Lincoln Electric Power Wave 455M Robotic Brochure

®

Power Wave

®
Power Wave
Product Product
Name Number
Power Wave 455M Robotic K2262-1
Power Wave 455M/STT Robotic K2263-1
(1) At rated output.
455M Robotic &
455M/STT Robotic
1)
(
TECHNICAL SPECIFICATIONS
Input Rated Output
Voltage Current/Voltage/Duty Cycle
208/230/460/575/3/50/60
450A/38V/100%
(570A/43V/60%)
400A/36V/100%
(500A/40V/60%)
AUTOMATED SOLUTIONS
CC
DC
CV
Input current
@Rated Output
60Hz: 60Hz:
58/53/25/22A
(82/78/37/31A)
50Hz: 50Hz:
49/45/23/18A
(67/61/31/25A)
3
50
60
Hz
PHASE
Output Dimensions Net
Range H x W x D Weight
in. (mm) lbs. (kg)
5-570A 26.1 x 19.9 x 32.9 286
(663 x 505 x 835) (130)
293
(133)
Publication E10.90 4/03
www.lincolnelectric.com
