3
Install the filter
Carefully insert the filter back into the product
without the plastic packaging (either end of the
filter works). Take care that the filter is placed in
the center of the cavity (ref. picture 3).
4
Close the base
Close the product by rotating the base in
clockwise direction with the handle provided at
the bottom till it is securely in place. (ref. picture 4).

OPERATION

Caution: Please ensure the filters are correctly
inserted in the filter compartment, the equipment
is installed on a level surface and the power plug
is firmly connected.
5
Connect the power plug.
6
Power on
Power on the product by gently touching the ON/
OFF icon on the center of the product (ref. picture 6).
7
Air speed control
Change the fan speed by gently touching fan icon
on the product. If the product is in AUTO mode, it
will switch to manual mode on touching the fan
icon. (ref. picture 7).
8
UV-C emitter control
Activate the UV feature by gently touching UV
icon on the product, and the UV-C emitter will
light on. The UV-C emitter can help eliminate
bacteria in the product. (ref. picture 8).
Touch the button again to turn off the UV feature.
9
Auto mode
Chose the AUTO mode by gently touching "A" icon
on the product. In AUTO mode the unit will adjust
operation according to latest air quality (PM2.5
level). (ref. picture 9).
10
Sleep mode
Chose the SLEEP mode by gently touching " "
icon on the product. In SLEEP mode unit will
operate at the low noise level and all indicators
except for SLEEP icon will go off. (ref. picture 10).
11
Power off
Power down the product by gently touching the
ON/OFF icon on the center of the product.
6

AIR QUALITY INDICATOR

12
The appliance has an air quality sensor that
analyzes the air quality.
The air quality light will show the real-time air
quality through different colors of light. As shown
below:
LIGHT'S COLOR
PM 2.5 (μg/m
Blue
0-15
Green
16-35
Orange
36-75
Red
>75
FILTER CHANGE INDICATOR
13
The filter change indicator will light up to
remind you to change the filter.
• When filter change indicator flicker with red
light, please replace the filter and reset the filter
change indicator.
• When filter change indicator stop flicker and the
red light fix, please replace the filter immediately
and reset the filter change indicator.
14
Filter change indicator reset operation
Press the ON/OFF button "
change indicator will reset, then red light will go
off.
UV-C EMITTER REPLACEMENT
15
The UV indicator will blink to remind you to
change the UV-C emitter.
Please replace the UV-C emitter as following
steps (ref. picture 11) and reset the UV change
indicator.
Caution: The appliance must be disconnected
from the supply before replacing the UV-C
emitter.
1. Open the product by rotating the base in
anticlockwise direction with the handle
provided at the bottom.
2. Remove the filter from the unit.
3. Grasping the UV-C emitter with a clean cloth
or a tissure and rotating it in anticlockwise
direction carefully.
5. Replaced the new UV-C emitter by rotating it in
clockwise direction carefully.
6. Install the filter and base back to the unit, make
sure they are securely in place.
16
UV change indicator reset operation
Press UV icon "UV" for 3 seconds and UV change
indicator will reset, then white light will go off.
3
)
AIR QUALITY
Very Good
Good
Bad
Very Bad
" for 5s and filter
www.electrolux.com
