4.2. Feature Callouts | Connectors & Hardware (Board)
1: Board mounting
holes (x4)
2: JST Battery
Connector
3: Power & CAN
connector (J5)
TABLE 5 - BOARD CONNECTORS & HARDWARE
Category
Mechanical
Connector
Connector
Connector
Mechanical
Connector
Connector
Connector
Embedded Planet, Inc. | 31225 Bainbridge Rd Suite N, Solon, OH 44139 | 216-245-4180 | www.embeddedplanet.com | Page 8 of 39
epConnected Vehicle | Product User Manual
8: Tectonic Edge™
connector for Agora
Reference Component Type
1 Board mounting holes
2 JST / Battery
3 Power & CAN
4 I/O array
5 Agora mounting posts
6 ARM Cortex
7 TagConnect
8 Tectonic Edge™
Version: 1.0.0 | 25 Feb 22
7: TagConnect programming/
debug connector
4: I/O Connector (J6)
Description / Purpose
Mounting hardware for use with enclosure
Connector input for LiPo battery power
Interface for CAN & power input
Interface for assorted I/O
For securing Agora to the host board
For programming/debug (SWD)
For programming/debug (SWD)
Board Edge/Finger interface for Agora
6: ARM Cortex
programming/
debug connector
5: Agora
mounting posts
