dun-bri GROUP DBG M35 Series Installation & Operating Instructions

DBG M35 SERIES R65 LED
WARNING MODULE
INSTALLATION + OPERATING INSTRUCTIONS
! IMPORTANT ! - Read all instructions before installing and operating the module. This module
must be installed by a qualified automotive technician. Failure to do so may void your warranty.
Voltage Range
LED Colour
Mounting
Connection
Flash Patterns
Syncable?
Dimmer Function
IP Rating
MODELS AVAILABLE
SKU
308.HPF306VV
308.HPF307VV
www.dun-bri.com
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
M35 Series
10-30V
Amber
Surface Mount (2 Screws)
Fly Lead
19
Yes (with alternating sync)
HPF307VV version only
IP69K
LEDs Approvals
6 ECE R65 (Class I), ECE R10
6 ECE R65 (Class II), ECE R10
+44 (0)1763 274185
Watts Dimensions (l) x (h) x (d)
18W 100mm x 28mm x 12mm
18W 100mm x 28mm x 12mm
sales@dun-bri.com
v1.1
