  • Page 1 SPARE PARTS DIAGRAM FOR Proving Cabinet Lilliput H=800 Lilliput H=1100 Combi-Lilliput H=700 First Choice Group Blakeney Way, Kingswood Lakeside Cannock, Staffs, WS11 8LD TEL: 01543 577778 FAX: 01543504141 Email: enquires@firstchoice-cs.co.uk Web: www.firstchoice-cs.co.uk...
  • Page 2 DR. ZANOLLI s.r.l. Via Casa Quindici, 22 37066 Caselle di Sommacampagna (Verona) Italy Tel +39 045 8581500 (r.a.) Fax +39 045 8581455 Web: www.zanolli.it  e-mail: zanolli@zanolli.it PROVING CABINET LILLIPUT Installation, use and maintenance manual...
  • Page 3 Dr. Zanolli s.r.l. Via Casa Quindici, 22 37066 Caselle di Sommacampagna VR Tel. +39-0458581500 Fax +39-0458581455 VAT N.IT00213620230 Proving cabinet Lilliput 11 English Manual Cod. CL LILLIPUT.UK.11 rev. 0.1 del 21/05/2012...
  • Page 4 PROVING CABINET LILLIPUT 11 INDEX 1 PRODUCT IDENTIFICATION ................4 2 CONFORMITY WITH DIRECTIVES ..............4 3 TECHNICAL SPECIFICATIONS ..............4 4 PROVING CABINET INSTALLATION ............. 5 4.1 Humidifier water connection (optionally) ..........5 5 CONTROL PANEL ..................6 6 WORKING ....................... 8 6.1 Humidifier working (optionally) ..............
  • Page 5: Product Identification

    PROVING CABINET LILLIPUT 11 1 Product identification This manual refers to the proving cabinets of the LILLIPUT. 2 Conformity with directives The proving cabinets bear the following compulsory mark: which guarantees their conformity to the following European directives: 2004/108/CE electromagnetic compatibility 2006/95/CE low voltage 3 Technical specifications The following table shows the proving cabinets’...
  • Page 6 PROVING CABINET LILLIPUT 11 Proving cabinet installation See figure 10.1 for the exact position of the electrical feed input (1). 4.1 Humidifier water connection (optionally) Connect the humidifier water inflow (2) to the plumbing, with a cock. Connect the water outflow of the humidifier-discharge to the plumbing (3). Verify that the water outflow discharges in a trap.
  • Page 7: Control Panel

    PROVING CABINET LILLIPUT 11 5 Control panel Prover heating element lamp Prover light switch Prover heating element thermostat Fig. 10.2 Control panel PROVING CABINET LILLIPUT 11...
  • Page 8 PROVING CABINET LILLIPUT 11 Prover heating Prover light switch element lamp Prover heating element thermostat Humidifier heating element lamp (optionally) Humidifier heating element energy regulator (optionally) Fig. 10.3 Control panel with humidifier (optionally) PROVING CABINET LILLIPUT 11...
  • Page 9 PROVING CABINET LILLIPUT 11 6 Working Figure 10.2 shows the control panel with all controls. To switch on the prover heating elements, move the prover heating element thermostat and set a leavening temperature. When the desired temperature has been set, the prover heating element lamp will switch on , up to the settled temperature.
  • Page 10: Electrical Diagram

    PROVING CABINET LILLIPUT 11 8 Prover cleaning Use a soft damp sponge to clean the stainless steel or aluminium plate baking, if necessary with a light, non abrasive detergent, being careful that it does not splash onto any refractory surfaces. Do not use abrasive detergents or corrosive materials, as it could dull the stainless steel.
  • Page 11 PROVING CABINET LILLIPUT 11 Fig. 10-4 Electrical diagram at 230Vac single phase PROVING CABINET LILLIPUT 11...
  • Page 12: Exploded Views And Spare Parts List

    PROVING CABINET LILLIPUT 11 Fig. 10-5 Electrical diagram at 230Vac single phase with humidifier (optionally) 10 Exploded views and spare parts list. In order to simplify the breakdown search and any necessary replacement of damaged parts, we give a list of spare parts and exploded diagrams showing each of the listed parts.
  • Page 13 PROVING CABINET LILLIPUT 11 Fig. 10-6 Prover exploded view Codes Codes Codes PROVING PROVING PROVING N° Description CABINET CABINET CABINET COMBI-LILLIPUT LILLIPUT H=800 LILLIPUT H=1100 H=700 DOOR GLASS CRIS0073 CRIS0074 CRIS0075 DOOR HANDLE MANI0068 MANI0068 MANI0068 LAMP LAMP0048 LAMP0048 LAMP0048 PROVER HEATING ELEMENT MANI0081 MANI0081...
  • Page 14 PROVING CABINET LILLIPUT 11 Fig. 10-7 Humidifier exploded view (optionally) odes PROVING CABINET N° Description LILLIPUT / COMBI-LILLIPUT PROOFING CABINET CONTROL PANEL PANN0369 ENERGY REGULATOR TERM0050 THERMOSTAT 0-90° CHAMBER TERM0002 FAIRLEAD PG13.5 ELET0090 CHAMBER HUMIDIFIER RESISTANCE RESI0016 HUMIDIFIER BALL FOR FLOATING GASI0011 CAR1704 HUMIDIFIER FLOATING BAR 3/8"...
  • Page 15 PROVING CABINET LILLIPUT 11 Separate collection. This product must not be disposed of with normal household waste. Local regulations may provide for separate collection of this kind of product PROVING CABINET LILLIPUT 11...
  • Page 16: Declaration Of Conformity

    PROVING CABINET LILLIPUT 11 11 Declaration of conformity PROVING CABINET LILLIPUT 11...
