Echo DSRM-2600/U Operator's Manual

Grass trimmer / brushcutter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

DSRM-2600/U

Grass Trimmer /

Brushcutter

Read and understand all provided literature before use. Failure

to do so could result in serious injury.

Cancer and Reproductive Harm

www.P65Warnings.ca.gov

X7508163900

Operator's

Manual

Table of Contents

Need help?

Do you have a question about the DSRM-2600/U and is the answer not in the manual?

Questions and answers

Summary of Contents for Echo DSRM-2600/U

Page 1 Operator’s Manual DSRM-2600/U Grass Trimmer / Brushcutter Read and understand all provided literature before use. Failure to do so could result in serious injury. Cancer and Reproductive Harm www.P65Warnings.ca.gov X7508163900 © 10/21 ECHO Incorporated...
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction......................... 3 Servicing Information....................3 Parts and Serial Number..................3 Service ....................... 4 ECHO Consumer Product Support ..............4 Product Registration................... 4 Additional Literature ................... 4 Safety ......................... 4 For safe use of your product ................4 International Symbols..................
Page 3: Introduction
Parts and Serial Number Genuine ECHO Parts and Assemblies for your ECHO products are available only from an Authorized ECHO Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you.
Page 4: Service
Register your ECHO equipment online at www.echo-usa.com or by filling out the product registration sheet included in this manual. Registering your product confirms warranty coverage and provides a direct link to ECHO if we find it necessary to contact you.
Page 5: International Symbols
This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result in serious or fatal injury. International Symbols Symbol Description Symbol Description Warning, See Hot Surface Operator’s Manual Wear Eye, Ear and Warning, side thrust Head Protection X7508163900 © 10/21 ECHO Incorporated...
Page 6: Handling The Product
Read all safety warnings and all instructions and specifications provided with this power tool. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. X7508163900 © 10/21 ECHO Incorporated...
Page 7 Do not use a power tool while you are tired, ill, or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. X7508163900 © 10/21 ECHO Incorporated...
Page 8 • Keep clothing buttoned or zipped, and keep shirt tails tucked in. • Wear sturdy work shoes with nonskid rubber soles. • DO NOT WEAR OPEN TOED SHOES. • DO NOT OPERATE UNIT WITH BARE FEET. X7508163900 © 10/21 ECHO Incorporated...
Page 9 • Use only with ECHO eFORCE™ 56V battery series. Use of any other battery may create a risk of injury and fire.
Page 10 This will ensure that the safety of the power tool is maintained. Environmentally Safe Battery Disposal R B R C Li - ion The toxic and corrosive materials below are in the batteries used in this machine: Lithium-Ion, a toxic material. X7508163900 © 10/21 ECHO Incorporated...
Page 11 Spectators and fellow workers must be warned, and children and animals prevented from coming nearer than 50 ft. (15 m) while the unit is in use. X7508163900 © 10/21 ECHO Incorporated...
Page 12: Equipment
Incorporated will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO Incorporated. Read and comply with all safety instructions. Do not attempt to modify this product. Serious injury can ◆...
Page 13 ◆ or other damage, and repair or replace as needed. Exposed wire or connectors can cause shocks, sparks, and risk of fire or explosion, resulting in serious injury. Check wire terminals for secure connections. ◆ X7508163900 © 10/21 ECHO Incorporated...
Page 14: Description
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. Safety label is for example only. Your label may appear slightly different.
Page 15: Contents
Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. DSRM-2600: Power Head / Drive Shaft Assembly Operator’s Manual...
Page 16: Assembly
Parts required: U-Handle assembly, handle bolt Install U-handle clamp (A) to drive shaft clamp (B). Secure with U-handle bolt (C). Loosen upper two (2) U-handle clamp screws (D) and position U-handle assembly for comfortable operation. Tighten U-handle clamp screws. X7508163900 © 10/21 ECHO Incorporated...
Page 17: Shield Installation
Place line head plate (A) on PTO shaft (F). Nylon Line Head Installation Parts Required: Nylon Line Head. Wear Gloves or personal injury may result: Cutoff knife is sharp. ◆ Gearcase and surrounding area may be hot. ◆ X7508163900 © 10/21 ECHO Incorporated...
Page 18: To Advance Trimmer Line
Battery Charging Note: See separate operator’s manuals packaged with battery and charger. • Use only with ECHO eFORCE™ 56V battery series batteries and chargers. • Keep charger and battery away from damp conditions and all liquids. • Do not operate the charger on an easily combustible surface (e.g. paper, textiles) or in an environment with a high risk of fire.
Page 19 The battery comes partially charged from the factory and needs to be fully charged before first use. Charge the battery when it no longer produces sufficient power to operate the unit or when battery lights indicate that the battery is low. X7508163900 © 10/21 ECHO Incorporated...
Page 20 25-50% charge. • Three green lights indicate that the battery has 50-75% charge. • Four green lights indicate that the battery has 75-100% charge. Unplug charger AC cord from the wall outlet. X7508163900 © 10/21 ECHO Incorporated...
Page 21 Slide battery into power head. Assure the battery latch (B) snaps into place and battery is secure before beginning operation. Assure battery latch is fully engaged before using unit. X7508163900 © 10/21 ECHO Incorporated...
Page 22: Balance And Adjust Unit - U Model
OPERATION Operation with Blades Metal blades are very sharp and can cause severe injuries, even if unit is off and blades are not moving. Avoid contact with blades. Wear gloves to protect hands. X7508163900 © 10/21 ECHO Incorporated...
