IM3035
02/2022
REV06
HOT ROD 500S
OPERATOR'S MANUAL
ENGLISH
Lincoln Electric Bester Sp. z o.o.
ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland
www.lincolnelectric.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOT ROD 500S and is the answer not in the manual?

Questions and answers

Summary of Contents for Lincoln Electric HOT ROD 500S

  • Page 1 IM3035 02/2022 REV06 HOT ROD 500S OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland www.lincolnelectric.eu...
  • Page 2: Table Of Contents

    12/05 THANK YOU! For choosing the QUALITY of the Lincoln Electric products.  Please check packaging and equipment for damage. Claims for material damaged in shipment must be notified immediately to the dealer.  For ease of use, please enter your product identification data in the table below. Model Name, Code & Serial Number can be found on the machine rating plate.
  • Page 3: Technical Specifications

    Technical Specifications NAME INDEX HOT ROD 500S K14089-1 INPUT Input Voltage Input Power at Rated Output EMC Group / Class Frequency 380 / 415V  10% 43 kVA @ 35% Duty Cycle II / A 50/60 Hz (40°C) Three Phase RATED OUTPUT Duty Cycle 40°C / 55°C...
  • Page 4: Electromagnetic Compatibility (Emc)

    Lincoln Electric. Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances.
  • Page 5: Safety

    Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation.
  • Page 6 WELDING SPARKS CAN CAUSE FIRE OR EXPLOSION: Remove fire hazards from the welding area and have a fire extinguisher readily available. Welding sparks and hot materials from the welding process can easily go through small cracks and openings to adjacent areas. Do not weld on any tanks, drums, containers, or material until the proper steps have been taken to insure that no flammable or toxic vapors will be present.
  • Page 7: Installation And Operator Instructions

    Lift only with equipment of adequate lifting capacity. Be sure machine is stable when lifting. Minutes or decrease The HOT ROD 500S welders can be stacked three high duty cycle when the following precautions are observed:  Be sure the bottom machine is on a firm, level surface...
  • Page 8 8. Hot Start Control: Hot Start is a temporary increase in Output Connections the output current during the start of stick (MMA) Refer to points [10], [11] and [12] of the images below. welding that helps ignite the arc quickly and reliably. The potentiometer is used to set the level of the The recommended output cable size can be found in the increased current.
  • Page 9 International Symbology Reference Maintenance The HOT ROD 500S name plates feature international WARNING symbols in describing the function of the various repair operations, modifications components. Below are the symbols used and an maintenances, it is recommended to contact the nearest explanation of what each represents.
  • Page 10 We respond to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice. We expressly disclaim any warranty of any kind, including any warranty of fitness for any customer’s particular purpose,...
  • Page 11: Weee

    12/05 Part List reading instructions  Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed.  Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine.
  • Page 12: Accessories

    Accessories K10376 Adapter M14/DINSe (F) (to connect the welding cables). * E/H-400A-70-5M Welding Cable with the Holder for Coated Electrodes 5m. * GRD-600A-95-5M Ground Cable with the Work Clamp 5m. FL060583010 FLAIR 600 Gouging torch with mounted monocable 2,5m * N/B-600A-95-5M 5m-extension cable for gouging torch.
