This operation manual describes precautions that are important for preventing
accidents as well as procedures used to handle the product.
●
To ensure the product is used safely and correctly, read this operation manual
thoroughly before using the product.
●
After reading this manual, keep it carefully stored in an easily accessible location
for future reference.
Operation Manual
CODE
080800-030
Low Volume Pump
LVS-30
With Warranty
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sibata LVS-30
Summary of Contents for Sibata LVS-30
- Page 1 CODE 080800-030 Operation Manual Low Volume Pump LVS-30 With Warranty ● This operation manual describes precautions that are important for preventing accidents as well as procedures used to handle the product. ● To ensure the product is used safely and correctly, read this operation manual thoroughly before using the product.
-
Page 2: Table Of Contents
Table of Contents Introduction ..................... 4 Notation Method in this Manual ..............4 1.1.1 Danger, Warning, Caution, and Note ..........4 1.1.2 Important and Hint ................4 1.1.3 Symbols.................... 4 Checking Package Contents ............... 5 Definition of Applicable Users ..............5 Safety Precautions .................. - Page 3 7.1.2 Interval Timer Settings ..............24 Registering and Recalling Sampling Parameter Settings ......25 7.2.1 Registering Settings ................. 25 7.2.2 Recalling Settings ................26 Replacing the Battery Unit while Sampling is Paused ......... 26 Preventing Inadvertent Operations during Sampling........27 Locking the Keys ..................
-
Page 4: Introduction
Introduction Notation Method in this Manual 1.1.1 Danger, Warning, Caution, and Note This product is designed to prioritize operator safety. Nevertheless, some risks could not be eliminated, due to product characteristics. In this manual, the signal words DANGER, WARNING, and CAUTION are used to indicate three levels of seriousness or danger of such risks to humans. -
Page 5: Checking Package Contents
If any items are missing or damaged, contact the distributor where you purchased the product. After unpacking the product, Sibata recommends storing the cushioning materials and boxes for use later when requesting repairs, but if they are discarded, be sure to discard them appropriately in accordance with laws, regulations, regional rules, and local government instructions. - Page 6 Do not plug the power cord into an outlet shared by multiple devices. Doing so could cause an electric shock or fire. Contact the distributor or your Sibata representative before operating the product at a voltage outside the specified range.
- Page 7 Do not insert screws or other foreign objects into the air intake port or exhaust port. If a foreign object accidentally enters a port, immediately switch the power OFF and contact the distributor or your Sibata representative. Keep the product away from sources of noise. Also, do not place it in areas with strong magnetic fields, high dust levels, or high humidity.
- Page 8 Doing so can prevent battery degradation. Note that in the unlikely event a product failure occurs, Sibata accepts no responsibility for paying compensation due to inability to acquire or record sampling results, loss of data or other information, or any other damages directly or indirectly resulting from such losses.
-
Page 9: About This Product
About this Product Overview The LVS-30 low volume pump is a small light-weight portable air sampling pump intended for measurements in working environments or other atmospheric air environments. It includes built-in constant-flowrate functionality that inhibits any decrease in intake flowrate associated with intake pressure increases, such as when collecting dust. -
Page 10: Names Of Parts
Names of Parts 3.3.1 Main Unit Air intake port (under rubber cover) Air intake port jig Battery cover USB port (under rubber cover) Control panel Exhaust port Handle DC power jack (under rubber cover) 3.3.2 LI-30 Battery Unit (Sold Separately) Screw Terminals... -
Page 11: Control Panel
3.3.3 Control Panel ● Action indicator (The color changes depending on pump parameter settings.) ● Display unit ● Go back to previous screen. ● Hold down to lock/unlock keys. ● Start, stop, or resume sampling. ● Apply setting. ● Pause sampling or hold Charging indicator down to stop sampling when paused. -
Page 12: Preparation Before Use
Preparation before Use Preparing the Power Supply This product can be operated using a separately sold LI-30 battery unit or an AC power supply (AC adapter and power cord). ● When a battery unit is installed, it can be charged by connecting to an AC power supply. -
Page 13: Connecting The Ac Adapter And Power Cord
While pressing the battery cover against the top of the main unit, push the cover straight forward. A click sound is emitted when installed properly. 4.1.2 Connecting the AC Adapter and Power Cord CAUTION The AC adapter (sold separately) can be used with power supplies ranging from 100 to 240 V, but the power cord (sold separately) is designed specifically for 100 V power supplies. -
Page 14: Switching The Power On/Off
Switching the Power ON/OFF To switch the power ON or OFF, simultaneously hold down for at least 2 seconds. When switching the power OFF, the operation corresponding to either may be inadvertently executed, but continue to hold down both buttons. [HOME] and [MENU] Screens When the power is switched ON, the [HOME] screen is displayed. -
