ESI PLANET 22C User Manual

Reference quality dante audio interface

Download this manual

Reference Quality Dante Audio Interface

User's Guide

Page 1 Reference Quality Dante Audio Interface User’s Guide...
Page 3 5. RJ45 network connector to connect planet 22c to the Dante network with embedded network status LEDs. 6. 12V DC power connector that connects to the included DC power supply. If planet 22c is not powered via the network cable (PoE operation), a power supply must be connected here.
Page 4 3. Connection / Usage Before using planet 22c, you need to decide if you use the included 12V DC power supply or if you can provide power via the network cable (PoE). For PoE operation either a PoE switch that supplies power via the network cable or a so-called PoE injector is in between network cables is required.
Page 5: Specifications
22c 5. Specifications Analog Inputs - ADC: BurrBrown PCM1804DB 24-bit Stereo - Connector: 2x 6.3mm / 1/4" fully balanced TRS - Maximum Input Level: +6dBV (-10dBV setting) +20dBu (+4dBu setting) - Impedance: 10 kOhm - THD+N: -107dB A-weighted (@-3dBFS, -10dBV setting)
Page 6: General Information
22c 6. General Information Trademarks ESI, planet and planet 22c are trademarks of ESI Audiotechnik GmbH. Dante and Audinate are legal trademarks of Audinate Pty Ltd., other product and brand names are trademarks or registered trademarks of their respective companies.
