Co-op GOLD Pallisade Hard-Top Gazebo Use And Care Manual

10' x 12'
Hide thumbs

Advertisement

Quick Links

Download this manual
Pallisade
Hard-Top Gazebo
10' X 12'
USE AND CARE GUIDE
Carefully read all instructions and caution warnings before
beginning assembly. Save this Use and Care Guide for
future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the GOLD Pallisade Hard-Top Gazebo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Co-op GOLD Pallisade Hard-Top Gazebo

Summary of Contents for Co-op GOLD Pallisade Hard-Top Gazebo

  • Page 1 Pallisade Hard-Top Gazebo 10' X 12' USE AND CARE GUIDE Carefully read all instructions and caution warnings before beginning assembly. Save this Use and Care Guide for future reference.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS MATERIAL CONTENTS ASSEMBLY INSTRUCTIONS 4–7 CARE AND MAINTENANCE SAFETY WARNINGS WARRANTY IMPORTANT INSTRUCTIONS 1. Read installation and maintenance instructions thoroughly. Be sure to use proper tools, and always wear personal protection equipment for your safety. 2. Before assembly, inspect the product for damage and ensure all parts are accounted for. 3.
  • Page 3 MATERIAL CONTENTS PARTS LIST Middle Slot “F”Baffle 1 “F”Baffle 2 “F”Baffle 3 Left Arc support Bar Right Arc support Bar Corner Support Small Roof Cover Roof connector Hook Post up connect piece Corner Cover Middle Cover Upper Closure plate Middle Closure plate Left small PC board...

  • Page 4: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Fig.1: Attach stake slice(B) on post(A) and fix them tightly by bolt(AA) and flat washer(BB) Fig.2: Attach decorative groove connector(G) to decorative grooves(C1&C2) and fix them tightly by bolt(AA) and flat washer (BB), same assembly for grooves(D1&D2) Fig.3: Attach Post(A) to decorative grooves(C1&C2) and fix them tightly by bolt(CC) and flat washer(BB), same assembly for grooves(D1&D2) Fig.4: Attach decorative grooves(C1, C2) to post(A)from the outside and fix them tightly by bolt(AA), same assembly for grooves(D1&D2)
  • Page 5 ASSEMBLY INSTRUCTIONS Fig.7: Use bolt(AA)and flat washer(BB) to lock corner support(K) to groove(C1, C2, D1, D2) Fig.8: Use bolt(EE) and washer(BB) to lock support bar (J1, J2) to decorative groove(C1, C2, D1, D2) and post(A) HARDWARE PACK 2 M6 Flat asher Bolt Fig.9:...
  • Page 6 ASSEMBLY INSTRUCTIONS Fig.12: Use bolt(AA) and washer(BB) to lock the bottom of the middle beam(F) to the decorative groove(C1, C2, D1, D2) Fig.13: Put small roof cover(L) on roof connector(M) using bolt(AA) and washer(BB); lock tightly. Assemble hook(N) to the roof connector(M). HARDWARE PACK 3 M6 Flat asher...
  • Page 7 ASSEMBLY INSTRUCTIONS Fig.17: Insert middle plate(Q2) into the bottom of middle beam(F) by bolt(AA) and washer(BB). Fig.18: Insert corner plate(Q1) into the bottom of corner beam(E) by bolt(AA) and washer(BB) 12 PCS 0mm Stake 52 PCS Plastic ing Fig.19: Use hook(GG) to attach the netting(S) to the netting tube. Fig.20: Use the velcro strap to connect netting(S) to the post(A).

  • Page 8: Care And Maintenance

    CARE AND MAINTENANCE To prevent scratching paint, use care when assembling and handling the product. Should any scratching or damage occur, cover the scratch immediately with rust-inhibiting paint (not included). Any surface rust that may occur if protective coatings are scratched can be removed with a light application of regular cooking oil.

  • Page 9: Warranty

    Co-op offers the original purchaser a one-year limited warranty on the finish of CO-OP® GOLD Gazebos against blistering, peeling or cracking within one year from the date of purchase.
