- Page 1 WPS-QPM01 HDMI/DP over Fiber Transceiver (10Gbit/s SFP+) Operation Manual Operation Manual...
- Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 3 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
CONTENTS 1. MAIN FEATURES ..........1 2. OPERATION CONTROL AND FUNCTIONS ..1 2.1 Receiver ............1 2.2 Transmitter........... 2 3. CONFIGURING YOUR HYSHARE VIA WEB ... 2 4. BEGIN TO CAST WITH HYSHARE ....3 5. USER LOGIN ............ 4 6. - Page 5 9.11 WiFi Enterprise ........18 9.12 Fixed Hos ..........18 9.13 Castcode Control ........19 9.14 Upgrade ........... 19 9.15 Multicast ..........20 9.16 Download Pairing File......21 9.17 Reboot ............. 21 9.18 Reset to Factory Default ......22 10. ABOUT DEVICE ........22...
-
Page 6: Main Features
1. MAIN FEATURES 1.1 No App required, just press one key to work with projector. 1.2 High compatibility with iOS, Android, Windows, MacOS. 1.3 Supports 1080p input and up to 3840x2160@30Hz output. 1.4 5GHz Wi-Fi transmission. 1.5 Support touch back, Google Cast and AirPlay. 1.6 Support 4 of splitter screens. -
Page 7: Transmitter
2.2 Transmitter HDMI Input: Connect to the source. USB: Connect to the USB port to get the power. 3. CONFIGURING YOUR HYSHARE VIA WEB With Hyshare, the user may configure their device via a web browser interface instead, which greatly enhances the user experience. In Hyshare’s Web Setting sections, customers may do custom settings including output resolution, preferred language, max connections, etc, based on different needs and usage scenarios. -
Page 8: Begin To Cast With Hyshare
4. BEGIN TO CAST WITH HYSHARE Before casting with Hyshare, please follow the below instructions, and connect your phone or laptop to Hyshare. We provide the user with two connecting methods: Direct Link or Through Wi-Fi. 4.1 Connecting through Direct Link 4.1.1 Connecting Hyshare to an external power supply. -
Page 9: User Login
4.2 Connecting Through Wi-Fi or External AP 4.2.1 If Hyshare is connected to the internet, the Wi-Fi icon will be displayed at the upper right corner of the standby screen. 4.2.2 Entering the IP address at the URL bar. You may see the IP address at the bottom left corner. -
Page 10: Download Android Apk
6. DOWNLOAD ANDROID APK For Android users, please enable USB debugging mode for USB display first, or you can download Hyshare APK from Hyshare’s webpage. Hyshare may need your further authorization and trust to install the APK file. Note: Hyshare APK supports from Android 5.0 and up. 7. -
Page 11: Remember Wi-Fi
7.2 Remember Wi-Fi The user can choose to remember the Wi-Fi or not. -
Page 12: Device Management
8. DEVICE MANAGEMENT Hyshare provides users with the following configuration options, including Language, Resolution, Maximum Connections, and so on. 8.1 Language Supporting mainstream languages, and auto language translation. -
Page 13: Resolution
8.2 Resolution Hyshare will select proper output resolution automatically. The user may switch to other options based on different usage scenarios. The default output resolution is 1920 x 1080_60P. Hyshare can support up to 3840 x 2160_30P. -
Page 14: Maximum Connections
8.3 Maximum Connections The host may decide the number of devices that are allowed to connect to Hyshare. The default setting of connections is 8 users. Please note that with the rising of connected devices, the lower network bandwidth would have for each user. -
Page 15: Reboot Timer
8.5 Reboot Timer The system will reboot after 8 hours of inactivity to release the temporary file. 8.6 One Touch Play If the display supports HDMI CEC, Hyshare Receiver will turn on the display when it is power on. -
Page 16: Admin Settings
9. ADMIN SETTINGS Admin Settings is designed for advanced users, including MIS Engineer, IT specialist, Network admin, etc. In the Admin Settings sections, Hyshare provides various custom configurations. 9.1 Wi-Fi Channel Setting up Wi-Fi Channel. Hyshare provides three options: Country, Channel and Bandwidth. -
Page 17: Lan Ip Settings
9.2 LAN IP Settings Configuring LAN network, including IP address, Gateway, Netmask, DNS, etc. 9.3 SSID Custom setting for SSID, including renaming, hide SSID or turn off SSID. - Page 18 9.3.1 Hide SSID: Hide SSID from the standby screen. Please make sure you’ve written it down. 9.3.2 Turn Off SSID: Deactivating Hyshare’s SSID function. Please make sure that the device is already connected to LAN.
-
Page 19: Password
9.4 Password Change Hyshare’s Wi-Fi connection password. 9.5 My Screen The user may replace the default theme of the standby screen by uploading photos. Please make sure the image format is PNG format in 1920 x 1080 and smaller than 2MB. -
Page 20: Dynamic Wallpaper
9.6 Dynamic Wallpaper Custom setting for dynamic wallpaper, upload the file through URL or USB disk. 9.7 Host Control: An admin can control other casting devices. 9.7.1 Auto Allow Request: Once turned on, other devices can cast content to the output screen directly. 9.7.2 Share Screen: Once turned on, based on the number of connected devices, the output screen will be split into one-half or one-quarter. -
Page 21: Airplay Support
9.8 AirPlay Support AirPlay function is turned off by default. iOS, OSX users may turn on to utilize AirPlay, native casting function provided by Apple. -
Page 22: Admin Password
9.9 Admin Password To provide better security, we suggest that the user may change an Admin Password regularly. 9.10 Screen Saver Specifies how much user idle time must elapse before the screen saver is launched. -
Page 23: Wifi Enterprise
9.11 WiFi Enterprise Wi-Fi Enterprise function allows a user to upload a digital certificate. This function is designed for the advanced user, including MIS Engineer, Network Admin, etc. 9.12 Fixed Hos Set the host by dynamic, fixed IP or fixed device. -
Page 24: Castcode Control
9.13 Castcode Control Mirrors the screen by entering the cast code displayed on the standby screen. 9.14 Upgrade Upgrade your Hyshare Receiver and Transmitter’s firmware to the latest version. Please make sure Hyshare is connected to the internet during the updating process. To better enhance the user experience, it is highly recommended that maintaining the consistency of devices’... -
Page 25: Multicast
9.14.1 Please make sure Hyshare Receiver is connected to the internet. 9.14.2 Connect Hyshare Transmitter to an external power supply. Please make sure your Transmitter has been paired with the Receiver. 9.14.3 Click “Select All”, allowing the user to update all Hyshare devices at once. -
Page 26: Download Pairing File
9.16 Download Pairing File Download the required file for pairing R01 and T01. 9.17 Reboot The user may reboot the device when a new configuration is applied to Hyshare. -
Page 27: Reset To Factory Default
9.18 Reset to Factory Default Reset Hyshare to factory defaults. Please note that all the custom configurations will be cleared. 10. ABOUT DEVICE Showing details device information about Hyshare, including SSID, firmware version, Wi-Fi channel, etc. - Page 28 CYPRESS TECHNOLOGY CO., LTD. www.cypress.com.tw...
