TVM 5400 Series
TVM 5600 Series
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep reading to learn all about
safe, efficient installation, and how to use your new mount.
TVM 5405/5605 Series - English
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for vogel's TVM 5400 Series
Summary of Contents for vogel's TVM 5400 Series
- Page 1 TVM 5400 Series TVM 5600 Series Full Installation Guide Everything you need to get your TV safely on the wall, in no time Before you start …we just wanted to say thanks for choosing Vogel’s. Smart choice. And you’re already making another smart choice – reading the manual! Keep reading to learn all about safe, efficient installation, and how to use your new mount.
- Page 2 Stay safe Warning Always read these safety instructions carefully before installing and using this product. Following these instructions is strictly required. Incorrect mounting and/or installation could put you, your TV, and your family at substantial risk. Don’t dare risk it… Read all Vogel’s recommends that the mounting and/or installation of this product should be carried out by a suitably qualified expert.
-
Page 3: What's In Your Box
What’s in your box? Something missing? Make sure your packaging has everything in place: A. Wall mount C. Interface strips D. Safety instructions E. Bolts for fastening strips on TV (see contents below) F. Spacers G. Washers Ø 18 mm H. - Page 4 Contents of the TV fasteners kit: 4x M6*12mm bolts 4x M6*25mm bolts 4x M6*35mm bolts 4x M8*12mm bolts 4x M8*25mm bolts 4x M8*45mm bolts 4x M6 washer 8x spacer 10mm 4x spacer 5mm You don't need all fasteners to mount your TV. Store the rest for later or other use! Got your tools ready? Don’t start without all the necessary tools: Crosshead screwdriver...
- Page 5 5 mm or 13/64” wood drill (for wooden walls only) Stud finder Socket wrench Pencil M4 (4mm) Allen key Take care of your safety Who cares about looking cool? Always wear personal protective equipment: Eye protection Ear protection Safety shoes TVM 5405/5605 Series - English...
- Page 6 Ready… set… get installing! Step 1: Attach the strips to the TV Carefully place the TV face down, on a clean surface without any obstacles! 1. Screw the interface strips Ⓒ on to the TV with the bolts Ⓔ. Make sure the interface strips Ⓒ are at the same height and do not stick out.
- Page 7 Refer to the user manual of your TV for the correct mounting material. TVM 5405/5605 Series - English...
- Page 8 Step 2: Attach the wall mount to the wall How well do you know your walls? What they’re made of matters more than you think… Concrete / Brick wall Don’t drill yet! Try our free DrillRight™ AR app to find just the right height and mark the first hole, easily.
- Page 9 How deep do you drill? Check the length of the screw (not the plug!) to find the right depth – this stops things from breaking. 5. Attach the wall mount Ⓐ to the wall with the screws Ⓗ, washers Ⓙ and plugs Ⓘ. Use the spirit level to level the wall mount.
- Page 10 6. Click the cover Ⓚ into place. Simple! TVM 5405/5605 Series - English...
- Page 11 Wooden wall with studs Don’t drill yet! Try our free DrillRight™ AR app to find just the right height and mark the first hole, easily. 1. Don’t just guess! Always use a stud finder to determine the position of studs. 2.
- Page 12 Don’t destroy your belongings! The wall mount must always be attached to the studs. 3. Mark the drilling holes. 4. Now for the fun part… drilling the holes. TVM 5405/5605 Series - English...
- Page 13 5. Attach the wall mount Ⓐ to the wooden wall with the screws Ⓗ and washers Ⓙ. Use the spirit level to level the wall mount . Make sure that you insert the centre screw into the wall first. Lubricate the screws for easy screwing in. 6.
- Page 14 Step 3: Attach the TV to the wall mount 1. Carefully lift and attach the TV to the wall mount Ⓐ. 2. When you hear a satisfying click (Auto-ClickLoc™ Safety System), you know your TV is safely in place. Lifting your TV is a two-person job. Don’t be bold! Job done now! Enjoy watching your TV! TVM 5405/5605 Series - English...
- Page 15 Handy features Having a cable mess? Do you need inspiration about how to hide and guide your cables or how to place other TV accessories? Take a look at our website vogels.com ! Removing your TV 1. Unplug the cables from your TV. 2.
- Page 16 Again, lifting your TV is a two-person job. Always get help. Tell us how you feel! Your opinion matters more than you might think. It helps us make better products, and helps other customers make informed choices. Share your feedback, and sign up to win Vogel’s products! Simply visit vogels.com/review for sharing or the Terms and Conditions.
-
Page 17: Simple Troubleshooting
Simple troubleshooting Found a problem you can’t fix? Don’t panic… try these! Problem Cause Solution ‘I have a lot of leftover No, you did it very well! You Don’t waste the other bolts, save them! bolts, is something only need 4 bolts to install You can use them for another TV when wrong?’... - Page 18 ‘Where can I request the correct bolts for my Whatever you need, simply contact your local TV (a service kit)?’ Vogel's dealer or Vogel's. Click here to contact Vogel's Consumer Care. ‘Where can I find installation videos?’ Click or tap the button on the front page of this manual.
- Page 19 Go green! We care about the planet. If you’re getting rid of the packaging or the TV mount itself, please visit your local recycling facility, or contact your municipal office. Recycling matters! TVM 5405/5605 Series - English...
- Page 20 Guarantee Thanks again for choosing Vogel’s! Just like every product we make, your new purchase is made of durable materials and is based on a meticulous design. That is why Vogel’s gives you a 15-year guarantee for defects in materials and manufacturing. 1.
