dun-bri GROUP DBG M37 Series Manual

DBG M37 SERIES R65 LED
WARNING MODULE
INSTALLATION + OPERATING INSTRUCTIONS
! IMPORTANT ! - Read all instructions before installing and operating the module. This module
must be installed by a qualified automotive technician. Failure to do so may void your warranty.
Voltage Range
LED Colour
Mounting
Connection
Flash Patterns
Syncable?
Dimmer Function
IP Rating
MODELS AVAILABLE
SKU LEDs
308.HPF303VV 3
308.HPF304VV 4
308.HPF305VV 6
www.dun-bri.com
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
M37 Series
10-30V
Amber
Surface Mount (2 Screws)
Fly Lead
8 for 3-LED version / 12 for 4-LED & 6 LED versions
Yes
No
IP67
Flash Patterns Approvals
8 ECE R65 (Class I), ECE R10
12 ECE R65 (Class I), ECE R10
12 ECE R65 (Class I), ECE R10
+44 (0)1763 274185
Dimensions (l) x (h) x (d)
82mm x 30mm x 14mm
98mm x 30mm x 14mm
130mm x 30mm x 14mm
sales@dun-bri.com
v1.1
