4.3.
Feature Callouts | Connectors & Hardware (Enclosure)
1: Mounting holes on each
side of the enclosure (x2)
TABLE 6 – ENCLOSURE CONNECTORS & HARDWARE
Category
Mechanical
Connector
Connector
Connector
Connector
Embedded Planet, Inc. | 31225 Bainbridge Rd Suite N, Solon, OH 44139 | 216-245-4180 | www.embeddedplanet.com | Page 9 of 39
Embedded Planet, Inc.
epConnected Vehicle | Product User Manual
2: Power/CAN connector
Reference
1
2
3
4
5
3: I/O connector
Component Type
Enclosure mounting holes
Power/CAN
I/O array
GNSS antenna
Cellular antenna
Version: 1.0.0 | 25 Feb 22
4: GNSS antenna
connector (SMA)
Description / Purpose
For securing device enclosure
Connector for power & CAN bus
Connector for external I/O array
External SMA-style GNSS antenna port
External SMA-style Cellular antenna port
5: Cellular
antenna
connector
(SMA)
