Simrad WBAT Setting Up

Wideband Autonomous
Transceiver
Setting up the WBAT
1. Removal of the USB flash drive
for data retrieval
Using a 24mm (6–point socket) and ratchet
a Remove the
USB
b Remove the gasket protecting the USB flash
drive.
c Remove the USB flash drive.
d During short-term storage the
be used in place of the USB flash drive.
Note
Do not remove the
Communication
cap.
cap may
"red"
end-cap.
2. Transducer end-cap removal for
battery replacement
From a suitable workbench
• Remove the nylon retainer cord
end-cap clear of the housing.
Note
Open vent valve
The safety valve
3. Battery and O-ring replacement
Using the integrated handle
a Remove the battery and replace with Lithium
or (optional)NiMH rechargeable batteries.
b Check and replace O-rings as needed at
, and
(B)
418472 / A /
to release internal pressure.
(A)
indicates overpressure.
(B)
.
(C)
and pull the
(!)
,
(A)