Page 15: Checking The Battery Charge Level
3 Extra ---------- Settings for 14 parameters Setting Parameter Description Page 1 Interval Timer Sets the interval timer. p. 24 2 Passcode Sets passcode for operating or unlocking keys. p. 27 Sets or deletes settings for up to five sets of sampling p. -
Page 16: Checking And Setting Date And Time Values
Checking and Setting Date and Time Values The date and time values can be set on this product. Because this information is recorded together with sampling results, it is recommended that these values be checked and specified in advance. : Select : Apply : Back After switching the power ON, press... -
Page 17: Attaching/Detaching The Air Intake Holder
Attaching/Detaching the Air Intake Holder NOTE To prevent accidents caused by intaking foreign matter or fine dust, always attach a filter element to the air intake holder. Open the air intake port cover and screw in an air intake port jig into the air intake port. Remove the two screws that fasten the air intake holder. -
Page 18: Connecting A Sampler To The Pump
Remove the air intake port jig. Connecting a Sampler to the Pump 4.7.1 Checking the Intake Pressure Pressure gauge Attaching a filter paper holder or other sampler to the air intake port results in a pressure loss that depends on the sampler. Sampler This product has a specified constant- flowrate operating range. -
Page 19: Specifying Sampling Parameter Settings
Specifying Sampling Parameter Settings On the [MENU] screen, select [1 Setup] and then press On the [Setup] screen, the sampling flowrate, flowrate conversion temperature, and sampling start/stop conditions can be specified. [Setup] Screen : Select : Apply : Back [FLOW] Sampling flowrate Flowrate conversion temperature Press... -
Page 20: Stop]
[STOP] Press to select the flashing parameter and then press Press to display the setting value or parameter and then press apply the setting. Display Setting Press to stop sampling. Sampling stops at the specified date/time. Set the year/month/day and hour:minute. Note: Set a time later than the current time and the [START] clock setting. -
Page 21: Sampling
Sampling Starting Sampling Specified performance levels might not be achievable immediately Important after switching the power ON. Warm up the system (with the power switched ON) for a few minutes before sampling. Display the [HOME] screen. (-> Refer to p. 14.) Check the displayed setting values and then press •... -
Page 22: Exceeding The Maximum Displayable Instantaneous Flowrate
When the sampling status ([PV] screen) is displayed, the sampling parameters ([SV] screen) or environmental conditions ([EI] screen) can be displayed by pressing Sampling flowrate Pump internal Flowrate conversion temperature temperature Sampling start Pump internal condition pressure Sampling stop Intake pressure condition (negative pressure) 6.2.1... -
Page 23: Checking Sampling Results
Checking Sampling Results After sampling is finished, sampling results can be checked as follows. Up to 15 sets of sampling data can be saved. For instructions on saving data, refer to p. : Select : Apply : Back Switch pages by pressing Page Display Content Total accumulated flowrate... -
Page 24: Useful Functionality
Useful Functionality Interval Timer 7.1.1 Overview of Actions Interval timer settings enable performing actions at specified intervals by alternating Current setting between specified run and wait times. : Select : Apply : Back 7.1.2 Interval Timer Settings Any start condition can be specified. Set the [STOP] sampling stop condition to [Run T.]. -
Page 25: Registering And Recalling Sampling Parameter Settings
Interval timer icon [HOME] Screen with Interval Timer Settings Specified Interval timer icon Number of Remaining time until operations/settings the next sampling starts Accumulated Accumulated operating time operating time Accumulated flowrate Accumulated flowrate [PV] Screen during Interval Timer Action Standby Screen Registering and Recalling Sampling Parameter Settings This product enables five sets of sampling parameter settings to be registered and then recalled from the [HOME] screen. -
Page 26: Recalling Settings
7.2.2 Recalling Settings To recall registered sampling parameter settings, on the [HOME] screen, press and select a box number. • Registered sampling parameter settings are displayed. • Each press of the button switches between indicating the currently displayed parameter setting and displaying the corresponding registered parameter settings. -
Page 27: Preventing Inadvertent Operations During Sampling
Preventing Inadvertent Operations during Sampling Locking the Keys After is pressed to start sampling, keys can be locked by Hold down holding down • If the keys are locked, then all key actions are disabled during sampling, except the keys or holding down unlock the keys. - Page 28 Set passcodes as follows. On the [MENU] screen, select [3 Extra]-[2 Passcode] and then press Screen Display Description of Operations Select [Restricted Mode] or [Key Lock] and then press The following operations are the same for both the Restricted Mode and Key Lock passcodes. Screen names are displayed as [Restricted Mode] or [Key Lock], respectively.
