Owner's Manual
Antimicrobial Protection
200 x 200 / 300 x 200 /
300 x 300 / 400 x 200 /
400 x 300 / 400 x 400 /
600 x 400 / 800 x 400 /
800 X 600 / 1000 X 600
Este manual está disponible en español en la página de Tripp Lite: tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Super Heavy-Duty
Mobile Display Cart
with UL Certification &
Model: DMCS70120AMUL
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS
INJURY OR PROPERTY DAMAGE MAY OCCUR!
120"
264 lb. / 120 kg
264 lb. / 120 kg
MAX
Tripp Lite по адресу: tripplite.com
Copyright © 2021 Tripp Lite. All rights reserved.
11 lb. / 5 kg
11 lb. / 5 kg
Flat-Panel
Flat-Panel
AV Shelf
AV Shelf
TV Mount
TV Mount
®
1
11 lb. / 5 kg
11 lb. / 5 kg
Video Tray
Video Tray
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tripp Lite DMCS70120AMUL
Summary of Contents for Tripp Lite DMCS70120AMUL
- Page 1 800 X 600 / 1000 X 600 Este manual está disponible en español en la página de Tripp Lite: tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании...
-
Page 2: Safety Instructions
PRODUCT REGISTRATION Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details. -
Page 3: Component Checklist
Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit tripplite.com/support for service. Left Leg (x1) Right Leg (x1) Cross Bracket (x1) Casters (x4) Lower Column (x2) Handle (x2) Mounting Plate Assembly (x1) AV Equipment Shelf (x1) -
Page 4: Assemble The Base
Assembly Assemble the Base Lock the brakes on the casters to avoid any sudden movements during installation. Assemble the Columns... - Page 5 Assembly Assemble the Columns Attach the Mounting Plate to the Column Loosen the screws to leave a gap greater than 4 mm.
- Page 6 Assembly Assemble the AV Equipment Shelf Loosen the screws to leave a gap greater than 4 mm. Assemble the Top Covers and End Caps...
- Page 7 Assembly Attach the TV Bracket to the Back of a Flat or Curved Screen...
- Page 8 Assembly Hang and Secure the Screen • Turn the bottom screw counterclockwise to tighten it. • Turn the bottom screw clockwise to loosen it. • Use a padlock (not included) to prevent theft of the display. IMPORTANT: Ensure the display is correctly mounted before releasing the display.
- Page 9 Assembly Assemble the Camera Shelf Attach the camera shelf to proper position according to the TV size.
- Page 10 Assembly Cable Management...
- Page 11 Adjustment 63 in. 61 in. 59 in. 57 in. 55 in. Height markings represent the 53 in. distance from the floor to the 51 in. center of the TV screen. 49 in.
-
Page 12: Troubleshooting
Troubleshooting If the columns are not properly aligned, the mouting plate may fail to attach to the columns. Follow the steps below to re-assemble the columns. Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months).
