- Page 1 WPS-QPL01 HDMI/DP over Fiber Transceiver (10Gbit/s SFP+) Operation Manual Operation Manual...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. MAIN FEATURES ..........1 2. OPERATION CONTROL AND FUNCTIONS ..1 2.1 Receiver ............1 2.2 Transmitter........... 2 3. CONFIGURING YOUR HYSHARE VIA WEB ... 2 4. BEGIN TO CAST WITH HYSHARE ....3 5. USER LOGIN ............ 4 6. -
Page 6: Main Features
1. MAIN FEATURES 1.1 No App required, just press one key to work with projector. 1.2 High compatibility with iOS, Android, Windows and MacOS. 1.3 Supports 1080p input resolution. 1.4 Supports output resolution up to 3840x2160@30Hz. 1.5 5GHz Wi-Fi transmission. 1.6 Support touch back, Chromecast and AirPlay. -
Page 7: Transmitter
2.2 Transmitter HDMI Input: Connect to the source. USB: Connect to the USB port to get the power. 3. CONFIGURING YOUR HYSHARE VIA WEB With Hyshare, the user may configure their device via a web browser interface instead, which greatly enhances the user experience. In Hyshare’s Web Setting sections, customers may do custom settings including output resolution, preferred language, max connections, etc, based on different needs and usage scenarios. -
Page 8: Begin To Cast With Hyshare
4. BEGIN TO CAST WITH HYSHARE Before casting with Hyshare, please follow the below instructions, and connect your phone or laptop to Hyshare. We provide the user with two connecting methods: Direct Link or Through Wi-Fi. 4.1 Connecting through Direct Link 4.1.1 Connecting Hyshare to an external power supply. -
Page 9: User Login
4.2 Connecting Through Wi-Fi or External AP 4.2.1 If Hyshare is connected to the internet, the Wi-Fi icon will be displayed at the upper right corner of the standby screen. 4.2.2 Entering the IP address at the URL bar. You may see the IP address at the bottom left corner. -
Page 10: Network Management
6. NETWORK MANAGEMENT Connecting Hyshare to the internet through external Wi-Fi or LAN. 6.1 Connect to 5GHz Wireless Access Point: Once your device is connected to Hyshare, entering the required password to access an external Wi-Fi. 6.1 Remember Wi-Fi: The user can choose to remember the Wi-Fi or not. -
Page 11: Device Management
7. DEVICE MANAGEMENT Hyshare provides users with the following configuration options, including Language, Resolution, Maximum Connections, and so on. 7.1 Language Supporting mainstream languages, and auto language translation. -
Page 12: Resolution
7.2 Resolution Hyshare will select proper output resolution automatically. The user may switch to other options based on different usage scenarios. The default output resolution is 1920 x 1080_60P. Hyshare can support up to 3840 x 2160_30P. -
Page 13: Display Mode
7.3 Display Mode Choose the display default to fit to screen or stretch to full screen. 7.4 Reboot Timer The system will reboot after 8 hours of inactivity to release the temporary file. -
Page 14: One Touch Play
7.5 One Touch Play If the display supports HDMI CEC, Hyshare Receiver will turn on the display when it is power on. -
Page 15: Admin Settings
8. ADMIN SETTINGS Admin Settings is designed for advanced users, including MIS Engineer, IT specialist, Network admin, etc. In the Admin Settings sections, Hyshare provides various custom configurations. 8.1 Wi-Fi Channel Setting up Wi-Fi Channel. Hyshare provides three options: Country, Channel and Bandwidth. -
Page 16: Ssid
8.2 SSID Custom setting for SSID, including renaming, hide SSID or turn off SSID. 8.2.1 Hide SSID: Hide SSID from the standby screen. Please make sure you’ve written it down. 8.2.2 Turn Off SSID: Deactivating Hyshare’s SSID function. Please make sure that the device is already connected to LAN. -
Page 17: Password
8.3 Password Change Hyshare’s Wi-Fi connection password. 8.4 My Screen The user may replace the default theme of the standby screen by uploading photos. Please make sure the image format is PNG format in 1920 x 1080 and smaller than 2MB. -
Page 18: Dynamic Wallpaper
8.5 Dynamic Wallpaper Custom setting for dynamic wallpaper, upload the file through URL or USB disk. -
Page 19: Admin Password
8.6 Admin Password To provide better security, we suggest that the user may change an Admin Password regularly. 8.7 Screen Saver Specifies how much user idle time must elapse before the screen saver is launched. -
Page 20: Upgrade
8.8 Upgrade Upgrade your Hyshare Receiver and Transmitter’s firmware to the latest version. Please make sure Hyshare is connected to the internet during the updating process. To better enhance the user experience, it is highly recommended that maintaining the consistency of devices’ firmware version, both Hyshare Receiver and Transmitter. -
Page 21: Reboot
8.9 Reboot The user may reboot the device when a new configuration is applied to Hyshare. 8.10 Reset to Factory Default Reset Hyshare to factory defaults. Please note that all the custom configurations will be cleared. -
Page 22: About Device
9. ABOUT DEVICE Showing details device information about Hyshare, including SSID, firmware version, Wi-Fi channel, etc. - Page 24 CYPRESS TECHNOLOGY CO., LTD. www.cypress.com.tw...