-
Page 29: Saving Sampling Results
Saving Sampling Results Up to 15 sets of sampling results can be saved. Either [Over Write] or [One Time] can be specified as the saving method. Specify the method as follows. On the [MENU] screen, select [3 Extra]-[13 Record Mode] and then press Record Mode settings are described below. -
Page 30: Increasing Measurement Precision
Increasing Measurement Precision 10.1 Performing User Calibration To measure samples more precisely, perform calibration with a sampler or other device attached to the air intake port. User calibration can be performed automatically by using a separately sold FC-L1 flow calibrator (supported from ver. 1.20). User calibration can cause flowrate to fluctuate due to other parameter settings (the flowrate setting or the sampler used during Important... - Page 31 : Select : Apply : Back On the [MENU] screen, select [3 Extra]-[5 User Calibration]-[Flow] and then press Step Screen Display Description of Operations (1) Specify Connect the flowmeter. settings. Specify the calibration flowrate and flowrate conversion temperature. Select [ENTER] and then press to start the pump.
-
Page 32: Checking The User Calibration History
10.2 Checking the User Calibration History This product can display a history of previous user calibrations. That makes it easy to identify pumps that are not user calibrated. It can also be used as an indicator for performing user calibration on a regularly scheduled basis. : Select : Apply : Back... -
Page 33: Pump Functionality And Customization
Pump Functionality and Customization 11.1 Adjusting the Activity Indicator Brightness : Select : Apply : Back On the [MENU] screen, select [3 Extra]-[4 LED] and then press • Adjust the indicator brightness by pressing . There are ten brightness levels. •... -
Page 34: Errors Displayed
11.3 Errors Displayed If an error occurs during sampling, this product stops sampling.* Also, the corresponding error is displayed on the screen and the activity indicator flashes red. For some errors, actions can be specified to continue if the error occurs. 11.3.1 Types of Errors Display/Status Cause... -
Page 35: Setting Actions For When An Error Occurs
11.3.2 Setting Actions for when an Error Occurs For flow errors, temperature errors, and pressure errors, settings can be specified to continue current actions even if those errors occur. : Select : Apply : Back On the [MENU] screen, select [3 Extra]-[8 Stop Error] and then press Whether to stop or continue actions can be switched ON or OFF for each error. -
Page 36: Troubleshooting
Release after switching the after the power supply switched “SIBATA” appears on the power ON or screen. -> Refer to p. 14. disappears after a few seconds. The AC adapter or power cord Check the plug status to make became disconnect while using sure it is connected properly. -
Page 37: Restoring Factory Settings (Initialization)
12.2 Restoring Factory Settings (Initialization) This operation will restore all setting values to factory settings, including measurement data, user calibration results, and other Important past setting changes. Once the operation is executed, it cannot be undone. On the [MENU] screen, press to select [3 Extra], and press to select [14 Factory Default]. -
Page 38: Specifications
The performance levels indicated below might not be achievable immediately after switching the power ON. Warm up the system for a few minutes before sampling. Item Code 080800-030 Model LVS-30 Variable Flowrate Range * 5.0 to 30.0 L/min Instantaneous Flowrate 0.0 to 40.0 L/min Display Range 5.0 L/min: 0 to 30 kPa... -
Page 39: List Of Materials Used
13.2 List of Materials Used Component Material Case Plastic PC, ABS, and POM Pump and Flow Rubber EPDM, Si, NBR, and CR Channels Metal A5052 and SUS304 Internal Parts PC and A5052 Built-in Battery for Clock Lithium ion button cell battery Other Electronic parts, C3604BD, and Fe 13.3 Consumables, Products Sold Separately, and Related Products... -
Page 40: Maintenance
Warranty and Repairs If a Sibata product fails within one year from date of purchase, it will be repaired free of charge. To request repairs, be sure to contact the distributor where you purchased the product. - Page 41 Therefore, always make a backup of necessary data before requesting repairs or other service work by Sibata. If you ignore the precautions in this manual or fail to create a backup, Sibata shall not be responsible for any damages resulting from lost or damaged data.
-
Page 42: Product Disposal
The product is not designed for disassembly or lithium ion battery removal directly by the user. To dispose of the battery unit, contact the distributor where you purchased the product or your Sibata representative. - Page 43 Problem Report Form If a problem occurs, fill out a copy of this Problem Report Form and contact the distributor where you purchased the product or your Sibata representative. Date completed: (yyyy/mm/dd) Product Operating Circumstances Serial No. Purchase Date (yyyy/mm/dd)
-
Page 44: Warranty
A repair service fee is charged in the following cases. (1) Failures or damage caused by usage methods (2) Failures or damage resulting from repairs or modifications not performed by Sibata (3) Failures caused by abuse or inadequate maintenance (4) Failures or damage resulting from fires, earthquakes, acts of nature, or other unavoidable...