Page 23 U-Handle ensures a higher safety factor. Do Not install blades on GT (Curved Shaft) model trimmers. • Use only ECHO approved parts. Failure to use the correct parts can cause the blade to fly off. Seriously injury to the operator and / or bystanders can occur.
Page 24: Blade Selection
13 mm (0.5 in.) diameter. 22-Tooth Clearing Blade is designed for dense thickets and saplings up to 64 mm (2.5 in.) diameter. A trimmer-brushcutter with a metal blade can cause serious injuries if handled improperly. X7508163900 © 10/21 ECHO Incorporated...
Page 25: Starting Unit
The attachment will operate when the battery is installed, the power indicator LED is lit, and the trigger switch and trigger switch lockout are engaged. Make sure the product is properly positioned to prevent loss of control and possible serious injury. X7508163900 © 10/21 ECHO Incorporated...
Page 26: Stopping Unit
Install battery. Turn power on to unit. If flashing continues, have your authorized servicing dealer repair the product. Stopping Unit The cutting attachment continues to run for a short period after the unit is switched off. X7508163900 © 10/21 ECHO Incorporated...
Page 27: Applications
Feed the line gradually into the material you wish to cut, avoiding contact with fences or other barriers. • GT models: Tilt cutting head to the left while cutting to direct debris away from the operator. X7508163900 © 10/21 ECHO Incorporated...
Page 28: Operating Techniques - Metal Or Plastic Blade
• Do not scythe back and forth as the grass may scatter and kickback may occur easily. • Tilt blade left by 5 to 10 degrees so that cut grasses will push left, making progress easier. • Move forward with each arc to cut a swath. X7508163900 © 10/21 ECHO Incorporated...
Page 29: Reaction Forces
The greater the cutting force or the amount of resistance, the greater the reactive force. X7508163900 © 10/21 ECHO Incorporated...
Page 30 • Applying consistent, even force to the blade during the cut • Avoiding obstacles and ground hazards • Using extra care when cutting harder materials such as extremely dry brush, saplings, and small trees • Cutting from a stable, secure position X7508163900 © 10/21 ECHO Incorporated...
Page 31: Blade Cutting Problems
To prevent binding: • Keep blades sharp • Avoid excessive pressure during cuts • Don’t exceed cutting capacity of blade • Don’t use blades with damaged or missing cutting teeth • Don’t rock blades in cut X7508163900 © 10/21 ECHO Incorporated...
Page 32: Maintenance
Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. Level 3 = See your dealer. Click HERE or go to http://www.echo-usa.com/products/maintenance-kit HERE https://www.shindaiwa-usa.com/you-can.aspx X7508163900 © 10/21 ECHO Incorporated...
Page 33: Maintenance And Care
Time intervals shown are maximum. Actual use and your experience will determine the frequency of required maintenance. If you continuously use vegetable based chain oil, inspect and do maintenance often. When you find anything wrong, ask your ECHO dealer for repair. Maintenance and Care Remove battery before performing maintenance procedures.
Page 34: Lubrication
Wear gloves or personal injury may result: Cut-off knife is sharp. ◆ Gearcase and surrounding area may be hot. ◆ Inspect cut-off knife (B) for damage or wear. Assure that it is properly attached to debris shield. X7508163900 © 10/21 ECHO Incorporated...
Page 35 Remove plug (A) and check level of grease. Add grease if necessary. DO NOT over-fill. Flex Cable Loosen handle clamping screw (B) and slide throttle handle forward. Loosen clamping screw (C) and slide shaft out of power head. X7508163900 © 10/21 ECHO Incorporated...
Page 36: Nylon Line Replacement
Cut one piece of line to recommended length. 2.0 mm (0.080 in.) diameter 6 m (20 ft.). 2.4 mm (0.095 in.) diameter 6 m (20 ft.). Align arrows on top of knob with openings in eyelets. X7508163900 © 10/21 ECHO Incorporated...
Page 37 When the wear indicators located at the bottom of the ® Speed-Feed head are worn smooth, or if holes appear, replacement of the cover or the ® entire Speed-Feed head required. X7508163900 © 10/21 ECHO Incorporated...
Page 38: Sharpening Metal Blades
If an electric grinder is used, use care not to overheat teeth, do not allow tips/tooth to glow red or turn blue. DO NOT place blade in cooling water. This will change the temper of the blade and could result in blade failure. X7508163900 © 10/21 ECHO Incorporated...
Page 39: Troubleshooting
Running time is too short Battery outside Remove the battery and acceptable allow to cool temperature range Unit electronics too hot Turn unit off and allow to cool Battery discharged Charge the battery X7508163900 © 10/21 ECHO Incorporated...
Page 40: Storage
Remove battery. Remove accumulation of dirt and debris from exterior of unit. Tighten all screws and nuts. Cover battery compartment, battery and charger. Store unit in a dry, dust-free place out of the reach of children. X7508163900 © 10/21 ECHO Incorporated...
Page 41: Disposal
• Battery contains lithium. Dispose of only at a designated collection point. • Lithium-ion batteries must be disposed of properly. • Please contact your dealer in case you do not know how to dispose of or recycle waste plastic parts. X7508163900 © 10/21 ECHO Incorporated...
Page 42: Specifications
669 mm (26.34 in.) Height 293 mm (11.54 in.) 618 mm (24.33 in.) Weight (with battery) 5.4 kg (11.9 lb.) 6.1 kg (13.45 lb) Battery ECHO eFORCE™ 56V series batteries Type Li-Ion Battery voltage 56 (rated 50.4) Capacity See Battery Manual Charger type ECHO eFORCE™...
Page 43: Warranty
ECHO Incorporated, and tion or rescission of the contract of sale of any ECHO brand sold in the United States and Canada. 56 Volt outdoor product. Proof of purchase will be required by the dealer to substantiate any warranty claim.
Page 44: Product Registration
Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
Page 48 U56200001001 - U56200999999 U56500001001 - U56500999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com...
