part # WPAES8-BNCM-6F), which can be used to facilitate wiring the audio and GPI connections. The pin outs of the cables are shown in Table 2-3.

  • Page 18: General Purpose Inputs And Outputs

    IN B Figure 2-2: Control Connection Pin Out 2.4. GENERAL PURPOSE INPUTS AND OUTPUTS The 7700ACO-HD has two GPI’s and two GPO’s available via terminal block. The terminal block pin out is shown in Figure 2-3. GPI 1 GPI 2...

  • Page 19: Specifications

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover SPECIFICATIONS 3.1. SERIAL DIGITAL VIDEO INPUTS Standards: STMPE 292M (1.5Gb/s), SMPTE 259M-C (270 Mb/s) 525 or 625 line component SMPTE 310M Number of Inputs: Connector: 2 BNC per IEC 61169-8 Annex A Maximum Cable Length: 100m of Belden 1694 or equivalent cable combined input and output.

  • Page 20: General Purpose Inputs And Outputs

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover 3.5. GENERAL PURPOSE INPUTS AND OUTPUTS Type Inputs: Opto-isolated input with internal pull-up to +5 Volts Outputs: Normally 10k internal pull-up to +5V. Ground to rear panel when relay is in...

  • Page 21: Status Indicators

    7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover STATUS INDICATORS The 7700ACO-HD has 8 LED Status indicators on the front card edge to show operational status of the card at a glance. Figure 4-1 shows the location of the LEDs and card edge controls.

  • Page 22: Bank Presence Leds

    Bank B is not present. Green Bank B is present. Table 4-2: Bank Presence LEDs 4.3. LOCAL / REMOTE STATUS This LED indicates whether the 7700ACO-HD is controlled locally (via card edge) or remotely (via VistaLINK ® Colour Description Remotely controlled via VistaLINK or card edge.

  • Page 23: Card Edge Controls

    DIP Switch: The 7700ACO-HD is equipped with a 4 position DIP switch to allow the user to set how the module will be controlled and monitored. Table 5-1 gives an overview of the DIP switch functions.

  • Page 24: 5.1.1. Setting Control Or Monitor Mode

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover 5.1.1. Setting Control or Monitor Mode DIP Switch Control Value Description Description The module is in control mode. The module can be configured by either card edge or VistaLINK depending ®...

  • Page 25: Card Edge Menu System

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover CARD EDGE MENU SYSTEM 6.1. NAVIGATING THE MENU SYSTEM You can use the toggle switch to move up and down the list of available parameters. To adjust any parameter, use the toggle switch to move up or down to the desired parameter and press the pushbutton.

  • Page 26: 6.2.1. Display Type Of Signal Present On Hd/Sd Input A

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover 6.2.1. Display Type of Signal present on HD/SD Input A Both SDIA and SDIB display the same type of information. For the sake of simplicity in the manual, only SDIA is shown below.

  • Page 27: Top Level Menu Structure

    6.4. SETTING THE CHANGEOVER MODE MODE This parameter is used to set the switch mode of the 7700ACO-HD. AUTO AUTO – This puts the module into auto changeover mode. If a signal in active bank is lost, the module will automatically switch to the second bank.

  • Page 28: Resetting The Module To Factory Defaults

    SELECTING WHICH INPUT SIGNALS TO SWITCH ON The 7700ACO-HD uses a pool of input signals to determine when to activate a switch between the two banks. The pool can consist of the input video signal and/or any (or all) of the eight AES inputs. The signals in the pool are monitored in order to activate a switch.

  • Page 29: Table 6-4: Pool Example

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover Table 6-4 provides examples of this functionality. In the example, the pool contains Input Video, AES 1, AES 3, AES 5, and AES 8. Also in each case, the transition will be from the primary bank to the secondary one.
  • Page 30 VIDE module will switch to the other bank. AES1 AES2 There is a strict priority that is followed by the 7700ACO-HD. Video has AES3 the highest priority. If the primary (or active) bank loses an AES signal, AES4 and the secondary bank is missing a video signal (and is in the pool) the AES5 7700ACO-HD will not switch to the secondary bank.

  • Page 31: 6.9.1. Adding An Input Signal To The Pool

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover 6.9.1. Adding an Input Signal to the Pool In order to include an input signal into the pool of monitored signals, the user must add it. The controls to add VIDE and AES1 to AES8, are the same.
  • Page 32 7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover This page left intentionally blank Page 20 Revision 1.3...

  • Page 33: Jumpers

    Firmware chapter. Once the upgrade is completed, remove the module from the frame, move J3 into the RUN position, remove the upgrade cable and re-install the module. The module is now ready for normal operation.  The Upgrade baud rate for the 7700ACO-HD module is 115,200 baud. Page 21 Revision 1.3...
  • Page 34 7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover This page left intentionally blank Page 22 Revision 1.3...

  • Page 35: Vistalink Remote Monitoring/Control

    (GUI), third party or custom manager software may be used to monitor and control Evertz VistaLINK enabled fiber optic products. ® 2. Managed devices (such as 7700ACO-HD), each with a unique address (OID), communicate with the NMS through an SNMP Agent. Evertz VistaLINK enabled 7700 series modules reside in the 3RU ®...

  • Page 36: Vistalink ® Monitored Parameters

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover 8.2. VISTALINK MONITORED PARAMETERS ® Figure 8-1: VistaLINK Monitored Parameters ® 8.3. VISTALINK CONTROLLED PARAMETERS ® Figure 8-2: VistaLINK Module Fault Traps ® Page 24 Revision 1.3...

  • Page 37: Figure 8-3: Vistalink Bank A Fault Traps

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover Figure 8-3: VistaLINK Bank A Fault Traps ® Figure 8-4: VistaLINK Bank B Fault Traps ® Page 25 Revision 1.3...

  • Page 38: Vistalink ® Traps

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover Figure 8-5: VistaLINK Control ® 8.4. VISTALINK TRAPS ® Figure 8-6: VistaLINK Traps ® Page 26 Revision 1.3...

  • Page 39: Menu Quick Reference

    7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover MENU QUICK REFERENCE Changeover Mode (MODE) Factory Reset (FRST) Firmware Version (VER) − AUTO − YES − GPI − NO − MAN Display Orientation Monitor Mode Auto Changeover...
  • Page 40 7700 MultiFrame Manual 7700ACO-HD HD/SD SDI 8 Channel AES & RS-232/RS-422 Auto Changeover End of Document Page 28 Revision 1.3...
