dun-bri GROUP DBG M38 Series Installation & Operating Instructions

DBG M38 SERIES R65 LED
WARNING MODULE
INSTALLATION + OPERATING INSTRUCTIONS
! IMPORTANT ! - Read all instructions before installing and operating the module. This module
must be installed by a qualified automotive technician. Failure to do so may void your warranty.
Voltage Range
LED Colour
Mounting
Connection
Flash Patterns
Syncable?
Dimmer Function
IP Rating
MODELS AVAILABLE
SKU LEDs
308.HPF310VV 3
308.HPF308VV 6
308.HPF309VV 12
www.dun-bri.com
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
M38 Series
10-30V
Amber
Surface Mount (2 Screws)
Fly Lead
11 for 3-LED version / 19 for 6-LED & 12 LED versions
Yes (with alternating sync)
6-LED & 12-LED versions only
IP69K
Approvals
ECE R65 (Class I), ECE R10, SAE J595
ECE R65 (Class II), ECE R10, SAE J595
ECE R65 (Class II), ECE R10, SAE J595
+44 (0)1763 274185
Watts Dimensions (l) x (h) x (d)
9W 82mm x 30mm x 11mm
18W 130mm x 30mm x 11mm
36W 130mm x 40mm x 11mm
sales@dun-bri.com
v1.1
