DBG R65 ALUMINIUM 6-LED
DIRECTIONAL WARNING MODULE
INSTALLATION + OPERATING INSTRUCTIONS
! IMPORTANT ! - Read all instructions before installing and operating the module. This module
must be installed by a qualified automotive technician. Failure to do so may void your warranty.
Voltage Range
LED Colour
Number of LEDs
Watts
Mounting
Flash Patterns
Connection
Syncable?
Approvals
IP Rating
Dimensions (l) x (h) x (d)
www.dun-bri.com
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
308.033
10-30V
Amber
6
18W
Bracket Mount
10
Fly Lead
Yes (with alternating sync)
ECE R65 (Class I), ECE R10
IP67
142mm x 30mm x 35mm
+44 (0)1763 274185
v1.0
